Table of Contents

Advertisement

Quick Links

Download this manual
OKIFAX4550/
OKIOFFICE87
Maintenance Manual
2001-05-08 Rev.4
Oki Data Corporation
1 / 592
41309401TH Rev.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OKIFAX4550 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oki OKIFAX4550

Summary of Contents for Oki OKIFAX4550

  • Page 1 OKIFAX4550/ OKIOFFICE87 Maintenance Manual 2001-05-08 Rev.4 Oki Data Corporation 1 / 592 41309401TH Rev.4...
  • Page 2 Document Revision History Corrected items Person in Rev.No. Date Section Page Description of change charge 2000-03 ISSUE E3 Endo 2000-07-21 Change the APPENDIX D. EF Oba 2000-10-31 Add the OKIOFFICE87, etc. EF Saito 2001-05-08 Change the APPENDIX D. NP3 Oba 41309401TH Rev.4...
  • Page 3 PREFACE This manual is intended to be used for installing and maintaining OKIFAX4550/OKIOFFICE87 facsimile transceiver. Maintenance of the OKIFAX4550/OKIOFFICE87 is assumed to be conducted at the following levels: • Assembly-level maintenance for mechanical portions • Unit-level maintenance for electrical at portions CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.

  • Page 4: Table Of Contents

    Actual Electo-photographic Process ..................147 Boards and Units ......................... 148 3.3.1 Boards and Units ....................148 Overall Dimension and Mechanical Structure of OKIFAX4550/OKIOFFICE87 ....150 4. MECHANICAL DISASSEMBLY AND REASSEMBLY ......... 151 Precautions for Parts Replacement ..................151 Tools ............................ 153 How to Disassemble and Reassemble ................
  • Page 5 6.16 Service Codes ........................213 6.16.1 G3 Service Code List ....................214 6.16.2 G4 Service Code Lists .................... 217 7. TROUBLESHOOTING AND REPAIR FOR OKIFAX4550/OKIOFFICE87 ..220 Overall Troubleshooting Flow Chart ..................222 No LCD Operation ....................... 223 Alarm LED On ........................224 Printing Test Failure ......................
  • Page 6 Function of Each Unit ....................275 2. Explanation of Signal Flow ...................... 278 OKIFAX4550 ......................... 278 OKIOFFICE87 ....................... 294 3. 46F Circuit Diagram (OKIFAX4550) ..................310 46F Circuit Diagram (1/13) .................... 310 46F Circuit Diagram (2/13) .................... 311 46F Circuit Diagram (3/13) .................... 312 46F Circuit Diagram (4/13) ....................
  • Page 7 Manipulating User Information ..................528 5. Model Main Screen ........................530 Screen Title ........................530 ONLINE Operation ......................530 APPENDIX H OKIFAX4550/OKIOFFICE87 TROUBLESHOOTING MANUAL ..533 1. General ............................ 533 2. Tools ............................533 3. Contents........................... 533 46F Board (OKIFAX4550) ..................... 533 R46 Board (OKIOFFICE87) ...................

  • Page 8: General Information

    • 128 mm to 356 mm (Length setting: Unlimited (1500mm) is also available.) (7) Automatic document feeder (ADF) • 20 sheets (NA Letter/A4-size: 20-1b bond/75 gm. Oki Data recommended paper) • 15 sheets (NA Letter/A4-size: 16 to 28-1b bond/60-105 gm) Note:...
  • Page 9 • Max. 8 sheets per minute (at NA letter size) (18) Pre-heating time • Approx. 30 sec. (Standby to Print) Note: This feature is not available OKIFAX4550/OKIOFFICE87 for ODA version. (19) Coding scheme • Modified Huffman (MH) • Modified READ (MR) •...
  • Page 10 Note: This is Phase C time at 3.85 line/mm and 33600 bps for 3 sec. in MMR code transmission. (22) Protocol • ITU-T Rec. T.30 • ITU-T Rec. G4 class 1 (option) • OKI special protocols: High-speed protocol (G3) (23) Error correction scheme • ITU-T ECM (24) Communication mode •...

  • Page 11: General User's Functions

    General User's Functions (1) Transmit mode • Automatic transmit mode • Manual transmit mode (2) Receive mode • Automatic receive mode • Manual receive mode • TEL/FAX automatic switchover mode • TAD mode • Memory only receive mode • Forwarding mode •...
  • Page 12 (21) G3 sequential broadcast (Memory) • Broadcast mode 90 stations at maximum for OKIFAX4550 120 stations at maximum for OKIOFFICE87 • Delayed broadcast mode (22) No paper/no toner reception (23) Memory-only reception (Memory reception even if paper does not run out)
  • Page 13 (44) PC interface • Standard: OKIOFFICE87 • Option: OKIFAX4550 Note: Hardware is mounted. (45) Language selection • 2 languages (LCD and Reports) (46) Reports • Activity report • Active memory files report • Protocol report • Message confirmation report (Single address and multiple addresses) •...

  • Page 14: General Maintenance Functions

    General Maintenance Functions Local tests (1) Self-diagnosis • CPU ROM/RAM check • FLASH memory check (Program, Language, Default) • RAM check • Print test (2) Sensor calibration (Adjustment of scanning level) (3) LEDs test (4) Tone send test (When NCU board is installed.) (5) Multi-frequency (MF) send test (When NCU board is installed.) (6) High-speed modem send test (When NCU board is installed.) (7) High-speed modem receive test (When NCU board is installed.)

  • Page 15: General Appearance

    General Appearance Figure 1.1 shows the general appearance of the OKIFAX4550/OKIOFFICE87. Figure 1.2 shows the control panel of the OKIFAX 4550. Tray-Paper Tray-Document Cover-Top Case-OPE (T) Cover-Front Cover-Main Cover Manual Document Stacker-Document Figure 1.1 General Appearance of OKIFAX4550/OKIOFFICE87 15 /...
  • Page 16 8.5" A4 RELAY PRINT DELAYED CONF.TX POLLNG OPERATION INIT.-TX 9/SPACE 10/PAUSE REPORT COUNTER LOCATION USER PRINTER PROG. CLEANING PRINT DISPLAY PROG. WXYZ PQRS 4550 OKIFAX STOP START UNIQUE EX FINE FINE ALARM PHOTO LIGHT NORMAL DARK SELECT HOOK AUTO REC HYPHEN SEARCH REDIAL...

  • Page 17: Basic Performance Specifications

    Basic Performance Specifications Table 1.1 shows basic performance specifications. Note: Technical function setting Function program setting One-touch key pressed SELECT FUNCTION key pressed Table 1.1 (1/11) Basic Performance Specifications Item Specifications Applicable line 1) Public switched telephone network (PSTN) 2) Private branch exchange (PBX) (OT9+2) Line interface 1) Impedance 600Ω...
  • Page 18 Horizontal Reduction = ON) Note: Local copy: Printable reading width in local copy mode Automatic document feeder (ADF) Max. 20 documents for OKIFAX4550/OKIOFFICE87: NA Letter or A4 (20-1b/75 gm) Max. 15 documents: NA Letter or A4 (16-28 lb/60-105 gm bond paper) Documents shall be placed facedown on ADF stacker.
  • Page 19 Same as above Note: One single sheet should be loaded on the manual paper feeder for one occasion. For best results use Oki Data recommended papers 1) Xerox 4200 (20 - lb/75 gm base weight paper) 2) L-type paper for photo-printers...
  • Page 20 0.25 6.35 0.25 6.35 0.25 6.35 0.25 6.35 0.25 6.35 0.25 6.35 The fax can discharge printed copies and stack them faceup. Copy stacking Maximum sheets on the copy stacker: 30* Note*: Oki Data recommended paper 20 / 41309401TH Rev.4...
  • Page 21 Table 1.1 (5/11) Basic Performance Specifications Item Specifications Scanning resolution Horizontal: • 300 dot/inch Note 1: In the local copy at standard (STD) resolution the dpi conversion is done from 300 dot/inch to 200 dot/inch. 2: 600 dpi × 15.4 line/mm : Copy is available for OKIOFFICE87.
  • Page 22 “MSG. IN MEMORY”, and the ALARM LED turns on. Minimum scan line time for receiv- 0 ms, when receiving in ECM mode or from an Oki Data facsimile. 5 ms at 15.4 line/mm or 7.7 line/mm and 10 ms at 3.85 line/mm when receiving from a non-Oki Data facsimile or non-ECM mode.
  • Page 23 (2M-byte) Note: ITU-T No.1 sample document is used to count the number of sheets. (MMR/STD/Sender ID : off) Note: OKIFAX4550/OKIOFFICE87 does not back up the message received in memory for the power failure. Overheat protection The heater of the fuser unit is controlled within the predeter- mined temperature range by the thermistor.
  • Page 24 3) PC FaxModem function 4) Location Programing function Note1: This function will be supplied as the OKIFAX 4550 option in case Oki Data can get the approval in respective countries without modifying the optional unit. (Hardware is standard and software is option for Bi-centro interface.)
  • Page 25 Table 1.1 (10/11) Basic Performance Specifications Item Specifications (3) OKIOFFICE87 US/CANADA Versions Typical Power Max. Power Mode Transmit Receive 104W 115W Local copy 141W 157W Standby 5.4W 6.1W (4) OKIOFFICE87 INT’L Versions Typical Power Max. Power Mode Transmit Receive 102W 112W Local copy 143W...
  • Page 26 Table 1.1 (11/11) Basic Performance Specifications Item Specifications 1) AC power cord × 1 Attachment 2) I/D unit × 1 (Already installed) (to the main body) 3) Toner cartridge × 1 4) Tray - Paper 5) Tray - Document 6) Document stacker × 1 7) Line cord ×...

  • Page 27: Reports And Lists

    Reports and Lists Table 1.2 shows Reports and Lists Specifications. The described information for FAX2NET service referes to "FX-046FAX/MFP Product Specification". Note: F +OT: Press FUNCTION and One-touch key Function program setting Technical function setting Table 1.2 (1/2) Reports and Lists Specifications Item Specifications Call-back message...
  • Page 28 Table 1.2 (2/2) Reports and Lists Specifications Item Specifications Telephone directory This directory is printed manually. (REPORT PRINTING + 4) Configuration report This report is printed manually. (REPORT PRINTING + 5) Active memory files This report will be manually or automatically printed out for information of transmission/reception data stored in the memory.

  • Page 29: Message Confirmation

    MESSAGE CONFIRMATION 07/01/2000 08:05 ID=OKI DATE S,R-TIME DISTANT STATION ID MODE PAGES RESULT 07/01 00'20" CALLING 0000 Message Confirmation Report (MCF) 29 / 41309401TH Rev.4...
  • Page 30 MESSAGE CONFIRMATION 07/01/2000 17:05 ID=OKI DATE S,R-TIME DISTANT STATION ID MODE PAGES RESULT 07/01 00'20" B.C. COMP. 60A0 150 km IMAGE in MCF with Memory TX 30 / 41309401TH Rev.4...

  • Page 31: Activity Report

    17:05 ID=OKI TOTAL TIME TX=08:22' RX=17:30' DATE TIME S,R-TIME DISTANT STATION ID MODE PAGES RESULT 06/29 10:00 01'20" OKI FAX 0000 06/29 10:10 01'00" 0485 88 3385 STOP 9080 06/29 10:30 00'20" ODS TAKASAKI 90C1 06/29 12:05 01'20" OKI FAX...
  • Page 32 DATE TIME DISTANT STATION ID MODE PAGES POLL TX 07/02 12:05 POLL RX TRANSMISSION DATE TIME DIDTANT STATION ID MODE PAGES 07/01 20:00 OKI DATA SYSTEMS 07/01 12:03 0273242117 07/01 19:00 ODC TAKASAKI Active Memory Files 32 / 41309401TH Rev.4...
  • Page 33 15) TEL N0.: Up to 20 digits are printed. 16) CALL BACK N0.: Up to 20 digits are printed. 17) FORWARDING N0.: Up to 32 digits are printed for OKIFAX4550 and up to 40 digits for OKIOFFICE87. 18) SERVER TEL N0.: When FAX2NET FUNCTION is set to ON, up to 32 digits are printed for OKIFAX4550 and up to 40 digits for OKIOFFICE87.
  • Page 34 30) 36: CED SEND “ON,” “OFF” are printed. 31) 37: FAX2NET FUNCTION “ON,” “OFF” are printed. 32) 38: TOP FEED “-10MM,” “-9MM,” “ —, “ 0MM,” “+1MM’” — “+9M” 39: BOTTOM FEED “-2MM,” —, “0MM,” “+1MM” —”+10MM” 33) 40: G3/G4 LEARNING “ON,”...
  • Page 35 Report image CONFIGURATION P1 02/14/2000 12:00 ID=ODS FUNCTION LIST 01:MCF (SINGLE-LOC.) 02:MCF (MULTI-LOC.) 03:ERR.REPORT (MCF) 04:IMAGE IN MCF 05:SENDER ID. 06:MONITOR VOLUME 07:BUZZER VOLUME 08:CLOSED NETWORK 09:TX MODE DEFAULT MIDDLE STD/NORMAL 10:T/F TIMER PRG. 11:RING RESPONSE 12:DISTINCTIVE RING 35SEC 1 RING 13:PAPER SIZE 14:USER LANGUAGE 15:INCOMING RING...
  • Page 36 CONFIGURATION P2 02/14/2000 12:00 ID=ODS DIAL PARAMETER REDIAL TRIES 3 TRY REDIAL INTERVAL 3 MIN DIAL TONE DETECT BUSY TONE DETECT MF(TONE)/DP(PULSE) PULSE DIAL RATE 10 PPS PULSE MAKE RATIO PULSE DIAL TYPE MF(TONE) DURATION 100MS PBX LINE PBX TYPE NORMAL AUTO START DIAL PREFIX...
  • Page 37 CONFIGURATION P3 02/14/2000 12:00 ID=ODS FUNCTION LIST 01:SERVICE BIT 02:MONITOR CONT. 03:COUNTRY CODE 04:TIME/DATE PRINT 05:TSI PRINT 06:TAD MODE TYPE2 07:REAL TIME DIAL 08:TEL/FAX SWITCH 09:MDY/DMY TYPE2 10:LONG DOC. SCAN 11:TONE FOR ECHO 12:MH ONLY 13:H/MODEM RATE 14:T1(TX) TIMER VALUE 15:T1(RX) TIMER VALUE 33.6K 16:T2 TIMER VALUE...
  • Page 38 Telephone Directory Print conditions Formats of OKIFAX4550, and OKIOFFICE87 shall be made common. OKIFAX4550 OKIOFFICE87 Number of OTs Number of ADs Number of groups Maximum number of digits of OT/AD Tel No. Maximum number of digits of OT OR Tel No.
  • Page 39 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 OKIFAX4550 Telephone Directory (1/3) 39 / 41309401TH Rev.4...
  • Page 40 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 OKIFAX4550 Telephone Directory (2/3) 40 / 41309401TH Rev.4...
  • Page 41 GROUP NUMBER = #1 #2 #3 #4 #5 <#1 ONE TOUCH> <#1 AUTO DIAL> <#2 ONE TOUCH> <#2 AUTO DIAL> <#3 ONE TOUCH> <#3 AUTO DIAL> <#4 ONE TOUCH> <#4 AUTO DIAL> <#5 ONE TOUCH> <#5 AUTO DIAL> OKIFAX4550 Telephone Directory (3/3) 41 / 41309401TH Rev.4...
  • Page 42 OKIOFFICE87 TELEPHONE DIRECTORY P1 02/14/2000 12:00 ID=ODS LOCATION ID TEL NO. G3-ECHO/G3-RATE/MODE ONE TOUCH 1 ABCDEFGHIJKLMNO 12345678901234567890123456789012 / 33.6K / G4 12345678901234567890123456789012 2 OT2 123456789012345678901234567890 OFF / 9.6K / G3 3 OT3 12345678901234567890 / 33.6K / G4 4 OT4 12345678901234567890 / 33.6K / G4 5 OT5 12345678901234567890...
  • Page 43 TELEPHONE DIRECTORY P2 02/14/2000 12:00 ID=ODS LOCATION ID TEL NO. G3-ECHO/G3-RATE/MODE AUTO DIAL 46 AD46 12345678901234567890123456789012 / 33.6K / G4 47 AD47 123456789012345678901234567890 / 33.6K / G4 48 AD48 12345678901234567890 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4 / 33.6K / G4...
  • Page 44 TELEPHONE DIRECTORY P3 02/14/2000 12:00 ID=ODS GROUP NUMBER = #1 #2 #3 #4 #5 <#1 ONE TOUCH> <#1 AUTO DIAL> 99 100 <#2 ONE TOUCH> <#2 AUTO DIAL> <#3 ONE TOUCH> <#3 AUTO DIAL> <#4 ONE TOUCH> <#4 AUTO DIAL> <#5 ONE TOUCH>...
  • Page 45 G3 Protocol Dump Image PROTOCOL DUMP P1 12/24/1998 19:00 ID=OKI TAKASAKI DATE TIME S,R-TIME DISTANT STATION ID MODE PAGES RESULT 12/24 18:56 00'33" 123456789012345678901234 0000 PPS_MPS PPS_EOP TRANSMITTED FRAME 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...
  • Page 46 PROTOCOL DUMP P2 12/24/1998 19:00 ID=OKI TAKASAKI RECEIVED FRAME FF C8 01 00 73 17 22 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...

