Telnet Interface
3.3.4.6 Server Blade Temperature
This option provides information on the server temperature. Some of the parameters displayed can also be set by
the user:
Parameter
Server Temperature Sensor Designation
Server Temperature Sensor Status
Server Temperature Upper Warning Level
Server Temperature Upper Critical Level
Server Temperature Lower Warning Level
Server Temperature Lower Critical Level
Server Temperature Current Value
3.3.4.7 Server Blade NIC Information
This option displays the IP and MAC address of the server blade.
3.3.4.8 Server Blade Watch Dog
This option is used to configure the watchdog timers for the server blade. There are two timers that can bet set
here:
Timer
Server Blade Software Watchdog This timer is used to monitor the operation system and the software applica-
Server Blade Boot Watchdog
ServerView BX900 Management Blade
Description
Displays the designation of the temperature sensor for the
server blade.
Displays the status of the temperature sensor. The values
displayed will be:
– SENSOR_DISABLED
– SENSOR_FAIL
– WARNING_TEMP_WARM
– CRITICAL_TEMP_WARM
– NOT-AVAILABLE
This parameter can be set to configure the upper warning level
of the temperature sensor for the server blade.
This parameter can be set to configure the upper critical level
of the temperature sensor for the server blade.
This parameter can be set to configure the lower warning level
of the temperature sensor for the server blade.
This parameter can be set to configure the lower critical level
of the temperature sensor for the server blade.
Displays the current temperature value for the server blade.
Description
tions. A watchdog timer agent that resets the timer must be implemented in
the operation system. When the time-out is reached, a time-out routine will
be started.
This timer is used to monitor the server blade POST. It will be reset by the
BIOS in periods configured within the POST code. When the time-out is
reached, a time-out routine will be started.
Management Agent
