Telnet Interface

3.3.15 VLAN Information

MMB supports up to 10 VLAN IDs and as of MMB BX900 firmware version 4.71 27 VLAN IDs. In a BX400 the
MMB supports up to 13 VLAN IDs.
Figure 20: VLAN Information menu
The following parameters are displayed for each group:
Parameter
VLAN Group ID
VLAN IP
VLAN Network Mask
VLAN Enable
VLAN IPv6

3.3.16 I2C Bus Management

I
This function is no longer available in the sub-menu as of MMB BX900 firmware version 5.32.

3.3.17 Management Blade Configuration Backup/Restore

This option enables all the MMB settings, including certificates, users, etc., to be backed up/restored.
The menu for this option looks like this:
Figure 21: Management Blade Configuration Backup/Restoration menu
ServerView BX900 Management Blade
Description
Identifies different VLAN group IDs. The integer 2 to 4095 are supported.
Sets the VLAN IP.
Sets the VLAN network mask.
Enables/disables the VLAN function.
The menu item is no longer available as of MMB BX900 firmware version 4.71.
Management Agent
35