  • Page 47: Broadcast Entry Report

    51=AD51 52=AD52 53=AD53 54=AD54 55=AD55 56=AD56 57=AD57 58=AD58 59=AD59 60=AD60 61=AD61 62=AD62 63=AD63 64=AD64 65=AD65 66=AD66 67=AD67 68=AD68 69=AD69 70=AD70 KEY PAD 12345678901234567890123456789012 123456789012345678901234567890 1234567890123456789012345678 12345678901234567890123456 123456789012345678901234 1234567890123456789012 12345678901234567890 123456789012345678 1234567890123456 12345678901234 OKIFAX4550 Broadcast Entry Report 47 / 41309401TH Rev.4...
  • Page 48 Report Image (OKIOFFICE87) BROADCAST ENTRY REPORT 02/14/2000 12:00 ID=ODS LOCATION ID LOCATION ID ONE TOUCH 1=12345678901234567890123456789012 2=12345678901234567890123456789012 3=OKI DATA CORP. 4=s-ishika@okidata.co.jp 5=timomo@alles.or.jp 6=0273265978 7=0273261447 10=0273265980 AUTO DIAL 01=12345678901234567890123456789012 02=12345678901234567890123456789012 03=ODS 04=OKI DATA SYSTEM 05=AD05 06=AD06 07=AD07 08=AD08 09=AD09 10=AD10 11=AD11...

  • Page 49: Broadcast Confirmation Report

    BROADCAST CONFIRMATION REPORT 07/01/2000 17:05 ID=OKI PAGES = 01 START TIME = 07/01 10:00 TOTAL TIME = 00:02'30" LOCATION ID PAGES RESULT LOCATION ID PAGES RESULT ONE TOUCH 1 = HEAD OFFICE 2 = OT2 3 = OT3 4 = OT4...

  • Page 50: Power Outage Report

    S,R-TIME DISTANT STATION ID MODE PAGES RESULT 06/30 10:10 0485-88-3385 LOST 9080 06/30 10:30 ODS TAKASAKI LOST 0000 06/30 12:05 01'20" OKI FAX CONF=01 LOST 0000 06/30 13:00 00'20" 03-5476-4300 LOST 0000 06/30 10:50 01'20" 0495-22-5400 LOST 0000 06/30 15:00 B.C.

  • Page 51: Confidential Rx Report

    CONFIDENTIAL RX REPORT 07/01/2000 17:05 ID=OKI DATE TIME S,R-TIME DISTANT STATION ID MODE PAGES RESULT 07/01 17:00 00'00" CONF=01 0000 Confidential RX Report 51 / 41309401TH Rev.4...
  • Page 52 OKI SHIBAURA → OKI HONJO 07/01/2000 09:24 NO.002 PLEASE CALL BACK SHIBAURA 03 5476 1234 Call Back Message 52 / 41309401TH Rev.4...
  • Page 53 • Image processor LSI RAM check • Setting DEFAULT TYPE and reading clock at self diagnosis execution. The following printing differs depending on the machine type of OKIFAX4550/OKIOFFICE87 and on the condition of option provided or not. “4M” is printed for OKIFAX4550 and “6M” for OKIOFFICE87.
  • Page 54 LANGUAGE VERSION aaaa HASH hhhh DEFAULT VERSION aaaa HASH hhhh RAM1 RAM2 DEFAULT TYPE 03/03/2000 12:00 DEVICE ID MFG:OKI DATA CORP; MDL:FX-046FAX; DES:OKI FX-046FAX; OPT-RAM ISDN BOARD CPU-ROM VERSION aaaa HASH hhhh CPU-RAM PROGRAM VERSION aaaa HASH hhhh DPRAM 54 / 41309401TH Rev.4...
  • Page 55 Protocol Dump The printing image is as follows: PROTOCOL DUMP P1 08/25/2000 19:00 ID=OKI TAKASAKI DATA TIME S,R-TIME DISTANT STATION ID MODE PAGES RESULT 04/19 14:49 00’07" OKI SHIBAURA(6412) TX-G4 0000 Dch. SETUP CONN-ACK +Bch+ DISC REL-C STATUS SETUP-ACK CONN +Bch+ Bch.
  • Page 56 PROTOCOL DUMP P2 CR/CN 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 CA/CC 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...

  • Page 57: Installation Procedure

    INSTALLATION PROCEDURE Setup Information 2.1.1 General The following flowchart outlines the installation procedure. (See 2.1.2) Site selection (See 2.1.3) Unpacking (See 2.1.4) Check of contents (See 2.1.5) Installation of attachments (See 2.1.6) AC cord connection (See 2.1.7) Telephone and line connections (See 2.1.8) Packing for shipment (See 2.2.1.1)
  • Page 58 (See 2.2.1.7) Dual access operations System data programming (See 2.2.1.8) TSI/sender ID included. One-touch key programming Two-digit auto dial programming Group setting (See 2.2.1.9) Dial parameter settings Programming mail box password Memory operations (See 2.2.1.10) Off-line tests (See 2.2.1.11) On-line tests * : See user's guide 58 / 41309401TH Rev.4...

  • Page 59: Site Selection

    2.1.2 Site Selection INSTALLATION Precautions for Installation (1) Fluctuation in line voltage • 120VAC (102V to 127V) • 230VAC (198V to 264V) (2) Room temperature 50 to 90°F (10 to 32°C) (3) Humidity 20 to 80% RH (4) Operating environment Pressure: Equivalent to altitude of 2500 m and below.
  • Page 60 11.81" 19.69" (300mm) (500mm) In case of scanning length (Max. 14 inches: 356mm) Note: This space is necessary for having the telephone set. (page 62) This space is necessary for installing the document stacker. This space is necessary for ventilation. (7) Levelness of installation surface 1 degree max.

  • Page 61: Unpacking

    2.1.3 Unpacking Procedure (1) Remove tape on the top of the carton box and open its cover. External carton box Packing tape Packing tape Carton label Figure 2.1 (1/2) Unpacking Procedure (2) Take out the accessory box from the carton box. (See Figure 2.1) (3) Take out the machine with plastic wrapper from the box.
  • Page 62 Accessories box Right cushion assembly Left cushion assembly (Top) (Top) Front Fixed tape Machine Left cushion assembly (Bottom) Polyethylene film Right cushion assembly (Bottom) External carton box Figure 2.1 (2/2) Unpacking Procedure 62 / 41309401TH Rev.4...

  • Page 63: Identification Contents

    After having taken out the machine and accompanied accessories from the carton box, check the contents according to the following list: Table 2.1 Contents List Item No. Name Q'ty Remarks OKIFAX4550/ OKIOFFICE87 AC power cord I/D unit Already installed. Toner cartridge Line cord One touch sheet Already installed.

  • Page 64: Installation Of Attachments

    2.1.5 Installation of Attachments (1) Items • Image Drum (ID) Unit (already installed) • Toner cartridge • Recording paper • Tray-paper, Tray-document and Document-stacker (2) Procedure Toner cartridge • Peel off the fixed tape attached to the cover-top. • Open the cover-top. Cover-Top Figure 2.2 Toner Cartridge Installation (1) •...
  • Page 65 • Take out the toner cartridge from the damp proof bag, shake it five or six times as shown in the illustration to eliminate the toner deflection, and peel off the seal gently. Seal Toner cartridge Figure 2.2 Toner Cartridge Installation (3) •...
  • Page 66 • Push the gray tab forward until it stops. Toner cartrige Gray tab Figure 2.2 Toner Cartridge Installation (5) • Clean the toner scattered in the vicinity of the toner cartridge using a cloth moistened with cold water. Do not use hot water since it makes the toner stick there. •...
  • Page 67 (3) Recording paper Note: About 100 sheets of the new paper can be set on the tray-paper. Loading the new paper. Sheets must not exceed 100 sheets of the new paper on the tray-paper. If excessive sheets are set, it will cause paper jams. Tray-paper New paper (print-side down): 100 sheets Figure 2.3 Recording Paper Cassette Installation...
  • Page 68 (4) Tray-paper, Tray-document and Document-stacker • Hang the tray-paper, the tray-document and the stacker-document onto hanging position. Tray-paper Tray-document Cover-top Stacker-document Figure 2.4 Document Stacker Installation 68 / 41309401TH Rev.4...

  • Page 69: Ac Cord Connection

    2.1.6 AC Cord Connection The power supply is provided as follows. Nominal input voltage 120VAC (Voltage range 102 to 127VAC) Nominal input voltage 230VAC (Voltage range 198 to 250VAC) Check whether the AC voltage of your input is within the above-mentioned voltage range and if so, check that the power switch is turned OFF.

  • Page 70: Telephone And Line Connections

    Figure 2.5 Telephone and Line Connections 2.1.8 Packing for Shipment CAUTION: When packing the OKIFAX4550/OKIOFFICE87 series for shipment, REMOVE THE IMAGE DRUM AND TONER FROM THE UNIT AND SHIP SEPARATELY! Failure to do this will result in damage to the machine.

  • Page 71: Programming And Initial Settings

    Programming and Initial Settings 2.2.1 Initial Settings 2.2.1.1 General Procedure of Key Operation Figure 2.6 shows the general procedure of key operation. (STANDBY MODE) (Press the SELECT FUNCTION key.) COPY COPY X2 SELECT FUNCTION (OT) Selection by One-touch key To technical program [Prg.
  • Page 72 Powered on while holding the 01: MCF. (SIGNLE-LOC.) SELECT FUNCTION key down. 02: MCF. (MULTI-LOC.) 03: ERR. REPORT (MCF.) *4 04: IMAGE IN MCF. Selection by YES/NO keys or digit (1 to 8) 05: SENDER ID 06: MONITOR VOLUME OT9: USER PROGRAMMING 07: BUZZER VOLUME 08: CLOSED NETWORK 09: TX MODE DEFAULT...
  • Page 73 Powered on while holding the COPY key down. Selection by YES/NO keys or digit (1 to 5) TECHINICAL PROGRAMMING Selection by YES/NO keys or digit (1 to 8) 1: SELF DIAGNOSIS 1: LOCAL TEST 2: SENSOR CALIBRATION 9: LOOP BACK 1 3: LED TEST 10: LOOP BACK 2 4: TONE SEND TEST...
  • Page 74 Note: When the machine is in POWER SAVE MODE, the machine returns to standby mode by pressing the START key. *1: In case of Germany, Austria and Switzerland version, ACTIVITY REPORT message does not appear on the LCD display. *2: User can read no. of counter in LCD but can not clear. *3: User can not select in some countries.

  • Page 75: Technical Functions

    2.2.1.2 Technical Functions T.F. This section explains setting items generally conducted by service personnel, not by users. Item Specifications Default Table 2.2 shows the initial setting items and their purposes. (The default setting is different by the individual countries.) Each item can be accessed by entering the corresponding service number on Technical Function.
  • Page 76 Table 2.2 (1/8) Service Personnel Initial Settings T.F. Item Specifications Default Switching serviceman/user operation. Service bit ON : Service personnel’s features are available. OFF : Service personnel’s features are not avail- able. To enable or disable the following functions: • Drum (Total, Print, Scan), and toner counter clear •...
  • Page 77 Table 2.2 (2/8) Service Personnel Initial Settings T.F. Item Specifications Default TAD mode Switches an automatic voice message response (For external telephone to the calling station. answering device.) TAD mode is of three types (TYPE1/TYPE2/ TYPE3). OFF/TYPE1/TYPE2/TYPE3 selectable. TYPE1 means: 1.
  • Page 78 Table 2.2 (3/8) Service Personnel Initial Settings T.F. Item Specifications Default MDY/DMY Switches LCD display and report print from month/day/year to day/month/year or vice versa. MDY/DMY selectable. Long document SCAN Switches the function of transmitting long-size document (more than 360 mm). ON : 1500 mm or 60 min.
  • Page 79 Table 2.2 (4/8) Service Personnel Initial Settings T.F. Item Specifications Default T2, timeout value (layer) T2, timeout value Registers the time duration (in seconds) for which the receiving fax detects the EOL (End Of Line) signal during phase C. The fax will discon- nect the line when EOL cannot be detected within T2.
  • Page 80 Table 2.2 (5/8) Service Personnel Initial Settings T.F. Item Specifications Default 0 to 15 dB. selectable (except FRE) 7 to 15 dB, selectable (FRE) At country code = CHN, set the actual set value +2dB. Note: The send signal power level should meet your country’s regulation.
  • Page 81 Disables NSF signal Note: When NSF switch = OFF, the fax opera- tion is shown as below. • When transmitting, even if OKI NSF signal is detected from the remote machine, the fax transmits DCS signal (The fax does not trans- mit NSC signal.)
  • Page 82 Table 2.2 (7/8) Service Personnel Initial Settings T.F. Item Specifications Default ID/TSI priority Selects ID/TSI printing in the distant station ID column of the report. Prints NSF signal with personal ID. TSI: Prints TSI signal without NSF. Set to ID Set to TSI Priority Personal ID...
  • Page 83 Table 2.2 (8/8) Service Personnel Initial Settings T.F. Item Specifications Default Fax2Net Function Set up whether to make Fax2Net service. Enable OFF: Disable * The following Fax2Net service can use only when Fax2Net function is set to ON. Web Retrieval/Broadcasting/Prepaid Regis- tration Top Feed Adjusts read start position of various machines.
  • Page 84 Table 2.3 (1/2) Technical Default Setting 84 / 41309401TH Rev.4...
  • Page 85 Table 2.3 (2/2) Technical Default Setting 85 / 41309401TH Rev.4...
  • Page 86 TEL/FAX automatic switching This function is used for the purpose of TEL/FAX automatic switching as follows. (1) If the machine detects a call with a CNG signal indicating an auto send facsimile call, it starts an automatic document receiving operation. (2) If machine detects a call without a CNG signal, machine generates the buzzer sounds as a telephone call.
  • Page 87 Switch Over Time (20/35 sec) LIFT HANDSET Load document NSF, CSI, DIS Press START AUTO REC. START Button OKI TOKYO RECEIVING G3/33.6K Manual Transmission CML"OFF" 1 sec 1 sec 3.2 sec To detect CNG signal Note *1: Ring Back Tone — 1 sec. ON, 3.2 sec. OFF *2: When you want to talk by phone, pick up handset.
  • Page 88 TAD mode TAD: Telephone Answering Device TAD can be connected to external telephone terminal to record your messages. TAD records your speech and switches an automatic voice message response to the calling station. Note 1: A choice of TAD mode is available by Technical Function No. 06. The predetermined time is selectable between 20 or 35 sec.
  • Page 89 • TAD mode flow chart In case of TYPE 2: If the fax does not detect CNG signal during working of TAD, the machine will go to standby mode. In case of TYPE 3: The fax does not detect CNG signal during 15 seconds from TAD operation starting. The fax starts CNG signal detection after 15 seconds from TAD operation.

  • Page 90: Technical Functions Example

    2.2.1.3 Technical Functions Example Note: The fonts displayed on the LCD operation panel may differ from the fonts written this manual. (1) Service Bit Setting Purpose To enable or disable the following functions: • Drum and toner counter display (clear) •...
  • Page 91 (2) Technical functions Operations: The display shows: 14:14 FAX (Standby) Press SELECT FUNCTION key. FUNCTION SELECT FUNCTION (OT) MEMORY AVAIL.=100% COPY Press COPY key twice. COPY TECH. PROGRAMMING YES(←/1-5) NO(→) ← ← Press key. 1:LOCAL TEST YES(←) NO(→/1-6) → Press key.
  • Page 92 Table 2.4 (1/6) Technial Functions T.F. Name of Function The Display Shows Service bit → 01:SERVICE BIT Setting (Toggle) [ X ] YES(←) NO(→) → ← X: OFF Line monitor control → 02:MONITOR CONT. Setting (Toggle) [ X ] YES(←) NO(→) →...
  • Page 93 Table 2.4 (2/6) Technial Functions T.F. Name of Function The Display Shows Tone for echo → 11:TONE FOR ECHO (echo protection) Setting (Toggle) [ X ] YES(←) NO(→) → ← X: OFF MH only → 12:MH ONLY Setting (Toggle) [ X ] YES(←) NO(→) →...
  • Page 94 Table 2.4 (3/6) Technial Functions T.F. Name of Function The Display Shows T2, timeout value 16:T2 TIMER *100MS [ X ] YES(←) NO(→) To 17: DIS BIT32 → X: 001 - 255 16:T2 TIMER *100MS ] ENTER 001-255 — 3-digit timer entered. →...
  • Page 95 Table 2.4 (4/6) Technial Functions T.F. Name of Function The Display Shows MF attenuator → 23:MF ATT. Setting [ X ] YES(←) NO(→) → → X:0 DB 1 DB → → → → 2 DB 15 DB 0 DB Ring duration detection time 24:RING DURA.
  • Page 96 Table 2.4 (5/6) Technial Functions T.F. Name of Function The Display Shows Media type → 27:MEDIA TYPE Setting [ X ] YES(←) NO(→) → → X: M Transfer roller clatch current → 28:TR LATCH CURRENT Setting [ X ] YES(←) NO(→) →...
  • Page 97 Table 2.4 (6/6) Technial Functions T.F. Name of Function The Display Shows Top feed → 38:TOP FEED Setting [ X ] YES(←) NO(→) → → → → → → Bottom feed → 39:BOTTOM FEED Setting [ X ] YES(←) NO(→) →...
  • Page 98 Table 2.5 G3 Fallback Object Service Code List (If G4 TX is faulty) Classification Code Description Remarks Dch layer 3 BA01 Unallocated (unassigned) number BA02 No route to specified transit network BA03 No route to destination BA06 Channel unacceptable BA07 Call awarded and being delivered in an established channel BA10 Procedure sequence error, Line disconnected during in-band procedure...

