Management Agent
Parameter
CPU Status
CPU Name
CPU Socket Designation Displays the CPU socket designation.
CPU Manufacturer
CPU Clock
3.3.4.4 Server Blade Memory
This option provides information on the server blade memory. The information is displayed in two tables:
Table
Server Blade Memory Information
Table
Server Blade Memory Modules Table
3.3.4.5 Server Blade Voltage Table
This option provides information on the server voltage. The following parameters are displayed:
Parameter
Server Voltage Designation
Server Voltage Status
Server Voltage Minimum Value Displays the minimum voltage value for the server blade.
Server Voltage Maximum Value Displays the maximum voltage value for the server blade.
Server Voltage Current Value
Server Voltage Nominal Value
22
Description
Displays the CPU status. The values displayed will be:
– OK
– NOT_PRESENT
– ERROR
– CRITICAL
– MISSING_TERMINATION
Displays the CPU name.
Displays information on the CPU manufacturer.
Displays the CPU clock.
Description
Displays information on the total size of the memory, as well as on the
error count, the error reset record and the error count start time.
Displays the status of each memory module, together with memory type
and error information.
Description
Displays the voltage designation for the server blade.
Displays the voltage status for the server blade. The values displayed will be:
– NOT_AVAILABLE
– OK
– TOO_LOW
– TOO_HIGH
Displays the current voltage value for the server blade.
Displays the nominal voltage value for the server blade.
ServerView BX900 Management Blade
Telnet Interface