  • Page 99: User's Functions

    2.2.1.4 User’s Functions This section explains the items usually set up by general users. Table 2.6 shows the initial setting items and their purposes. Each F.P.can be accessed by entering the corresponding function number on Function Program- ming. The detailed procedure of the initial setting items will be explained on the following pages. Note: S-ON: Effective if the service bit has been set on.
  • Page 100 1) One-touch dial 10 one-touch keys are provided. (OKIFAX4550/ OKIOFFICE87) Max. 32 digits for each location number for OKIFAX4550. Max. 40 digits for each location number for OKIOFFICE87. In addition to an ordinary location number, another alternate location number can be registered in to each one-touch key.
  • Page 101 2) Two/Three-digit dial 70 different codes are provided. (OKIFAX4550) 100 different codes are provided. (OKIOFFICE87) * Two- digit location code: 01 to 70 (OKIFAX4550) * Two-digit or max. three-digit location code: 01 to 99, 100 (OKIOFFICE87) 101 /...
  • Page 102 Table 2.6 (3/7) User's Functions Item Specifications Max. 32 digits for each location number for OKIOFFICE87. Max. 40 digits for each location number for OKIOFFICE87. Note 1: If a telephone number is registered, data can be registered without registering ID and communication parameters.
  • Page 103 In addition to fax numbers, an alpha/ numeric name can be Telephone directory and location assigned to each of one-touch keys and two/three-digit dial codes, 01 to 70, for OKIFAX4550 and 01 to 99, 100 for (Alpha search) OKIOFFICE87. Any location ID can be searched and displayed on LCD.
  • Page 104 One single sheet from the feeder below the paper exit can be copied. Example of sheets:Transparency for an overhead projector Broadcast Max. 90 (OKIFAX4550), Max. 120 (OKIOFFICE87) remote (Memory transmission) locations can be specified by the following means: • One-touch keys (with of without a group list).
  • Page 105 Table 2.6 (6/7) User's Functions Item Specifications No toner reception The fax can temporarily store received messages in memory when toner has run out. The messages are printed when toner has been newly supplied or an operator presses the SELECT FUNCTION key followed by the one-touch key No. 2 under the LCD message “PRINT MEMORY MSG.”...

  • Page 106: Specifications

    Table 2.6 (7/7) User's Functions Item Specifications Dual Access Combination Table PC1 ON 2'nd 1'st Standby ON HOOK During FAX Calling During RING RESPONSE Call Reception During detection of TEL/FAX During TAD detection 1st Phase B Calling ~ Transmission Feeder TX Transmission after scanning During Scanning Memory TX...
  • Page 107 User's Initial Settings Note: The fonts displayed on the LCD operation panel may differ from fonts written this manual. 2)-1 One Touch Key Operations Restrict Access = ON ID NG 1 4 : 1 4 F A X POWER ON E N T E R I D →...
  • Page 108 (OKIFAX4550)/100 (OKIOFFICE87) is not assigned, relay broadcast report is not transmitted. When it is assigned, relay report is transmitted to fax number assigned to auto dial code 70, for OKIFAX4550 or to auto dial code 100 for OKIOFFICE87. Polling transmission/reception...
  • Page 109 Table 2.7 (2/6) User's Initial Settings (One-touch key Program) F+OT Item Specifications Report printing The report print in 6 items are as follows: 1. Activity report 2. Broadcast message confirmation report (Multi location) 3. Activity memory files report 4. Phone directory report 5.
  • Page 110 (alphabetic, numeric and symbolic). (4) 10 one-touch keys are provided. 2. Two-digit or max. three-digit Auto-dial No. 01 to 70 for OKIFAX4550, No. 01 to 99, 100 for auto dial program OKIOFFICE87 allows registering telephone number in 32 digits (numeral, -, P and space) for OKIFAX4550 and 40 digits for OKIOFFICE87 and ID for the telephone directory maximum 15 characters (alphabetic, numeric and symbolic).
  • Page 111 1) Number of forwarding for incoming call destination that can be specified. OKIFAX 4550/OKIOFFICE87: 1 2) Number of characters used to specify a destination. 32 characters (numeral, -, P and Space) for OKIFAX4550 and 40 characters for OKIOFFICE87. 111 / 41309401TH Rev.4...
  • Page 112 1) FAX 2NET server telephone number: Telephone number of the FAX2NET server to be used (Max 32 digits for OKIFAX4550 and Max. 40 digits for OKIOFFICE87). 2) Account number: ID particular to terminal registered in FAX2NET service.
  • Page 113 Table 2.7 (5/6) User's Initial Settings (One-touch key Program) F+OT Item Specifications 11. ISDN programming Sets to Country code, ISDN No. (subscriber number), ISDN ID (subscriber code) and ISDN sub address. 1) Setting values This setting consists of the following: •...
  • Page 114 2)-2 Function Program Table 2.8 (1/6) User's Initial Settings (Function Program) P.F. Item Specifications Default Message confirmation report Enables or disables the automatic message (Single location) confirmation report printing after a single loca- tion call. Printing the MCF report. OFF: Disables this function. Message confirmation report Enables or disables the automatic message (Multiple locations)
  • Page 115 Table 2.8 (2/6) User's Initial Settings (Function Program) P.F. Item Specifications Default Closed network The fax compares lower four digits of TSI/CSI received from remote station with fax numbers registered locally for one-touch dial and two-digits autodial. If unmatched, the communication will be auto- matically disconnected.
  • Page 116 Table 2.8 (3/6) User's Initial Settings (Function Program) P.F. Item Specifications Default User language A choice of 2 languages for LCD and print mes- sage are available. GER, FRE etc. are displayed insted of OTHER. ENGLI/OTHER selectable. Incoming ring Instead of ringer circuit, software can control built- in speaker to ring sound.
  • Page 117 Table 2.8 (4/6) User's Initial Settings (Function Program) P.F. Item Specifications Default PC/FAX switch To enable or disable PC interface function. When PC reception is not available, for example, application is not activated on the PC or cable is missing between PC and fax etc., this setting allows to switch from PC to fax reception auto- matically.
  • Page 118 Table 2.8 (5/6) User's Initial Settings (Function Program) P.F. Item Specifications Default Width Reduction This function can print characters written at the edges of a document. Switches the reduction of the horizontal scanning direction. ON: Reduction printing (216 mm to 203 mm) Reduction rate is shown as below.
  • Page 119 Table 2.8 (6/6) User's Initial Settings (Function Program) P.F. Item Specifications Default Speech Receive Determine whether the incoming call is answered when the information transmission capacity instracted by the network is voice transmission. 1) Setting values ON(Answered)/OFF(Not answered) • This setting cannot be made when G4 op- tion board is not provided.
  • Page 120 Table 2.9 (1/2) User Default Setting 120 / 41309401TH Rev.4...
  • Page 121 Table 2.9 (2/2) User Default Setting 121 / 41309401TH Rev.4...

  • Page 122: User's Functions Example

    2.2.1.5 User's Functions Example Note : The fonts displayed on the LCD operation panel may differ from fonts written this manual. Function Program Operations: The display shows: To bring the LCD up to the desired mes- 1:FUNC. PROGRAMMING sage, press SELECT FUNCTION key ←...
  • Page 123 Table 2.10 (1/4) User's Functions Tap No. Name of Function The Display Shows → Message 01:MCF(SINGLE-LOC.) Setting (Toggle) confirmation report → ← X: OFF ← → ] YES( ) NO( (Single location) → Message 02:MCF (MULTI-LOC.) Setting (Toggle) confirmation report →...
  • Page 124 Table 2.10 (2/4) User's Functions Tap No. Name of Function The Display Shows → Note 3 Paper size 13:PAPER SIZE Setting ← → ] YES( ) NO( → → → X: A4 LGL 13 LGL 14 ← ← ← JISB5 EXEC.
  • Page 125 Table 2.10 (3/4) User's Functions Tap No. Name of Function The Display Shows → No toner memory 22:NO TONER MEM. RX Setting (Toggle) reception ← → ] YES( ) NO( → ← X: OFF → Memory full save 23:MEM FULL SAVE Setting (Toggle) ←...
  • Page 126 Table 2.10 (4/4) User's Functions Tap No. Name of Function The Display Shows Note 5 → Speech receive 31:SPEECH RECEIVE Setting (Toggle) ← → ] YES( ) NO( → ← X: OFF Note 6 → USB Conv. mode 32:USB CONV. MODE Setting (Toggle) USB: Universal ←...
  • Page 127 Note 1: RESOLUTION & ORIGINAL of Tx mode defult setting can be selected by using → key. STD / NORMAL STD / DARK STD / LIGHT FINE / NORMAL EX. FINE / NORMAL FINE / LIGHT FINE / DARK EX. FINE / DARK EX.FINE / LIGHT PHOTO / NORMAL PHOTO / DARK...
  • Page 128 Ring response time Before specifying the ring response time, set the service bit on following the operations shown in 2.2 (1/8). (Service Bit Setting). Operations: The display shows: To bring the LCD up to the desired SELECT FUNCTION (OT) message, press SELECT FUNCTION MEMORY AVAIL.=100% key once and one-touch key No.
  • Page 129 Dial parameters (In case the service bit is "OFF".) To get the "DIAL PARAMETER" message on the display, perform the same operetion as Table 2.11.(Dial parammeters settings) 2:DIAL PARAMETER ← → YES( /1-9*#) ← REDIAL TRIES Available for USA, INT'L, NOR, SWE, FIN. GER, HUN, ←...
  • Page 130 The following table can be set depending on the National codes even if the service bit is "off". Table 2.11 Dial parameters setting if the service bit "OFF" NATIONAL CODE USA INT'L GBR IRL NOR SWE FIN DEN GER HUN TCH POL Redial tries Redial interval Dial tone detect...

  • Page 131: Clock Adjustment

    2.2.1.6 Clock Adjustment Operations: The display shows: To bring the LCD up to the desired message, SELECT FUNCTION (OT) press SELECT FUNCTION key once and MEMORY AVAIL.=100% one-touch key No. 9 in the standby mode. (In case of no message in memory) Press OT9 Enter 3 using the ten-key pad.

  • Page 132: Dual Access Operation

    2.2.1.7 Dual Access Operation OKI TOKYO OKI TOKYO OKI TOKYO SENDING /144 RECEIVING/144 MEMORY-RX/144 Set documents during memory TX Set documents Set documents or set documents during feeder TX after the end of the pre-scanning RELOAD DOCUMENT Pre-feed error SELECT LOCATION...

  • Page 133: System Data Programming

    2.2.1.8 System Data Programming • TSI/CSI (Defalut: Blank) • Registration of sender ID (Defalut: Blank) • Registration of telephone number for the call-back message (Defalut: Blank) Operations: The display shows: To bring the LCD up to the desired SELECT FUNCTION (OT) message, press SELECT FUNCTION MEMORY AVAIL.=100% key once and one-touch key No.
  • Page 134 Operations: The display shows: Continued from the previous page. NO=03 3404 7123 ID=OKI (Example) Press START key. START NO=<CALL BACK NO.> 3 SEC LATER NO=_ 03..5 NO=03 3404 7765_ (Example) START Press key. START 134 / 41309401TH Rev.4...

  • Page 135: Dial Parameters Settings

    2.2.1.9 Dial Parameters Settings (1) Procedure The following shows the case in which the service bit is on. Operations: The display shows: To bring the LCD up to the desired message, SELECT FUNCTION (OT) press SELECT FUNCTION key once and MEMORY AVAIL.=100% one-touch key No.
  • Page 136 The display shows: Continued from the previous page. 2:DIAL PARAMETER ← → YES( /1-9*#) ← (1) Redial time REDIAL TRIES "0 TRY" to "10 TRY", ← → [2 TRY] YES( ) NO( "1 TRY" to "5 TRY" (country code=FRE) ← →...
  • Page 137 Table 2.12 Default Settings of Dial Parameters 137 / 41309401TH Rev.4...
  • Page 138 Table 2.13 Dial Parameters Settings Item Specifications Dial parameters Redial tries Switches on the re-dial times to meet the regulations of the installed country. 0 to 10 tries (in one-try steps) 1 to 5 tries for FRE. Redial interval Switches on the re-dial intervals to meet the regulations of installed country.

  • Page 139: Off-Line Tests

    2.2.1.10 Off-line Tests (1) Purpose Activate self-diagnosis which includes: • Print test • CPU-ROM version printing • CPU-RAM check • PROG version printing • LANGUAGE version printing • DEFAULT version printing • RAM check • RAM check (memory board: optional) (2) Procedure Operations: The display shows:...
  • Page 140 LANGUAGE VERSION aaaa HASH hhhh DEFAULT VERSION aaaa HASH hhhh RAM1 RAM2 DEFAULT TYPE 03/03/2000 12:00 DEVICE ID MFG:OKI DATA CORP; MDL:FX-046FAX; DES:OKI FX-046FAX; OPT-RAM ISDN BOARD CPU-ROM VERSION aaaa HASH hhhh CPU-RAM PROGRAM VERSION aaaa HASH hhhh DPRAM Figure 2.7 Printed Data of Self-diagnosis Print Test (Example)

  • Page 141: On-Line Tests

    2.2.1.11 On-line Tests Transmission (1) Load documents (2) Make sure that • The loaded documents are fed in automatically. • The STD and NORMAL lamps light. • The display shows SELECT LOCATION. (3) Dial the telephone number of the remote machine by the ten-key pad. (4) Make sure that the telephone number of the remote machine is shown on the display.
  • Page 142 X X : X X X X X (STANDBY CONDITION) (• LOAD DOCUMENT(S), SELECT RESOLUTION MODE) AUTO DIALING? Manual TX WHICH MODE? ONE-TOUCH TWO-DIGIT AUTO DIAL CODE • ONE-TOUCH KEY • PRESS "AUTO DIAL" KEY (e.g. No. 1) • SET THE CODE (e.g. 01) O K I T A K A S A K I 0 2 7 3 5 6 7 8 9 0 O K I T A K A S A K I...
  • Page 143 X X : X X X X X (← STANDBY CONDITION) MANUAL RECEIVE MODE • OFF-HOOK AND CONVERSATION • PRESS "START" KEY AUTO RECEIVE MODE? (• RINGING DETECTED) A U T O R E C . S T A R T M A N U A L R X S T A R T TSI &...

  • Page 144: Brief Technical Description

    BRIEF TECHNICAL DESCRIPTION 144 / 41309401TH Rev.4...

  • Page 145: Fundamentals Of The Electro-Photographic Process

    Fundamentals of the Electro-Photographic Process The electro-photographic process involves six sub-processes: (1) Charging (2) Exposure (3) Development (4) Transfer (5) Fusing (6) Cleaning Outline of each process is explained below. Process Illustration Description The surface of the electro-photo- graphic Image drum is uniformly charged with negative charges by applying a negative voltage to the Power...
  • Page 146 Process Illustration Description The recording paper is placed over the Image drum surface and a positive EP drum charge, opposite in polarity to the toner, is applied to the reverse side of the paper from the transfer roller. The toner is attracted by the positive charge and is transferred to the paper.

  • Page 147: Actual Electo-Photographic Process

    Actual Electo-photographic Process The electro-photographic process consists of six essential processes. The following Figure 3.2 provides a general description. 2 LED head Electro-photographic drum 1 Charge roller Toner 6 Cleaning roller 5 Heater roller 3 Developing roller Recording paper Back-up roller 4 Transfer roller * Process: 1 : Charging...

  • Page 148: Boards And Units

    3.3.1 Boards and Units The following one board, Main control board and three units constitute the facsimile transceiver machine. • Main control board MCNT: (46F: OKIFAX4550, R46: OKIOFFICE87) • Network control unit board NCU: (INU/EN9) • Operation panel assembly unit...
  • Page 149 149 / 41309401TH Rev.4...

  • Page 150: Overall Dimension And Mechanical Structure Of Okifax4550/Okioffice87

    Overall Dimension and Mechanical Structure of OKIFAX4550/OKIOFFICE87 Separation rubber Scanner block Roller - ADF LED head EP drum OPE board Roller - Heater Paper exit ID unit Roller - Scan Document exit Manual paper feeder inlet I mage sensor Printer block Roller - Hopping Figure 3.4 Overall Dimension and Mechanical Structure...

  • Page 151: Mechanical Disassembly And Reassembly

    MECHANICAL DISASSEMBLY AND REASSEMBLY General The section explains the procedures for replacement of parts, assemblies, and units in the field. Only the disassembly procedures are explained here. For reassembly, reverse the disassembly procedure. Precautions for Parts Replacement DANGER Do Not You may be subjected to high-voltage electric shock by touching the following parts without an insulating material: Touch !
  • Page 152 (2) Do not try to disassemble as long as the facsimile is operating normally. (3) Do not remove unnecessary parts: Try to keep disassembly to a minimum. (4) When disassembling, follow the prescribed sequence. Otherwise, parts may be damaged. (5) Since screws and small parts are likely to be lost, they should temporarily be attached to their original positions.

  • Page 153: Tools

    Tools Table 4.1 shows the tools required for the replacement of parts such as circuit boards and mechanical units. Table 4.1 Tools Q'ty Remarks Service tools Philips screw driver (L) Philips screw driver (M) Flat screw drivers (S) Philips screw driver (S) Radio pliers Nippers Multimeter...
  • Page 154 Start Item number for detailed description (4.3.1) (4.3.1) LED Print Head Open the Cover Assembly-Top (4.3.2) ID Unit (4.3.2) (4.3.2) (4.3.2) Cover-Rear Cap-TEL-I/F Cover-Main (4.3.2) (4.3.4) (4.3.4) Board-NCU Open the Frame Separation Rubber Assembly Scanner (U) (4.3.3) (4.3.3) (4.3.3) Open the OPE Printer Unit Bracket-package Panel Assembly...
  • Page 155 Printer Unit Start (4.3.8) Open the Cover ID Unit Assembly-Top (4.3.8) Transfer roller (4.3.2) (4.3.2) (4.3.2) Cover Rear Cap-TEL-I/F Cover Main (4.3.9) (4.3.14) High-voltage Heat Power Supply Assembly (TLHV/OLHV) (4.3.9) Holder Assembly (4.3.17) (4.3.13) Paper Sensor E Drive shaft E Paper Sensor Exit and Eject Roller Toner Sensor Assy.
  • Page 156 Figure 4.2 Appearance of the OKIFAX4550/OKIOFFICE87 156 / 41309401TH Rev.4...

  • Page 157: Led Print Head

    4.3.1 LED Print Head It is used two kind of head as the LED print head. (208 mm width or 216 mm width) (1) Disassembly procedure Open the cover assembly-top by raising. Cover assembly-top Disconnect the PC connector from the LED print head.

  • Page 158: Id Unit, Rear-Cover, Cover-Main, Board-Ncu Or Board-G4N

    4.3.2 ID Unit, Rear-Cover, Cover-Main, Board-NCU or Board-G4N (1) Disassembly procedure Open the cover assembly-top by raising. Take out the ID unit from the equipment. ID unit Cover assembly-top Cover-Rear: Remove the Cover-Rear by remov- ing the screws two and the part of the fixing hooks (4).
  • Page 159 Board-NCU and Board-G4N Remove the Board-NCU or Board-G4N by removing the two screw 3 and disconnect the connector (CN3) from Board-46F or R46. Board-NCU or Board-G4N Screw 3 First, move the center of Guide-paper (L) and (R) of Holder assembly, and then, open the Cover-Main from the rear side.

  • Page 160: Unit-046 Ope-Panel

    4.3.3 Unit-046 OPE-Panel (1) Disassembly procedure First, carry out the disassembly pro- cedure up to the point of the 4.3.2 (Item (e). Cover-main). Cable 2 Dismount the Printer-Unit. OPE panel assembly (See Section 4.3.18) Open the OPE-panel assembly. OPE panel assembly: Remove the OPE panel assembly by Screw 3 removing two screws 3, the eight...

  • Page 161: Separation Rubber, Roller Assembly Sensor

    4.3.4 Separation Rubber, Roller Assembly Sensor (1) Disassembly procedure Separation rubber: The separation rubber can be removed from the Frame Assembly-Scanner (U). Frame Assembly-Scanner (U) Roller Assembly Sensor: Remove the Plate-Support by removing the two screws 1. Note: Just fitting to two bossess. Remove the two springs (L) and (R).

  • Page 162: Roller Assembly-Adf, Cis (Contact Image Sensor), Lever-Pc1 And Pc2

    4.3.5 Roller Assembly-ADF, CIS (contact image sensor), Lever-PC1 and PC2 (1) Disassembly procedure First, carry out the disassembly procedure up to the point of the 4.3.2 and 4.3.3. Dismount the Printer-Unit. (See Section 4.3.18) Remove the Frame assembly-Scanner (L) by removing the four screws 1 and the four connectors.
  • Page 163 Plate Scanner (R) Plate Scanner B Plate Scanner (L) Plate Earth ADF Speaker Roller assembly-ADF Turn the Frame Assembly-Scanner in- side out and perform the disassembly procedure. Roller Assy-ADF Remove the Plate Scanner (L) by re- moving the two screws. Lever PC2 Remove the Speaker.
  • Page 164 Motor-S: Remove the Motor-S by removing the connector of motor and the two screws 1. Connector Motor-S Screw 1 Photo-Sensor (PC1, PC2): After disconnecting the two connec- tors, remove the photo-coupler sen- sors PC1 and PC2 on the Plate Scan- ner B by pressing the latch using the flat screwdriver or like.

  • Page 165: Board-46F, Board-R46 Power Supply Unit, Board Hv-P6L

    4.3.6 Board-46F, Board-R46 Power Supply Unit, Board HV-P6L (1) Disassembly procedure First, carry out the disassembly procedure up to the point of the Screw 4.3.2 (Cover-Rear, Cover-Main etc.). Board-46F or R46: Disconnect the all connectors. Remove the Board-46F or R46 by removing the five screws.

  • Page 166: Printer Unit Section

    4.3.7 Printer Unit Section [Base Frame Unit] LED head Flat cable assy Pressure roller (B) (Back up roller) Heat assy Paper guide (R) Papr guide (L) Resistration roller Transfer Hopper Paper Idle gear heat roller holder spring Side plate M Tension plate Stopper spring...

  • Page 167: Transfer Roller

    4.3.8 Transfer Roller (1) Disassembly procedure Open the cover assembly-top by rais- ing and remove the ID unit. Remove the right claw. Then, dismount transfer roller, two registration bearing, and gear T. Registration bearing Transfer roller Gear T Registration bearing Label (2) Reassembly procedure Reverse the disassembly procedures.

  • Page 168: High-Voltage Power Supply Unit (Hv-P2H)

    4.3.9 High-Voltage Power Supply Unit (HV-P2H) (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover-Rear and Cover-MAIN). Remove three screws 1 then remove Cover- HV and draw out high-voltage power supply board (HV-P2H). Disconnect all the cables 3 and 4 from high- voltage power supply board (HV-P2H) and dis- mount high-voltage power supply board.

  • Page 169: Holder Assembly

    4.3.10 Holder Assembly (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover- Rear and Cover-MAIN). Dismount the Bracket-Package. Dismount the Holder-Paper. Unlock and dismount the Guide- Paper (L) and Guide Paper (R). Remove the claw and dismount Spring-Holder.

  • Page 170: Plate-Side M And Gear-Idle

    4.3.11 Plate-Side M and Gear-Idle (1) Disassembly procedure Perform parts replacement while making the base frame assembly stand so that Plate-Side M will face upward. First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover- Rear and Cover-MAIN). Remove two screws 1 and two claws, then dismount Plate-Side M.

  • Page 171: Registration Roller

    4.3.12 Registration Roller (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover- Rear and Cover-MAIN). Move registration roller to the right and dismount it by lifting. (Two regis- Registration roller tration bearings also come off at the same time.

  • Page 172: Drive Shaft E (Eject) And Eject Roller

    4.3.13 Drive Shaft E (Eject) and Eject Roller (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover-Rear and Cover-MAIN). Remove two screws 1 from Cover Heat Assembly (section 4.3.14), lift the heat assay, and dismount idle gear E (A) and idle gear E (B).

  • Page 173: Heat Assembly

    4.3.14 Heat Assembly This section explains how to dismount the heat assembly and parts in the assembly. (1) Disassembly procedure Screw 1 < Dismounting the heat assembly> First, carry out procedure up to the Heat assembly point of the 4.3.2 (ID Unit, Cover- Screw 1 Rear and Cover-MAIN).

  • Page 174: Pressure Roller B (Back Up Roller)

    4.3.15 Pressure Roller B (Back Up Roller) (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover-Rear and Cover-MAIN). Dismount the high-voltage power sup- ply board. (See Section 4.3.9) Bearing BU Dismount heat assembly. (See section 4.3.14) Dismount the engagement with the Pressure roller B...

  • Page 175: Hopping Shaft Assembly

    4.3.16 Hopping Shaft Assembly (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover-Rear and Cover-MAIN). Dismount the high-voltage power sup- ply board. (See Section 4.3.9) Dismount the paper holder assembly. Knock pin (See Section 4.3.10) Dismount the sheet guide.

  • Page 176: Paper Sensor E, Paper Sensor Exit And Toner Sensor Assembly

    4.3.17 Paper Sensor E, Paper Sensor Exit and Toner Sensor Assembly (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover-Rear and Cover-MAIN). Dismount the high-voltage power sup- ply board. (See Section 4.3.9) Dismount the paper holder assembly.

  • Page 177: Printer Unit

    4.3.18 Printer Unit (1) Disassembly procedure First, carry out procedure up to the point of the 4.3.2 (ID Unit, Cover-Rear and Cover- Main). Remove Bracket-Package with three screws, then disconnect Cable-Flat from connector on 46F or R46-Board (M-CNT). Pull out the Holder-Assy. Dismount the high-voltage power supply board.

  • Page 178: Adjustments

    ADJUSTMENTS Setting of LED Print Head Drive Time • Adjustment point: Technical Function No. 26. * To bring the LCD up to Technical Function, press SELECT FUNCTION key once, COPY key twice and "2" key (In case of no message in memory). Note: When the rank marking of the replaced LED print head (new part) is the same as that of the used LED print head (old part), you do not always have to set the LED print head drive time.

  • Page 179: Confirmation Items

    5.2.1 Confirmation Items The clock frequency and power voltage of the machine are not possible to adjust in the field. However, their measurement procedures are described here for confirmation of clock frequency and each voltage. Clock Frequency • Measurement point: 46F board;...

  • Page 180: Measurement

    5.2.2 Measurement Trun the AC power OFF. Carry out the disassembly procedure up to Cover assembly-top, Frame assembly-scanner, and Unit-printer. (Refer to the Mechanical Disassembly and Reassembly in Chapter 4.) Connect extension cables to the 46F board. Connect the frequency counter (for clock frequency), digital voltmeter (for power voltage) and Oscilloscope (for SIG signal).
  • Page 181 Crystal Oscillator Connector CN5-1 (SIG) IC24-9pin Ground Terminal Connector CN7 Ground Terminal CN7-1 (+24VDC) CN7-2,3 (+5VDC) CN7-8 (+30VDC) CN7-9 (-8VDC) CN7-12 (+5VSUB) Figure 5.2 Measurement Points on R46 Board 181 / 41309401TH Rev.4...

  • Page 182: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Replacement of Consumable The user (or service personnel) is required to replace the following items as consumable parts. (1) User side Expected Use Before Reference Item No. Part name Replacement in Figure 6.1 Toner Cartrige 1,875 sheets/4% duty (ITU-T document sample No.1) (For the second or later cartridge to a new I/D Unit)
  • Page 183 (3) Others Table 6.1 Reliability Item Specifications Document feeder Jam occurrence and misfeeds in the automatic document feeder will be less than one in 500 operations for all specified documents. Recording paper Jam occurrence in the automatic paper feeder will be less than feeder one in 1,500 operations and misfeeds will be less than one in 500 operations for all specified recording paper.

  • Page 184: Routine Inspection

    Routine Inspection Basically, the routine inspection of following items is performed about half-yearly (or every one year) after the machine is installed. The description of routine inspection is shown in Table 6.2. Table 6.2 Routine Inspection Expected Use Before Reference Item No. Part name Replacement in Fig.6.2...
  • Page 185 (5) LED head (4) Separation rubber (2) Roller - ADF Paper exit ID unit (1) Roller - Scan Document exit (3) Image sensor (6) Printer block Figure 6.2 Parts of Routine Inspection 185 / 41309401TH Rev.4...

  • Page 186: Printer Counter Display/Clear

    Printer Counter Display/Clear Note: The fonts displayed on the LCD operation panel may differ from the fonts written this manual. Purpose A user can clear the image drum unit and check some of the counters (such as the print counter, scan counter) by using the ← key or → key. 2-1.
  • Page 187 2-2. Procedure The following shows the case when the service bit has been set OFF & TONER COUNT CLEAR = ON. Operations: The display shows: 1 4 : 1 4 F A X To bring the LCD up to the desired message, press SELECT FUNCTION key once and Press FUNCTION key.

  • Page 188: Printer Counter Display/Clear

    Printer Counter Display/Clear Purpose The service personnel can clear and check the following data: • Image Drum • Toner • Image Drum (Total) • Print • Scan Procedure The following shows the case when the service bit has been set ON. Operations: The display shows: To bring the LCD up to the desired message,...

  • Page 189: Local Test

    Local Test 6.5.1 When G4 option board is not installed. 1 : L O C A L T E S T Y E S ( ← ) N O ( → / 1 - 5 ) → key or 1-5 ←...

  • Page 190: When G4 Option Baord Is Installed

    6.5.2 When G4 option baord is installed. 1 : L O C A L T E S T Y E S ( ← ) N O ( → / 1 - 6 ) → key or 1-6 ← key Technical Programming LT-1 ←...

  • Page 191: Self-Diagnosis Test

    Self-diagnosis Test Purpose To check ROMs, RAMs and printing function. Procedure (in Case of not G4 Boad) Operations: The display shows: To bring the LCD up to the desired message, TECH. PROGRAMMING press SELECT FUNCTION key once and COPY YES(←/1-5) NO(→) key twice in the standby mode.

  • Page 192: Self Diagnosis Report

    • Image processor LSI RAM check • Setting DEFAULT TYPE and reading clock at self diagnosis execution. The following printing differs depending on the machine type of OKIFAX4550/OKIOFFICE87 and on the condition of option provided or not. “4M” is printed for OKIFAX4550 and “6M” for OKIOFFICE87.
  • Page 193 LANGUAGE VERSION aaaa HASH hhhh DEFAULT VERSION aaaa HASH hhhh RAM1 RAM2 DEFAULT TYPE 03/03/2000 12:00 DEVICE ID MFG:OKI DATA CORP; MDL:FX-046FAX; DES:OKI FX-046FAX; OPT-RAM ISDN BOARD CPU-ROM VERSION aaaa HASH hhhh CPU-RAM PROGRAM VERSION aaaa HASH hhhh DPRAM Figure 6.3 Self-diagnosis Data...

  • Page 194: Sensor Calibration Test

    Sensor Calibration Test Purpose To adjust the linearity of output levels of contact image sensor. Operations: The display shows: To bring the LCD up to the desired message, TECH. PROGRAMMING press SELECT FUNCTION key once and COPY ← → YES( /1-5) key twice in the standby mode.
  • Page 195 Operations: The display shows: Continued from the previous page Enter "2". 2:SENSOR CALIBRATION ← → YES( /1-8) ← ← Press key. 2:SENSOR CALIBRATION End of prefeed PLEASE SET DOCUMENT Set white document. Load document(s). For adjustment of levels, use white plain bond paper(s) of NA Letter or A4 2:SENSOR CALIBRAION size.

  • Page 196: Leds Test

    LEDs Test Purpose To check all LEDs on operation panel by lighting. Procedure Operations: The display shows: To bring the LCD up to the desired message, TECH. PROGRAMMING ? press SELECT FUNCTION key once and COPY ← → YES( /1-5) key twice in the standby mode.

  • Page 197: Tone Send Test

    Tone Send Test Purpose To send the G3 tonal frequencies to the line. Procedure Operations: The display shows: To bring the LCD up to the desired message, 1:SELF DIAGNOSIS press SELECT FUNCTION key once, COPY ← → YES( /1-8) ← key twice and key twice.

  • Page 198: High-Speed Modem Send Test

    6.10 High-speed Modem Send Test Purpose To check the telephone line quality in combination with a remote station programmed to the high-speed modem receive test mode. Procedure Operations: The display shows: To bring the LCD up to the desired message, 1:SELF DIAGNOSIS press SELECT FUNCTION key once, COPY ←...
  • Page 199 TX Side RX Side 5:MODEM SEND TEST 6:MODEM REC TEST ← → YES( /1-8) ← → YES( /1-8) ← ← Press key. Press key. CML relay operates. CML relay operates. The display shows: 5:MODEM SEND TEST " Training MODEM rate The display shows: (e.g.

  • Page 200: High-Speed Modem Receive Test

    6.11 High-speed Modem Receive Test Purpose To check the telephone line quality in combination with a remote station programmed to the high-speed modem send test mode. Procedure Operations: The display shows: To bring the LCD up to the desired message, 1:SELF DIAGNOSIS press SELECT FUNCTION key once, COPY ←...

  • Page 201: Mf Send Test

    6.12 MF Send Test Purpose To send the multi-frequencies of tone dialling to the line. Procedure Operations: The display shows: To bring the LCD up to the desired message, 1:SELF DIAGNOSIS press SELECT FUNCTION key once, COPY ← → YES( /1-8) ←...

  • Page 202: Tone (Tel/Fax)

    6.13 Tone (TEL/FAX) Purpose To check the pseudo-ring back tone of TEL/FAX automatic switching. Procedure Operations: The display shows: To bring the LCD up to the desired message, 1:SELF DIAGNOSIS press SELECT FUNCTION key once, COPY ← → YES( /1-8) ←...

  • Page 203: Protocol Dump Data Printing

    6.14 Protocol Dump Data Printing Purpose To analyze the transmitted/received G3 protocol signals. Procedure • Manual print-out of the last communication. (a) Manual print-out Operations: The display shows: 14:14 FAX Press SELECT FUNCTION key, provided FUNCTION (Standby) that the service bit is ON. SELECT FUNCTION (OT) MEMORY AVAIL.=100% Press one-touch key No.6...

  • Page 204: G3 Protocol Dump

    6.14.1 G3 Protocol Dump Purpose: To allow the serviceman to obtain a list of protocol signals transferred between the transmitter and receiver. Print conditions: • Modem trace information for each TX/RX is printed. (Informeation for RX is added on 2nd page.) •...
  • Page 205 G3 Protocol Dump Image PROTOCOL DUMP P1 12/24/1998 19:00 ID=OKI TAKASAKI DATE TIME S,R-TIME DISTANT STATION ID MODE PAGES RESULT 12/24 18:56 00'33" 123456789012345678901234 0000 PPS_MPS PPS_EOP TRANSMITTED FRAME 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...
  • Page 206 PROTOCOL DUMP P2 12/24/1998 19:00 ID=OKI TAKASAKI RECEIVED FRAME FF C8 01 00 73 17 22 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...

  • Page 207: Analysis From The Data

    6.14.2 Analysis from the data The printed out data permits to analyze G3 facsimile communication protocol signals between two facsimile machines. Figure 6.5 (2/2) shows the result of an analysis on the printed data referring to Figure 6.5 (1/2) (Protocol dump data). (Transmitter) (Receiver) Dialling...

  • Page 208: Fcf (Facsimile Control Field) Conversion Table

    6.14.3 FCF (Facsimile Control Field) conversion table Table 6.2 shows all FCF signals which are needed to analyze the printed out protocol dump data. Some signals have two different hexadecimal codes in accordance with the calling party or called party. Table 6.2 FCF Signals Conversion Table Abbreviation Hex.

  • Page 209: G4 Protocol Dump

    6.14.4 G4 Protocol Dump Purpose: To allow the serviceman to obtain a list of protocol signals transmitter and receiver. Method: The report will be manually printed out for maintenance purpose. If it is G4, the G4 communication protocol dump is printed out. 1.
  • Page 210 Protocol Dump The printing image is as follows: PROTOCOL DUMP P1 08/25/2000 19:00 ID=OKI TAKASAKI DATA TIME S,R-TIME DISTANT STATION ID MODE PAGES RESULT 04/19 14:49 00’07" OKI SHIBAURA(6412) TX-G4 0000 Dch. SETUP CONN-ACK +Bch+ DISC REL-C STATUS SETUP-ACK CONN +Bch+ Bch.
  • Page 211 PROTOCOL DUMP P2 CR/CN 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 CA/CC 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00...

  • Page 212: System Reset

    6.15 System Reset Purpose To clear or initialize the following data: (a) Location data (b) Configuration data (default) Procedure Operations: The display shows: Press SELECT FUNCTION key, COPY key twice. TECH. PROGRAMMING (In case of no message in the memory) ←...

  • Page 213: Service Codes

    6.16 Service Codes The service code can be printed on Activity Report to recognize the result of each communication. The activity report indicates the code ”0000", should a communication terminates on normal status as a service code. The activity report indicates one of the codes of “90XX”, should a communication terminates on abnormal status, as an error code.

  • Page 214: G3 Service Code List

    6.16.1 G3 Service Code List Table 6.3 (1/3) Service Codes List Code Description 0000 Successful end of communication. 1080 STOP key has been pressed while calling a remote fax. 10A2 Busy tone detected. 14C0 Dial tone not detected. 14C1 Line current not detected. 14C2 Calling-and-waiting for line connection time out.
  • Page 215 Table 6.3 (2/3) Service Codes List Code Description 29C1 In closed Network setting, TSI/CSI is either not received or, if received, it is not autho- rized one. 29E0 Contents of CM/JM are faulty at receive side. 29E1 Phase 2 time out at receive side. 29E2 Phase 3 time out at receive side.
  • Page 216 Table 6.3 (3/3) Service Codes List Code Description 9083 T3 time out. 9084 No recording paper. 9087 Document jam. 9088 60-minute or 70-minute time out. 9089 Document length has exceeded its maximum limit. 908E Recording paper jam. 9090 Received DCN. 909D Telephone number to be called to the Fax2Net is the wrong number.

  • Page 217: G4 Service Code Lists

    6.16.2 G4 Service Code Lists Table 6.4 (1/3) G4 Service Code Lists Alarm Result Remarks Classification Code Description Dch layer 2 ISDN board error BB02 LSI NG BB05 TEI release by network BB06 TEI verification procedure failure Dch layer 3 BA01 Unallocated (unassigned) number BA02...
  • Page 218 Table 6.4 (2/3) G4 Service COde Lists Classification Code Description Alarm Result Remarks BC02 N2 times time out Bch layer 2 FRMR reception BC03 BC04 FRMR transmission The other party link disconnection BC05 BC08 T3 time out SABME wait time out BD01 B201 The other party terminal busy...
  • Page 219 Table 6.4 (3/3) G4 Service COde Lists Classification Description Alarm Result Remarks Code B901 Command response reception error Bch layer 5 B902 Non-implicit command response received B903 Lack of essential parameter B904 Invalid parameter reception B905 Invalid parameter value reception B906 Window size over reception B907...

  • Page 220: Troubleshooting And Repair For Okifax4550/Okioffice87

    TROUBLESHOOTING AND REPAIR FOR OKIFAX4550/OKIOFFICE87 220 / 41309401TH Rev.4...
  • Page 221 This chapter contains: (a) Troubleshooting flow charts related to general operations (b) Troubleshooting flow charts by test operations Troubleshooting flow charts placing an emphasis on mechanical portions Section Name of Flow Chart Page Overall troubleshooting flow chart No LCD operation ALARM LED on Printing test failure No local copy...

  • Page 222: Overall Troubleshooting Flow Chart

    Go to 7.6 (Auto dial failure). Transmission problem? Go to 7.7 (Transmission problem). Auto reception OK? Go to 7.8 (Auto reception failure). Reception problem? Go to 7.9 (Reception problem). Note: 46F/R46 board for OKIFAX4550/ OKIOFFICE87 is shown as MCNT. Verify symptom. 222 / 41309401TH Rev.4...

  • Page 223: No Lcd Operation

    Replace OPE UNIT (O4W). Solved? Replace MCNT Solved? Check MCNT board and the cable between MCNT and OPE boards. Return to section 7.1 Return to section 7.1 Note: 46F/R46 board for OKIFAX4550/OKIOFFICE87 is shown as MCNT. 223 / 41309401TH Rev.4...

  • Page 224: Alarm Led On

    Alarm LED On Start Checking Points: Communication error? "COVER OPEN" on LCD? Press STOP key. "PRINTER ALARM i" alarm? ALARM LED goes off? "PAPER JAM" alarm? "NO PAPER" alarm? Go to 7.22 (Printer unit). "TONER LOW" alarm? Return to section 7.1 1.

  • Page 225: Printing Test Failure

    Printing Test Failure Start Perform SELF DIAGNOSIS. Print test OK? Replace MCNT Board Solved? Return to section 7.1 Go to 7.22 (printer unit) 225 / 41309401TH Rev.4...

  • Page 226: No Local Copy

    No Local Copy Checking Points: Start Printing function of Go to 7.4 (Printing test failure). self-diagnosis is OK? Load a document. The document is fed by any length? 1. Check PC1. 2. Replace MCNT board. 3. Check the mechanical portion. The document is fed by (Scan motor, etc.) about 7cm and stops with...

  • Page 227: Auto Dial Failure

    Auto Dial Failure Start Manual dial OK? Can you hear dial tone when lifting up your handset? 1. Check the line cable. 2. Check the exchange. Check pulse dial/tone dial, dial rate, etc. Check closed network. Test other fax machines (Note 1) under the same conditions.

  • Page 228: Transmission Problem

    Transmission Problem This section explains how to localize the cause of problems occurred after completion of connection with a remote station. Start Step 1: Set MH ONLY (Technical function No. 12) to ON. Solved? Step 2: Set HIGH-SPEED MODEM RATE (Technical function No.

  • Page 229: Auto Reception Failure

    Auto Reception Failure Start Manual reception OK? Your handset telephone Placed in the auto receive rings when a call arrives? mode? If not, place the 1. Check the handset of fax machine in that mode telephone set. by pressing AUTO REC key. 2.

  • Page 230: Reception Problem

    Reception Problem This section explains how to localize the cause of problems occurred after completion of connection with a remote station. Start Step 1: Set MH ONLY (Technical function No. 12) to ON. Solved? Step 2: Set HIGH-SPEED MODEM RATE (Technical function No.

  • Page 231: Sensor Calibration Test

    7.10 Sensor Calibration Test Start Checking Points: Perform SENSOR CALI- BRATION. (See 6.6) "SCANNING ERROR" appears on LCD while adjusting for level. Check that white plain bond paper of NA Letter or A4 size is loaded on the feeder. Abnormal feeding is observed during No document SCANNING CHECK?

  • Page 232: Led Test

    7.11 LED Test Start Checking Points: Perform LED TEST. (See 6.8) All LEDs light? No (No LED lights) Any LED does not light? Yes (One LED or some LEDs light.) 1. Check the connection cable. 2. Check the oscillator OSC (OPE). 3.

  • Page 233: Tone Send Test

    7.12 Tone Send Test Start Note 1: The tonal frequency (2100 Hz) will be sequentially sent for 5 seconds on the line terminals L1 and L2. Perform TONE SEND TEST. (See 6.9.) Connect leads of frequency counter (or oscilloscope) across the line terminals L1 and L2.

  • Page 234: High-Speed Modem Test

    7.13 High-speed Modem Test Start Connect oscilloscope probe across the line terminals L1 and L2 Perform H-MODEM SEND TEST for the transmitter and H-MODEM REC TEST for the receiver. (See Fig. 6.9.1) Which mode, TX or RX? Modem’s signal appears across L1 and L2? TX End Modem’s signal appears...
  • Page 235 RX (Receiver) The error counter of LCD stops counting up? RX End Receive signal appears across L1 and L2? Check the line. Receive signal appears across CN3-48 (R) and CN3-14 (GND) of NCU board? Replace MCNT Board. Signal route: <46F> CN10-A2 (R)→IC12-3→...

  • Page 236: Mf Send Test

    7.14 MF Send Test Start Connect oscilloscope probe across the line terminals L1 and L2. Perform MF SEND TEST. (See 6.12.) MF signal appears across L1 and L2? MF signal appears across CN10-A4 (S) and CN10-B1 (0V) of MCNT Board? Replace MCNT Board.

  • Page 237: Tone (Tel/Fax) Send Test

    7.15 Tone (TEL/FAX) Send Test Start Note: The pseudo-ring back tone is sent to the Connect oscilloscope probe telephone line for TEL/FAX automatic across the line terminals switching. L1 and L2. Perform TONE (TEL/FAX) SEND TEST. (See 6.13.) Pseudo-Ring Back Tone signal appears across L1 and L2? MF signal appears across CN10-A4...

  • Page 238: No Acoustic Line Monitor

    7.16 No Acoustic Line Monitor There are two source routes of acoustic line monitor: General communication signal DP pulse signal Start MONITOR VOLUME (Function program No. 06) Set MONITOR VOLUME has been set to to LOW or HIGH. LOW or HIGH? Yes (OFF) MONITOR CONTROL (Technical function No.

  • Page 239: Power Supply Unit

    7.17 Power Supply Unit (A) Low-voltage Selection Replace the Power Supply Unit when output voltage written on the item A3 in the Appendix A is not normal. (B) High-voltage Selection T.B.D. (To be determined) 7.18 No Document Feeding Note: This section places an emphasis on troubleshooting of mechanical portions. Therefore, it is recommended to replace the MCNT Board first and, then if not solved, follow this flow chart.

  • Page 240: Multiple Document Feeding

    7.19 Multiple Document Feeding Definition: Multiple document feeding. Multiple documents are not separated and they are fed in the same one feeding operation. Start The leading edges of Align them. the documents are aligned? The separation rubber Clean it. is dirty? After pushing the Check the ADF spring, separation rubber assembly,...

  • Page 241: Document Skew

    7.20 Document Skew Start 1. Set the guides to meet the Are the document guides set to meet the document width. document width? 2. Load the documents Are the documents straightly loaded along straight along the guides. the guides? The documents have Load documents by meeting the same width? the same width.
  • Page 242 Is separation rubber dirty? Clean it. Are pinch rollers pressed normally by the Set them properly. springs? (After pushing them by fingers, do they return back to the original positions?) Clean them. Are roller-scan dirty? Are roller-scan Replace it. worn or slippery? Clean it.

  • Page 243: Document Jam

    7.21 Document Jam Start Note: 46F/R46 board for OKIFAX4550/OKIOFFICE87 are shown as MCNT. Load a document. 1. Check PC1. Is document fed by 2. Replace MCNT Board. any length? 3. Check the mechanical portion. (Scan motor, etc.) See 7.1.18 for further details.

  • Page 244: Printer Unit

    7.22 Printer Unit 7.22.1 Precautions Points to check before correcting image troubles (1) Is the printer being run in proper ambient conditions? (2) Have the supplies (toner) and the routine replacement part (EP unit) been replaced properly? (3) Is the recording paper normal? (4) Has the EP unit been loaded properly? Tips for correcting image troubles (1) Do not touch, or bring foreign matter into contact with the surface of the drum.

  • Page 245: Troubleshooting Flow Charts Of Printer Unit

    7.22.2 Troubleshooting Flow Charts of Printer Unit Overall troubleshooting flow chart: Troubles Troubles indicated Troubleshoot Perform detailed by LCD message according to the LCD troubleshooting with message trouble list. one of troubleshooting See Table 7.22.1 flow chart 1 to 6. Image troubles Troubleshoot Perform trouble-...
  • Page 246 Troubleshooting flow chart 1: Cover (Cover-top) is open. ** COVER OPEN ** Close the cover Solved? Is the cover open switch Connect the cover open connector out of position? switch connector. Return to section 7.1 See ACTION 2. 246 / 41309401TH Rev.4...
  • Page 247 Troubleshooting flow chart 2: Warning message to replace ID unit because of its life. ** CHANGE DRUM SOON ** Turn on power again. Does the CHANGE See ACTION 3. DRUM SOON message remain on display? Is the MCNT Board Mount it properly. mounted properly? See ACTION 4.
  • Page 248 Troubleshooting flow chart 3: Engine controller error (ROM/RAM error) ** PRINTER ALARM 2 ** Turn on power again. Does the PRINTER See ACTION 5. ALARM 2 message remain on display? See ACTION 6. 248 / 41309401TH Rev.4...
  • Page 249 Troubleshooting flow chart 4: Fuser unit thermal error ** PRINTER ALARM 4 ** Turn on power again. Is the PRINTER ALARM 4 message See ACTION 7. displayed with a delay? About 60 seconds later See ACTION 6. Turn on power again. Is the fuser unit heater See ACTION 7.
  • Page 250 Troubleshooting flow chart 5: Recording paper feed jam, transport jam, ejection jam, recording size error PAPER OUT/JAM REPLACE PAPER Is the paper tray Load it properly. loaded properly? Is the paper of Replace with paper of the specified size? specified size. Does the same error Remove the jammed paper.
  • Page 251 Troubleshooting flow chart 6: No recording paper tray or not recording paper No recording paper on the tray PAPER OUT/JAM REPLACE PAPER Has the paper Load it. tray been loaded? Is recording paper Load recording paper. out? See ACTION 14. 251 / 41309401TH Rev.4...
  • Page 252 Table 7.22.2 Action Items (Printer Unit-LCD Message) ACTION ACTION Check MCNT Board. Check connection between the PWU and the fuser assembly,heater, ther- Check P2H/P6L Board cover open mostat. switch, cover open switch connec- tion. Check PWU. Check MCNT Board. Check Sensor-E, magnet-H, hopping Return to Section 7.1.
  • Page 253 Table 7.22.3 Image Troubles Reference Troubleshooting Abnormal Symptom Figure Flow Chart No. Images are light or blurred as a whole. Fig. A The blank background is smeared. Fig. B Blank paper is output. Fig. C Black belts or black stripes in vertical direction. Fig.
  • Page 254 Troubleshooting flow chart 7: Images are light or blurred as a whole. Is toner low? Supply toner. Use paper of OKI Is paper of OKI specified grade. specified grade? Are fingerprints or dirts adhering or moisture- Replace the paper. absorbing to the paper? Is the lens surface of the Clean the lens.
  • Page 255 Troubleshooting flow chart 8: The blank background is smeared. Has the Image Drum been Close and wait for about exposed to external light? 30 minutes. Is the heat roller of the Clean it. fuser unit dirty? Is the contact of the cleaning roller Adjust the contact of the of the EP unit in contact cleaning roller to contact...
  • Page 256 Troubleshooting flow chart 10: Black belts or stripes in the vertical direction. Replace the EP Unit Solved? End. Replace the LED print head or Power Supply Unit. 256 / 41309401TH Rev.4...
  • Page 257 Troubleshooting flow chart 11: Periodic abnormal printing Developing roller (inside EP unit) 1.44" (36.6 mm) failure. period? Replace or clean the EP unit. EP drum (inside EP unit) 1.98" (50.3 mm) failure. period? Replace the EP unit. Tonner supply roller (inside the EP 2.63"...
  • Page 258 Troubleshooting flow chart 12: Some parts not printed Is the print paper folded, Replace the paper. bent, or scratched? Is the transfer roller Clean it. dirty? Check EP unit or Power Supply Unit. 258 / 41309401TH Rev.4...
  • Page 259 Troubleshooting flow chart 13: White belts or streakes in the vertical direction Is the lens surface of the Clean the lens. LED print head dirty? Is the contact plate of the transfer Make proper contact of the roller in contact with the contact contact plate with the contact assembly properly? assembly.
  • Page 260 Troubleshooting flow chart 14: Poor fusing Is the paper OKI Use paper of OKI specified grade. specified grade? Is the (Bias) Repair the pressure roller spring normal? spring. (Tension: 2.5 kg) Is the contact of the fuser Adujust the contact of the...

  • Page 261: Dipswitchs Setting Tables For En9/Inu Ncu Boards

    DIPSWITCHS SETTING TABLES FOR EN9/INU NCU BOARDS (Setting as of Jan. 25, 2000) Each country's hardware parameters comparison table. Dip-switch EC countries France Remarks (except UK and France) Shunt wire Ring detection Ring detection Not used 261 / 41309401TH Rev.4...
  • Page 262 EC Countries (except UK and France) (41143501) This section gives the following instruction. • DIP switch setting • Screw tightening position (a black dot) For detail, see the figure below. 411435 LINE 262 / 41309401TH Rev.4...
  • Page 263 UK (41143502) This section gives the following instruction. • DIP switch setting • Screw tightening position (a black dot) For detail, see the figure below. 411435 LINE 263 / 41309401TH Rev.4...
  • Page 264 France (41143503) This section gives the following instruction. • DIP switch setting • Screw tightening position (a black dot) For detail, see the figure below. 411435 LINE 264 / 41309401TH Rev.4...
  • Page 265 (Setting as of Jan. 25, 2000) Each country's hardware parameters comparison table. Singapore Poland Dip-switch Australia Remarks China (non-EC Canada Zealand Malaysia countries) Ring Impedance Ring Impedance 265 / 41309401TH Rev.4...
  • Page 266 US, Canada (41143901) This section gives the following instruction. • Screw tightening position (a black dot) For detail, see the figure below. 411439 LINE * Connector for short-plug and SW1 are not mounted. 266 / 41309401TH Rev.4...
  • Page 267 Australia (41143902) This section gives the following instruction. • DIP switch setting • Short-plug location • Screw tightening position (a black dot) For detail, see the figure below. 411439 LINE 267 / 41309401TH Rev.4...
  • Page 268 New Zealand (41143903) This section gives the following instruction. • DIP switch setting • Short-plug location • Screw tightening position (a black dot) For detail, see the figure below. 411439 LINE 268 / 41309401TH Rev.4...
  • Page 269 Singapore, China, Malaysia (41143904) This section gives the following instruction. • DIP switch setting • Short-plug location • Screw tightening position (a black dot) For detail, see the figure below. 411439 LINE 269 / 41309401TH Rev.4...
  • Page 270 Poland (non-EC countries) (41143905) This section gives the following instruction. • DIP switch setting • Short-plug location • Screw tightening position (a black dot) For detail, see the figure below. 411439 LINE 270 / 41309401TH Rev.4...

  • Page 271: Appendix Apc Board Descriptions And Operation

    H.V. Board P6L Board-PSU Plate Assy.-Base Figure A.1 Unit Configuration (Modifying) (1) Main control board (46F: OKIFAX4550, R46: OKIOFFICE87) (2) Network control unit (NCU) (3) Power supply unit (MPW1446 (230V), MPW1546 (120V) (4) Operation panel board (04W) (5) High Voltage Board (P2H)
  • Page 272 272 / 41309401TH Rev.4...
  • Page 273 273 / 41309401TH Rev.4...

  • Page 274: The Unit Configuration Is As Follows

    The unit configuration is as follows: Meaning of abbreviations used in Block Diagram : Analog-to-digital converter : Amplifier : Battery : Connector number i : Central processing unit D-MOTOR : Drum motor : Motor drive DRAM : Dynamic random-access memory IEXSEED300 : Image proccessing gate array LC821033...

  • Page 275: Function Of Each Unit

    Function of Each Unit The section describes the principal functions of the individual units of the OKIFAX4550/OKIOFFICE87 electrical sections. Figure A.2/A.3 shows the pertinent block diagram. (1) 46F board (OKIFAX4550) • IOGA4 (Input/output gate array 4) 1/4: CPU SH7034 Basic processor CPU periheral functions •...
  • Page 276 (2) R46 board (OKIOFFICE87) • CPU SH7034 Basic processor CPU periheral functions • IOGA6 (Input/output gate array 6) 1/3, 2/3, 3/3 Scanned data DMA control Printing control Peripheral input/output control • Flash memory (Instead of EP-ROM and SRAM) Memory storage for program code Memory storage for user/service setting data •...
  • Page 277 (5) Power supply unit: MPW1446 (230V)/MPW1546 (120V), P6L, P2H • Conversion of main alternating current to the following direct currents: +5V DC power supply -8V DC power supply +24 V DC power supply +30 V DC power supply • Supplying of main alternating current to fuser unit •...

  • Page 278: Explanation Of Signal Flow

    Explanation of Signal Flow OKIFAX4550 (1) Copy Mode Figure A.4 (1/13) shows the picture signal route in local copy mode One-line picture data is transferred to A/D converter (analog/digital) via operational amplifier from the scanning unit (CIS: contact image sensor) as an analog data. After conversion from analog data to 6-bit digital data by A/D converter, the picture data is sent to IEXSEED (image processing LSI) and SRAM.
  • Page 279 (6) PC-FAX TX Figure A.4 (6/13) shows the signal route in PC-FAX TX mode. The data encoded and HDLC framed in PC is input to IOGA4 via the parallel I/F to be transferred to the DRAM under the control of DMA. The stored encoded data is output from DRAM to the MODEM under the control of IOGA4 (CPU).
  • Page 280 (13) G4 RX mode Figure A.4 (13/13) shows the signal route of this mode. The signal received from an ISDN line is transferred to the dual-port RAM (DPRAM) by the control of the CPU via the ISDN driver and ISDN controller of the G4N board. Notified of the existence of received G4 data by interruption, the IOGA4 (CPU) of the 46F board transfers the data from the DPRAM to the DRAM.
  • Page 281 281 / 41309401TH Rev.4...
  • Page 282 282 / 41309401TH Rev.4...
  • Page 283 283 / 41309401TH Rev.4...
  • Page 284 284 / 41309401TH Rev.4...
  • Page 285 285 / 41309401TH Rev.4...
  • Page 286 286 / 41309401TH Rev.4...
  • Page 287 287 / 41309401TH Rev.4...
  • Page 288 288 / 41309401TH Rev.4...
  • Page 289 289 / 41309401TH Rev.4...
  • Page 290 290 / 41309401TH Rev.4...
  • Page 291 291 / 41309401TH Rev.4...
  • Page 292 292 / 41309401TH Rev.4...
  • Page 293 293 / 41309401TH Rev.4...

  • Page 294: Okioffice87

    OKIOFFICE87 (1) Copy Mode Figure A.5 (1/13) shows the picture signal route in local copy mode One-line picture data is transferred to operational amplifier from the scanning unit (CIS: contact image sensor) as an analog data. The picture data is sent to LC821033 (image processing LSI). Here, the picture data undergoes various kinds of picture processings (LC821033), converted to two-level binary data (black and white) and then sent to IOGA6 (scanning control).
  • Page 295 (6) PC-FAX TX Figure A.5 (6/13) shows the signal route in PC-FAX TX mode. The data encoded and HDLC framed in PC is input to LVC161284 and IOGA6 via the parallel I/F to be transferred to the DRAM under the control of DMA. The stored encoded data is output from DRAM to the MODEM under the control of CPU.
  • Page 296 (12) G4 TX mode Figure A.5 (12/13) shows the signal route of this mode. The signal route from the image sensor to the LC821033, DRAM, IOGA6, CPU, and DRAM is the same as that of the item (2), “G3 send mode”. The read one-line image data is stored in the DRAM, encoded by the CPU and again stored in the DRAM.
  • Page 297 297 / 41309401TH Rev.4...
  • Page 298 298 / 41309401TH Rev.4...
  • Page 299 299 / 41309401TH Rev.4...
  • Page 300 300 / 41309401TH Rev.4...
  • Page 301 301 / 41309401TH Rev.4...
  • Page 302 302 / 41309401TH Rev.4...
  • Page 303 303 / 41309401TH Rev.4...
  • Page 304 304 / 41309401TH Rev.4...
  • Page 305 305 / 41309401TH Rev.4...
  • Page 306 306 / 41309401TH Rev.4...
  • Page 307 307 / 41309401TH Rev.4...
  • Page 308 308 / 41309401TH Rev.4...
  • Page 309 309 / 41309401TH Rev.4...

  • Page 310: F Circuit Diagram (Okifax4550)

    46F Circuit Diagram (OKIFAX4550) 46F Circuit Diagram (1/13) Block diagram 46F-PCB circuit diagram (1/13) shown the consists of an input/output gate array IC2 (IOGA4), crystal oscillator circuit and reset signal generator. Figure A.6 shown the block diagram of IC2 (IOGA4) and the peripheral circuits.

  • Page 311: Circuit Diagram (2/13)

    46F Circuit Diagram (2/13) Block diagram 46F-PCB circuit diagram (2/13) shown the consists of Flash memory, DRAM, Real time clock IC and Back up battery circuit. Figure A.7 shows the block diagram of Flash memory, DRAM and Real time clock. Function Flash memory (FLS) Flash memory (electrically erasable and programmable device) is used for the main...

  • Page 312: Circuit Diagram (3/13)

    46F Circuit Diagram (3/13) Block diagram 46F-PCB circuit diagram (3/13) shown the consists of IC11 (analog switch IC) and IC5 (amplifier) generates the following audio monitor. • Line monitoring • Buzzer signals Figure A.8 shows the block diagram of audio monitor circuit. Function Line monitoring Send and receive signals are input from the transformer on the NCU board to this circuit...

  • Page 313: Circuit Diagram (4/13)

    46F Circuit Diagram (4/13) Block diagram 46F-PCB circuit diagram (4/13) shown the consists of the following functions: • IC6 (A/D converter) • Connector CN5 that provides an interface between 46F board and CIS (contact image sensor). Figure A.9 (1/3) shows the related signals and block diagram of CIS. Function One-line picture data is read in the sequence from the scanning unit (CIS) as SIG signal (analog data) to A/D converter (analog/digital converter) of IC6.
  • Page 314 1.25 MHz (L: duty 75%) MISP VLED ON: all the time 4 • • • • • • 2592 2.5 msec 1 line Figure A.9 (2/3) Signal timing of CIS (contact image sensor) 800 ns 600 ns PDCK N + 1 N + 2 N + 3 N + 4...

  • Page 315: Circuit Diagram (5/13)

    46F Circuit Diagram (5/13) Block diagram 46F-PCB circuit diagram (5/13) shown the consists of Modem (33.6 kbps). Modem consists the following functions: • Modulation/demodulation Modulation type: 1) ITU-T Rec. V34 (33600/31200/28800/26400/24000/21600/19200/16800/14400/12000/ 9600/7200/4800/2400 bps) for G3 picture data. 2) ITU-T Rec. V17 (14400/12000/9600/7200 bps) for G3 picture data. 3) ITU-T Rec.

  • Page 316: Circuit Diagram (6/13)

    46F Circuit Diagram (6/13) Block diagram 46F-PCB circuit diagram (6/13) shown the consists of connector CN12 that provides an interface between 46F board and LED print head. Figure A.11 (1/2) shows the related signals and block diagram of LED print head. Function Data of 1664 LEDs on the LED print head is loaded into the shift registers by the HCLCK (4MHz or 6.7 MHz) signal.
  • Page 317 HCLCK HLATCH HDATA0 STRB1-N STRB2-N STRB3-N STRB4-N First line printing data sent Second line printing data sent First line printing Figure A.11 (2/2) Normal Mode Printing Timing Chart 317 / 41309401TH Rev.4...

  • Page 318: Circuit Diagram (7/13)

    46F Circuit Diagram (7/13) Block diagram 46F-PCB circuit diagram (7/13) shown the consists of the following connectors: • Connector CN10 that provides an interface between 46F board and NCU/G4N board. • Connector CN3 that provides an interface between 46F board and external electro-mechanical conponents (PC1 and PC2).
  • Page 319 CN10 CN3 Receiving Modem sensitivity control Relay driver circuit MUTE PBXE IOGA4 to OPE Hook-up signal detection circuit to OPE Ringing signal detection circuit Figure A.12 (1/4) Interface between 46F Board and NCU Board OPE (04W) KSCAN0 X’tal KSCAN7 CN4 CN1 Key switch matrix TXDOPE...
  • Page 320 Between the MCNT and OPE, serial data is transferred via the SIO incorporated in the CPU. <Communication method> Communication method: Start-stop synchronization Transfer rate: 5832 bps Data length: 8 bits <Data configuration> Status bit: 1 bit Data: 8 bits Even parity: 1 bit (ignored by OPE) Stop bits: Bits 1 and 5...

  • Page 321: Circuit Diagram (8/13)

    46F Circuit Diagram (8/13) Block diagram 46F-PCB circuit diagram (8/13) shown the consists of the following functions and connectors: • IC9 (Drum motor driver) • Connector CN13 that provides an interface between 46F board and the drum motor. Figure A.13 shows the related signals of the drum motor. Function Drum motor control This drum motor is driven by the motor driver IC9.

  • Page 322: Circuit Diagram (9/13)

    46F Circuit Diagram (9/13) Block diagram 46F-PCB circuit diagram (9/13) shown the consists of the following function and connectors: • IC7 (Send motor driver) • TR512/TR513 (Clutch driver) • Connector CN1 that provides an interface between 46F board and the send motor. •...
  • Page 323 IC16 PHSA PHSB PHSC PHSD Send motor IEXSEED MTP3 drive Send motor MTP2 MTP1 MTP0 +30V (1-2 phase excitation) TR512/TR513 PJON Clutch IOGA4 Clutch Clutch drive Figure A.14 (1/2) Related Signals of Send Motor and Clutch PHSA PHSB PHSC PHSD STD/FINE:t=1.25ms (800pps) EX-FINE:t=2.5ms (400pps) Figure A.14 (2/2) Timing Chart of Send Motor...

  • Page 324: Circuit Diagram (10/13)

    3.10 46F Circuit Diagram (10/13) Block diagram 46F-PCB circuit diagram (10/13) shown the consists of the following connectors: • Connector CN11 that provides an interface between 46F board and Bi-Centro I/F. Figure A.15 (1/2) shows the interface between 46F and Bi-Centro I/F. Figure A.15 (2/2) shows the timing chart of Centronics Parallel Interface.

  • Page 325: Circuit Diagram (11/13)

    3.11 46F Circuit Diagram (11/13) Block diagram 46F-PCB circuit diagram (11/13) shown the consists of the following connector: • Connector CN6 that provides an interface between 46F board and power supply unit (P2H). • Connector CN7 that provides an interface between 46F board and power supply unit (MPW1446/MPW1546).
  • Page 326 CN6 CN1 CVOPN-N CVOPN-N COVER open switch IOGA4 WRSNS-N Write sensor WRSNS Outlet sensor PSOUT-N PSOUT Inlet sensor PSIN-N PSIN TRSNS-N TNR5N5 Toner end sensor Figure A.16 (1/4) Sensor and Switch Control TONER FULL state 280 ms < t1 < 630 ms TNRSNS-N 2.51 sec.
  • Page 327 Fuser unit temperature control The heater in the fuser unit is controlled by the thermister, IOGA4 keeps the heater roller surface within a prescribed temperature range. The IOGA4 supervises the status of THCHK (A/D converter input section) periodically, turning HEATON signal on and off according to IOGA4 of THCHK status to exercise temperature control.
  • Page 328 High-voltage and medium-voltage control High voltages are activated by IOGA4 and generated by the high-voltage circuit inside the power supply unit. The CH (charge) voltage of about -1.30kV is used for the charge roller. The TR1/TR2 (transfer) voltage of about +3.9kV/-0.75kV is used for the transfer roller. Medium voltages are activated by IOGA4 and generated by the medium-voltage circuit inside the power supply unit.

  • Page 329: Circuit Diagram (12/13)

    3.12 46F Circuit Diagram (12/13) Block diagram 46F-PCB circuit diagram (12/13) shown the consists of the IEXSEED300 (image processing LSI) of IC16 and SRAM. Figure A.17 shows the related signals of IEXSEED300. Functions IEXSEED300 is d eveloped LSI for the image processing. IEXSEED300 contains the following functions: •...

  • Page 330: Circuit Diagram (13/13)

    3.13 46F Circuit Diagram (13/13) Block diagram 46F-PCB circuit diagram (13/13) shown the consists of the ispLSI2032E-110LT44 (PLD: Programmable Logic Device) of IC22. Figure A.18 shows the related signals of PLD. Functions • chip select decode : V34CS and MUPISCS signals are produced from NMDCS2 and A18 signals.

  • Page 331: R46 Circuit Diagram (Okioffice87)

    R46 Circuit Diagram (OKIOFFICE87) R46 Circuit Diagram (1/15, 2/15, 3/15) Block diagram R46-PCB circuit diagram (1/15, 2/15, 3/15) shown the consists of an input/output gate array IC2 (IOGA6), crystal oscillator circuit and reset signal generator. Figure A.19 shown the block diagram of IC2 (IOGA6) and the peripheral circuits. Function IOGA6 is newly developed LSI for scanning, printing control and provided with a built-in CPU.

  • Page 332: R46 Circuit Diagram (4/15)

    R46 Circuit Diagram (4/15) Block diagram R46-PCB circuit diagram (4/15) shown the consists of Flash memory, DRAM, Real time clock IC and Back up battery circuit. Figure A.20 shows the block diagram of Flash memory, DRAM and Real time clock. Function Flash memory (FLS1) Flash memory (electrically erasable and programmable device) is used for the main...

  • Page 333: R46 Circuit Diagram (5/15)

    R46 Circuit Diagram (5/15) Block diagram R46-PCB circuit diagram (5/15) shown the consists of IC8 (analog switch IC) and IC11 (amplifier) generates the following audio monitor. • Line monitoring • Buzzer signals Figure A.21 shows the block diagram of audio monitor circuit. Function Line monitoring Send and receive signals are input from the transformer on the NCU board to this circuit...

  • Page 334: R46 Circuit Diagram (6/15)

    R46 Circuit Diagram (6/15) Block diagram R46-PCB circuit diagram (6/15) shown the consists of Modem (33.6 kbps). Modem consists the following functions: • Modulation/demodulation Modulation type: 1) ITU-T Rec. V34 (33600/31200/28800/26400/24000/21600/19200/16800/14400/12000/ 9600/7200/4800/2400 bps) for G3 picture data. 2) ITU-T Rec. V17 (14400/12000/9600/7200 bps) for G3 picture data. 3) ITU-T Rec.

  • Page 335: R46 Circuit Diagram (7/15)

    R46 Circuit Diagram (7/15) Block diagram R46-PCB circuit diagram (7/15) shown the consists of connector CN12 that provides an interface between R46 board and LED print head. Figure A.23 (1/2) shows the related signals and block diagram of LED print head. Function Data of 4992 LEDs on the LED print head is loaded into the shift registers by the HCLCK signal.
  • Page 336 HDCLK-P HDDLD-P HDD(3~0)-P HDSTB1-N HDSTB2-N HDSTB3-N HDSTB4-N First line printing data sent Second line printing data sent First line printing Figure A.23 (2/2) Normal Mode Printing Timing Chart 336 / 41309401TH Rev.4...

  • Page 337: R46 Circuit Diagram (8/15, 9/15)

    R46 Circuit Diagram (8/15, 9/15) Block diagram R46-PCB circuit diagram (8/15, 9/15) shown the consists of the following connectors: • Connector CN10 that provides an interface between R46 board and NCU/G4N board. • Connector CN3 that provides an interface between R46 board and external electro-mechanical conponents (PC1 and PC2).
  • Page 338 CN10 CN3 Receiving Modem sensitivity control Relay driver circuit MUTE PBXE IOGA6 to OPE Hook-up signal detection circuit to OPE Ringing signal detection circuit Figure A.24 (1/4) Interface between R46 Board and NCU Board OPE (04W) KSCAN0 X’tal CPU1 KSCAN7 CN4 CN1 Key switch matrix...
  • Page 339 Between the MCNT and OPE, serial data is transferred via the SIO incorporated in the CPU1. <Communication method> Communication method : Start-stop synchronization Transfer rate : 5832 bps Data length : 8 bits <Data configuration> Status bit : 1 bit Data : 8 bits Even parity...

  • Page 340: R46 Circuit Diagram (10/15)

    R46 Circuit Diagram (10/15) Block diagram R46-PCB circuit diagram (10/15) shown the consists of the following functions and connectors: • IC9 (Drum motor driver) • Connector CN13 that provides an interface between R46 board and the drum motor. Figure A.25 shows the related signals of the drum motor. Function Drum motor control This drum motor is driven by the motor driver IC9.

  • Page 341: R46 Circuit Diagram (11/15)

    R46 Circuit Diagram (11/15) Block diagram R46-PCB circuit diagram (11/15) shown the consists of the following function and connectors: • IC7 (Send motor driver) • TR505/TR506 (Clutch driver) • Connector CN1 that provides an interface between R46 board and the send motor. •...
  • Page 342 MPHA MPHB MPHC MPHD Send motor IOGA6 MPT4 Send motor drive MPT3 MPT2 MPT1 +30V (1-2 phase excitation) CPU1 TR505/TR506 PJON Clutch SH7034 Clutch Clutch drive Figure A.26 (1/2) Related Signals of Send Motor and Clutch MPHA MPHB MPHC MPHD STD/FINE:t=1.25ms (800pps) EX-FINE:t=2.5ms (400pps) Figure A.26 (2/2) Timing Chart of Send Motor...

  • Page 343: R46 Circuit Diagram (12/15)

    R46 Circuit Diagram (12/15) Block diagram R46-PCB circuit diagram (12/15) shown the consists of the following connectors. • Connector CN11 that provides an interface R46 board and Bi-Centro I/F. CN11 IC12 3.3V 222, 223, 226~231 DATA8-P PDATA1-P to PDATA8-P DATA1-P 2 to 9 STB-N STB-N...

  • Page 344: R46 Circuit Diagram (13/15)

    4.10 R46 Circuit Diagram (13/15) Block diagram R46-PCB circuit diagram (13/15) shown the consists of the following connector: • Connector CN6 that provides an interface between R46 board and power supply unit (P2H). • Connector CN7 that provides an interface between R46 board and power supply unit (MPW1446/MPW1546).
  • Page 345 CN6 CN1 CVOPN-N CVOPN-N COVER open switch IOGA6 WRSNS-N Write sensor WRSNS Outlet sensor PSOUT-N PSOUT Inlet sensor PSIN-N PSIN TRSNS-N TNR5N5 Toner end sensor Figure A.28 (1/4) Sensor and Switch Control TONER FULL state 280 ms < t1 < 630 ms TNRSNS-N 2.51 sec.
  • Page 346 Fuser unit temperature control The heater in the fuser unit is controlled by the thermister, IC2(IOGA6) keeps the heater roller surface within a prescribed temperature range. The CPU1 supervises the status of THCHK (A/D converter input section) periodically, turning HEATON signal on and off according to CPU1 of THCHK status to exercise temperature control.
  • Page 347 High-voltage and medium-voltage control High voltages are activated by IC2(IOGA6) and generated by the high-voltage circuit inside the power supply unit. The CH (charge) voltage of about -1.30kV is used for the charge roller. The TR1/TR2 (transfer) voltage of about +3.9kV/-0.75kV is used for the transfer roller.

  • Page 348: R46 Circuit Diagram (14/15)

    4.11 R46 Circuit Diagram (14/15) Block diagram R46-PCB circuit diagram (14/15) shown the consists of the LC821033 (image processing LSI) of IC13. Figure A.29 shows the related signals of LC821033. Functions LC821033 is developed LSI for the image processing. LC821033 contains the following functions: •...

  • Page 349: R46 Circuit Diagram (15/15)

    4.12 R46 Circuit Diagram (15/15) Block diagram R46-PCB circuit diagram (15/15) shown the consists of the following functions: • Connector CN5 that provides an interface between R46 board and CIS (contact image sensor). Figure A.30 (1/2) shows the related signals and block diagram of CIS. Function One-line picture data is read in the sequence from the scanning unit (CIS) as SIG signal (analog data) to IC13.

  • Page 350: Ope (04W) Circuit Diagram

    OPE (04W) Circuit Diagram Block diagram Figure A.31 shows a block diagram of OPE (04W). The 04W (operation unit) circuit consists of the following blocks: IC1 (one chip MOS-CPU) • Output ports Setting LEDs on and off: 8 ports Specifies the row during key switch matrix scanning: 8 ports •...

  • Page 351: Power Supply Unit

    Power Supply Unit MPW1446 (230V)/MPW1546 (120V) Circuit Diagram IMPORTANT: Oki Data Corporation recommends that maintenance of the Power supply unit (MPW1446 (230V)/ MPW1546 (120V)) be performed by replacement of a unit, not by replacement of components. Therefore, circuit descriptions in this section are for reference.
  • Page 352 352 / 41309401TH Rev.4...

  • Page 353: P2H Circuit Diagram

    P2H Circuit Diagram This circuit consists of photo-sensors and high voltage generation unit. Note: If the high-voltage unit inside the P2H circuit board is replaced, the output voltage and current output from the terminals must be checked and adjusted. This section does not describe the checking and adjustment methods, however.

  • Page 354: High-Voltage Section

    High-voltage section 7.1.1 Functional overview The high-voltage outputs consist of TR1 (3.9 kV), TR2 (-0.75 kV), DB1 (+265 V), DB2 (-265 V), SB2 (-550V), CB1 (+400 V), CB2 (-1.35 kV) and CH (-1.30 kV) and are obtained as follows. The control signal obtained from IOGA4 of R46 board is applied to High-voltage power supply circuit.

  • Page 355: Photosensors

    Photosensors The photosensors mounted on this circuit board/sensor board supervise the paper running state during printing. These four photosensors are used in this printer as listed below. All of their outputs enter 46F/R46 board. PS1 (photosensor 1): TNRSNS Detects the lack of the toner. PS2 (photosensor 2): PSIN Detects the leading part of the paper and gives the supervision timing for switching from hopping operation to feeding operation.

  • Page 356: En9 And Inu Circuit Diagram

    EN9 and INU Circuit Diagram The NCU board is selected from EN9 and INU because it differs depending on country’s specifica- tions. • EN9 UK, Flance, EC countries • INU US, Canada, Australia, New Zealand, Singapore, China, Malaysia, non-EC countries (Poland etc.) Block diagram •...
  • Page 357 Explanation on CN3 Terminals Terminal Explanation pin No. name Detection of off-hook of terminal connected to TEL-1 or TEL-2. 0 - 5 V signal output synchronized with the ringing signal frequency Relay control signal for special service code detection at parallel pickup or remote reception 13, 14, Ground 41, 42...

  • Page 358: En9 Circuit Diagram

    EN9 circuit diagram Lightning arresters (AR1, 2) The nominal operating voltage is 500 V. When connecting the ground of the arrestor to the chassis, tighten ARG on the PCB with a screw. At this time, the PCB is grounded through the power cable. The TB1 arrestor ground terminal can also be used to connect to the earth directly.
  • Page 359 Off-hook detectors (IC8, RL7) These circuits detect the off-hook state of the telephone connected to the TEL1, TEL2, through LINE terminals. IC8 uses a high detection sensitivity than of RL7. In TEL/FAX mode, the higher sensitive IC8 is used to detect the off-hook state of the telephone while the main equipment is hunting a line.
  • Page 360 RL7 F OFF-HOOK Detector Ring Detector Shunt Impedance matching NT MUTE LINE , AR FICC arresters to Modem Receiving Q502, Q503 Q1 4 sensitivity Constant current current MUTE...

  • Page 361: Inu Circuit Diagram

    INU circuit diagram Lightning arresters (AR1, 2) The nominal operating voltage is 500 V. When connecting the ground of the arrestor to the chassis, tighten ARG on the PCB with a screw. At this time, the PCB is grounded through the power cable. The TB1 arrestor ground terminal can also be used to connect to the earth directly.
  • Page 362 Off-hook detectors (IC5) These circuits detect the off-hook state of the telephone connected to the TEL. Impedance switches (CN15 to CN35) These circuits set the impedance according to the line requirement. 220: 220 ohm + 820 ohm//115 nF (CN15) 370: 370 ohm + 620 ohm//310 nF (CN35) 600: 600 ohm (CN25) Ring impedance switches (S1-1, 2) These switches set the ring impedance according to the line requirement.
  • Page 363 OFF-HOOK Detector Ring Detector Impedance C5 R505 matching TEL CN1 CN15 ~ CN35 MUTE LINE , AR arresters to Modem Receiving sensitivity MUTE circuit...

  • Page 364: Outline Of Parallel Pick Up

    Outline of Parallel Pick Up Parallel pick up is a function that controls a fax (to make a fax in receive mode) from a telephone set connected parallel to a fax. The two possible parallel connections of telephone sets A and B are shown in the figure.

  • Page 365: G4N-Pcb

    G4N-PCB This PCB board is optionally available. Using this board allows the system to be ready for the G4 protocol. The block diagram of this board is shown on the next page. This board is connected to the MCNT board with a 50-pin connector (CN1). 23 pins of this connector are signals lines dedicated to the G4N board, and the remaining 27 pins are signal lines shared with the NCU board.
  • Page 366 366 / 41309401TH Rev.4...

  • Page 367: Appendix Bdescriptions Of Print Operation

    APPENDIX B DESCRIPTIONS OF PRINT OPERATION Electro-Photographic Processor The electro-photographic processor prints out the image data to be sent from the main control board on sheets of paper. Figure B-1 shows the layout drawing of the electro-photographic processor. (1) Image drum unit The image drum unit makes a toner adhere to the formed electrostatic latent image with static electricity.
  • Page 368 368 / 41309401TH Rev.4...

  • Page 369: Electro-Photographic Process

    Electro-Photographic Process (1) Electro-photographic process The electro-photographic process is outlined below. Charging Main Motor Electromagnetic Clutch Hopping Roller Regist Gear Drum Gear Operation Normal rotation Non-rotation Non-rotation Rotation Warm-up Rotation Rotation Rotation Hopping Reverse rotation Non-rotation Rotation Rotation Prinitng The surface of the OPC drum is charged negatively and uniformly by applying the DC voltage to the CH roller.
  • Page 370 370 / 41309401TH Rev.4...
  • Page 371 371 / 41309401TH Rev.4...

  • Page 372: Explanation Of Each Process Operation

    Explanation of Each Process Operation (1) Hopping As shown in the figure below, the clutch for hopping is turned on/off according to current ON/ OFF to a coil. When the clutch is OFF Spring for resetting Hopping gear Clutch plate Coil Magnetic substance plate...
  • Page 373 (2) Printing and warm-up At warm-up Triple gear Transfer gear Resist gear Idle gear Planetary gear a" a’ Hopping gear Gear A Pulse motor (main) Rotate the pulse motor (main) in the a direction. The planetary gear rotates in the a’ direc- tion, dislocating its position in the a”...
  • Page 374 (3) Charging Charging is performed by applying DC voltage to the charge roller that is in contact with the surface of the OPC drum. High- voltage Charge roller power supply Charge roller (4) Exposure Light emitted from the LED head irradiates the negatively charged surface of the OPC drum. The surface potential of the irradiated surface attenuates to form the electrostatic latent image corresponding to the image signal.
  • Page 375 (5) Development The electrostatic latent image on the surface of the OPC drum is changed to a visible toner image by applying a toner to it. Development is performed in the contact part between the OPC drum and developing roller. The sponge roller negatively charges a toner and applies it to the developing roller.
  • Page 376 (6) Transfer The transfer roller is composed of conductive sponge material. This roller is set so that the surface of the OPC drum and sheets of paper will adhere closely. A sheet of paper is placed on the surface of the OPC drum and the positive charge opposite to the negative charge of a toner is applied from the reverse side by the transfer roller.
  • Page 377 (7) Fusing The transferred unfused toner image is fused to a sheet of paper because heat and pressure are applied when it passes between the heat roller and back-up roller. The Teflon-coated heat roller contains a 400 W heater (Halogen lamp) that heats the heat roller.

  • Page 378: Paper Jam Detection

    Paper Jam Detection The OKIFAX4550/OKIFAX4550 ISDN monitors the paper status when the power supply is on and during printing. In the following cases, the OKIFAX4550/OKIFAX4550 ISDN interrupts the printing process as a paper jam. Printing can be recovered by opening the cover, removing the jammed paper, and closing the cover.
  • Page 379 Normal rotation Pulse motor (main) Reverse rotation Electromagnetic clutch Manual feed sensor Paper sensor Outlet sensor Warm-up Paper feed Printing Operation mode Timing Chart for Paper Feed (Tray Feed) 379 / 41309401TH Rev.4...

  • Page 380: Toner Low Detection

    Toner Low Detection • Hardware configuration of toner sensor The figure below shows the hardware configuration of the toner sensor. Image drum unit Agitation bar (iron) Magnet Toner sensor lever Photointerrupter Hardware Configuration of Toner Sensor • Toner detection method Toner sensor Magnet draw-in (1) Toner sensor monitoring conditions are shown in the figure below.

  • Page 381: Cover Open

    Cover Open Opening the stacker cover turns off the microswitch on the high-voltage power supply board to suspend +5 V supply to the high voltage power supply. This results in the stop of all high-voltage outputs. At the same time, the CVOPN signal is issued to notify the main control board of the switch status and cover open processing is executed.

  • Page 382: Appendix Ccircuit Diagrams

    APPENDIX C CIRCUIT DIAGRAMS 46F-PCB Circuit Diagram (1/13~13/13) (41196601SS) R46-PCB Circuit Diagram (1/15~15/15) (41033201SS) 04W-PCB Circuit Diagram (1/2~2/2) (40071401SS) EN9-PCB Circuit Diagram (1/2~2/2) (41144301SS) INU-PCB Circuit Diagram (1/1) (41144501SS) MPW1546 POW(120VAC) Circuit Diagram (1/1) (S1PS1303) MPW1446 POW(230VAC) Circuit Diagram (1/1) (S1PS1302) P2H-PCB Circuit Diagram (1/1) (40599101SS)
  • Page 383 46F-PCB Circuit Diagram (1/13) (41196601SS) 383 / 41309401TH Rev.4...
  • Page 384 46F-PCB Circuit Diagram (2/13) (41196601SS) 384 / 41309401TH Rev.4...
  • Page 385 46F-PCB Circuit Diagram (3/13) (41196601SS) 385 / 41309401TH Rev.4...
  • Page 386 46F-PCB Circuit Diagram (4/13) (41196601SS) 386 / 41309401TH Rev.4...
  • Page 387 46F-PCB Circuit Diagram (5/13) (41196601SS) 387 / 41309401TH Rev.4...
  • Page 388 46F-PCB Circuit Diagram (6/13) (41196601SS) 388 / 41309401TH Rev.4...
  • Page 389 46F-PCB Circuit Diagram (7/13) (41196601SS) 389 / 41309401TH Rev.4...
  • Page 390 46F-PCB Circuit Diagram (8/13) (41196601SS) 390 / 41309401TH Rev.4...
  • Page 391 46F-PCB Circuit Diagram (9/13) (41196601SS) 391 / 41309401TH Rev.4...
  • Page 392 46F-PCB Circuit Diagram (10/13) (41196601SS) 392 / 41309401TH Rev.4...
  • Page 393 46F-PCB Circuit Diagram (11/13) (41196601SS) 393 / 41309401TH Rev.4...
  • Page 394 46F-PCB Circuit Diagram (12/13) (41196601SS) 394 / 41309401TH Rev.4...
  • Page 395 46F-PCB Circuit Diagram (13/13) (41196601SS) 395 / 41309401TH Rev.4...
  • Page 396 R46-PCB Circuit Diagram (1/15) (41033201SS) 396 / 41309401TH Rev.4...
  • Page 397 R46-PCB Circuit Diagram (2/15) (41033201SS) 397 / 41309401TH Rev.4...
  • Page 398 R46-PCB Circuit Diagram (3/15) (41033201SS) 398 / 41309401TH Rev.4...
  • Page 399 R46-PCB Circuit Diagram (4/15) (41033201SS) 399 / 41309401TH Rev.4...
  • Page 400 R46-PCB Circuit Diagram (5/15) (41033201SS) 400 / 41309401TH Rev.4...
  • Page 401 R46-PCB Circuit Diagram (6/15) (41033201SS) 401 / 41309401TH Rev.4...
  • Page 402 R46-PCB Circuit Diagram (7/15) (41033201SS) 402 / 41309401TH Rev.4...
  • Page 403 R46-PCB Circuit Diagram (8/15) (41033201SS) 403 / 41309401TH Rev.4...
  • Page 404 R46-PCB Circuit Diagram (9/15) (41033201SS) 404 / 41309401TH Rev.4...
  • Page 405 R46-PCB Circuit Diagram (10/15) (41033201SS) 405 / 41309401TH Rev.4...
  • Page 406 R46-PCB Circuit Diagram (11/15) (41033201SS) 406 / 41309401TH Rev.4...
  • Page 407 R46-PCB Circuit Diagram (12/15) (41033201SS) 407 / 41309401TH Rev.4...
  • Page 408 R46-PCB Circuit Diagram (13/15) (41033201SS) 408 / 41309401TH Rev.4...
  • Page 409 R46-PCB Circuit Diagram (14/15) (41033201SS) 409 / 41309401TH Rev.4...
  • Page 410 R46-PCB Circuit Diagram (15/15) (41033201SS) 410 / 41309401TH Rev.4...
  • Page 411 04W-PCB Circuit Diagram (1/2) (40071401SS) 411 / 41309401TH Rev.4...
  • Page 412 04W-PCB Circuit Diagram (2/2) (40071401SS) 412 / 41309401TH Rev.4...
  • Page 413 EN9-PCB Circuit Diagram (1/2) (41144301SS) 413 / 41309401TH Rev.4...
  • Page 414 EN9-PCB Circuit Diagram (2/2) (41144301SS) 414 / 41309401TH Rev.4...
  • Page 415 INU-PCB Circuit Diagram (1/1) (41144501SS) 415 / 41309401TH Rev.4...
  • Page 416 POW (120VAC) Circuit Diagram (1/1) (MPW1546) 416 / 41309401TH Rev.4...
  • Page 417 POW (230VAC) Circuit Diagram (1/1) (MPW1446) 417 / 41309401TH Rev.4...
  • Page 418 P2H-PCB Circuit Diagram (1/1) (40599101SS) 418 / 41309401TH Rev.4...
  • Page 419 P6L-PCB Circuit Diagram (1/1) (40386701SS) 419 / 41309401TH Rev.4...
  • Page 420 G4N-PCB Circuit Diagram (1/7) (41033701SS) 420 / 41309401TH Rev.4...
  • Page 421 G4N-PCB Circuit Diagram (2/7) (41033701SS) 421 / 41309401TH Rev.4...
  • Page 422 G4N-PCB Circuit Diagram (3/7) (41033701SS) 422 / 41309401TH Rev.4...
  • Page 423 G4N-PCB Circuit Diagram (4/7) (41033701SS) 423 / 41309401TH Rev.4...
  • Page 424 G4N-PCB Circuit Diagram (5/7) (41033701SS) 424 / 41309401TH Rev.4...
  • Page 425 G4N-PCB Circuit Diagram (6/7) (41033701SS) 425 / 41309401TH Rev.4...
  • Page 426 G4N-PCB Circuit Diagram (7/7) (41033701SS) 426 / 41309401TH Rev.4...

  • Page 427: Appendix D Mechanical Expanded View Drawing And Parts List

    APPENDIX D MECHANICAL EXPANDED VIEW DRAWING AND PARTS LIST OKIFAX4550/OKIOFFICE87 ASSEMBLY SECTION 1 SECTION 9 SECTION 3, 4 SECTION 8 SECTION 2, 11, 12 SECTION 5, 6, 7 SECTION 10 OPTION TELEPHONE 427 / 41309401TH Rev.4...
  • Page 428 SECTION 1 CABINET ASSEMBLY (OKIFAX4550/OKIOFFICE87) 428 / 41309401TH Rev.4...
  • Page 429 Section 1 CABINET ASSEMBLY (OKIFAX4550/OKIOFFICE87) 1/2 Rev. Oki parts Number Description Q ty Remarks Unit-Printer Refer to Section 11 HOLDER-ASSY Refer to Section 11 4YA4116-1228G001 LED HEAD General specification-31B OKIFAX4550 40521101 LED HEAD Unit-51J OKIOFFICE87 41016104 Cable-Flat-Assy For OKIFAX4550 THAI production 4YX4083-1134G001 CABLE FLAT ASSY.
  • Page 430 Clamp-Cable OKIOFFICE87 * 2: If there are the parts stock, they can be used as spare parts for OKIFAX4550 UK production. Do not order with these parts number. * 3: This is the spare parts kit for OKIFAX4550 UK production.
  • Page 431 SECTION 2 UNIT-PRINTER 431 / 41309401TH Rev.4...
  • Page 432 Section 2 UNIT-PRINTER Rev. Oki parts Number Description Q ty Remarks Printer Unit Assembly See Section 11 40607401 H.V. Board P2H 40413401 Cover-HV Screw F 432 / 41309401TH Rev.4...
  • Page 433 SECTION 3 UNIT-051 OPE PANEL 433 / 41309401TH Rev.4...
  • Page 434 Section 3 UNIT-051 OPE PANEL Rev. Oki parts Number Description Q ty Remarks 41766901 OP Panel Assy. ODA/OEL/INT/TENOVIS 00032101 OP Panel Assy. OKI-INT/OEL 41766904 OP Panel Assy. LANIER 00032103 OP Panel Assy. LANIER 00032104 OP Panel Assy. BOSCH 40682804 Sheet-Function...
  • Page 435 SECTION 4 OPEPANEL (OPERATION PANEL) ASSEMBLY 435 / 41309401TH Rev.4...
  • Page 436 Section 4 OPE PANEL ASSEMBLY Rev. Oki parts Number Description Q ty Remarks Case-OPE(T) OKI, LANIER 40086701 Board-04W 40023001 Holder-LCD 40023101 Button-Function 2PP4120-1067P001 Ten Key (Round) 40023201 Button-Start OKI, TENOVIS 40023202 Button-Start LANIER 40023301 Button-Stop OKI, TENOVIS 40023302 Button-Stop LANIER...
  • Page 437 SECTION 5 FRAME ASSEMBLY-SCANNER (L) 437 / 41309401TH Rev.4...
  • Page 438 Section 5 FRAME ASSEMBLY-SCANNER L Rev. Oki parts Number Description Q ty Remarks Frame-Scanner (L) 40019401 Lever-PC1 40019501 Lever-PC2 40019601 Roller Assy.-ADF 40020201 Plate-Earth ADF 40020601 Piece-Exit 40020703 Spring-Exit 40127501 CONN Cord-Speaker 40141401 CONTACT IMAGE SENSOR-A4 300dpi 40644701 Film-Guide (CIS)
  • Page 439 SECTION 6 PLATE ASSEMBLY-SCANNER (B) 439 / 41309401TH Rev.4...
  • Page 440 Section 6 PLATE ASSEMBLY-SCANNER (B) Rev. Oki parts Number Description Q ty Remarks Plate-Scanner (B) 40135301 Photo-Interrupter 440 / 41309401TH Rev.4...
  • Page 441 SECTION 7 PLATE ASSEMBLY-SCANNER (R) 441 / 41309401TH Rev.4...
  • Page 442 Section 7 PLATE ASSEMBLY-SCANNER (R) Rev. Oki parts Number Description Q ty Remarks Plate-Scanner (R) 4YB4120-1036P001 S-Motor 151/175 B SCREW FA 442 / 41309401TH Rev.4...
  • Page 443 SECTION 8 FRAME ASSEMBLY-SCANNER (U) 443 / 41309401TH Rev.4...
  • Page 444 Section 8 FRAME ASSEMBLY-SCANNER (U) Rev. Oki parts Number Description Q ty Remarks Frame-Scanner (U) 4PP3527-5153P001 BACK-UP PLATE 40267001 SEPARATION RUBBER ASSEMBLY 40021401 Spring-Pinch (L) 40021501 Spring-Pinch (R) 40745801 Guide-Sensor (A) OKIFAX4550 40745802 Guide-Sensor (A) OKIOFFICE87 40021701 Guide-Sensor (B) OKIFAX4550...
  • Page 445 SECTION 9 COVER ASSEMBLY-TOP 445 / 41309401TH Rev.4...
  • Page 446 Section 9 COVER ASSEMBLY-TOP Rev. Oki parts Number Description Q ty Remarks Cover-Top 40606701 Holder-LED (A) Guide-Document (L) Guide-Document (R) 40022601 Spring-D 4PP4128-1268P001 PLATE EXIT 4PP4083-2024P001 EJECT ROLLER A 4PP4083-2328P003 PINION GEAR B CS RING B SCREW FA 446 /...
  • Page 447 SECTION 10 PLATE ASSEMBLY-BASE 447 / 41309401TH Rev.4...
  • Page 448 Section 10 PLATE ASSEMBLY-BASE Rev. Oki parts Number Description Q ty Remarks Plate-Base A Rubber Foot 40606901 Sheet-Insulation 40128001 Cord-Falt (FUJI CARD) Sheet-FG 448 / 41309401TH Rev.4...
  • Page 449 SECTION 11 PRINTER BASE FRAME UNIT Heat assy 449 / 41309401TH Rev.4...
  • Page 450 Pressure Roller B (Back Up Roller) 3PP4083-1233P001 Paper Guide (R) 3PP4083-1232P001 Paper Guide (L) 1PP4083-1231P001 Paper Holder 3PP4083-1192P001 Paper Sensor Exit 4PP4083-1247P001 Hopping Spring 40638001 Contact-CB 40638102 Conn, Cord-HV Screw 40625401 4PP4083-1137P001 Spring Pressure (R) *1 = Only for OKIFAX4550/OKIOFFICE87 450 / 41309401TH Rev.4...
  • Page 451 Section 11 PRINTER BASE FRAME UNIT 2/2 Rev. Oki parts Number Description Q ty Remarks 40562401 Sheet Guide 40592801 Heat Assy. 120V 40592802 Heat Assy. 230V 40034001 Stopper Spring 4PB4091-6047P001 Caution Label (TR) 230V 40688601 Washer-TR 40710301 Guide-Gear T 40634701...
  • Page 452 SECTION 12 PRINTER HEAT ASSY 452 / 41309401TH Rev.4...
  • Page 453 Section 12 PRINTER HEAT ASSY. Rev. Oki parts Number Description Q ty Remarks 3PB4083-1202P001 Heat Roller 41524001 Halogen Lamp 120V 41524002 Halogen Lamp 230V 4PB4083-1204P001 Thermostat 4PB4083-1205P001 Thermistor 4PB4083-1213P001 Heat Cord 453 / 41309401TH Rev.4...
  • Page 454 SECTION 13 CABLES 454 / 41309401TH Rev.4...
  • Page 455 Section 13 CABLES Rev. Oki parts Number Description Q ty Remarks 40635401 Connection Cord-Wire (AC) 40040001 Connection Cord-Wire (OPE) 40040201 Connection Cord-Wire (CIS) 40040301 Connection Cord-Wire (PC1/2) 105A1070C0003 TFC-20-10-10 Core CIS-46F or R46 105A1070C0004 TFC-23-11-14 Core CPE-46F or R46 105A1073C4002...

  • Page 456: Appendix Eboard Layout And Parts List

    APPENDIX E BOARD LAYOUT AND PARTS LIST 46F-PCB Assy (1/9~9/9) (41196601) R46-PCB Assy (1/10~10/10) (41033201) 04W-PCB Assy (1/3~3/3) (40071401) EN9-PCB Assy (1/6~6/6) (41144301) INU-PCB Assy (1/4~4/4) (41144501) INU-PCB Assy (1/5~5/5) (41144502) MPW1546 POW(120VAC) Assy (1/5~5/5) (S1PS1303) MPW1446 POW(230VAC) Assy (1/6~6/6) (S1PS1302) P2H-PCB Assy (1/4~4/4) (40599101)
  • Page 457 46F-PCB Assy (1/9) (41196601) 457 / 41309401TH Rev.4...
  • Page 458 46F-PCB Assy (2/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D1, D506 1SS392 (TE85R) 6110225N0001 D-Signal D508, D509, D511, D514 SS100MA80VACP 611A0000N0001 D-Signal D507, D510, D513 SS100MA80VKCP 611A0000N0002 D-Signal D2, D502 ~ D505, D512 SS100MA80VSCP 611A0000N0003 D-Signal D501 RD4.3M-B3 613A0233M0092C D-Zener 16ZM5-5...
  • Page 459 46F-PCB Assy (3/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R581, R503 CR/RK73H/ERJ/MCRF362 3235003F0362 RES-MET RN -C R508 CR/RK73H/ERJ/MCRF391 3235003F0391 RES-MET RN -C CR/RK73H/ERJ/MCRF393 3235003F0393 RES-MET RN -C R563 CR/RK73H/ERJ/MCRF472 3235003F0472 RES-MET RN -C R562, R501 CR/RK73H/ERJ/MCRF512 3235003F0512 RES-MET RN -C R39, R41, R42, R526, R527, CR/RK73H/ERJ/MCRF513 3235003F0513...
  • Page 460 46F-PCB Assy (4/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R535, R585, R632~R635, CR/RK73K/ERJ/MCRJ222 3235003J0222 R644 RES-MET RN -C R517, R518, R520 CR/RK73K/ERJ/MCRJ301 3235003J0301 RES-MET RN -C R578 CR/RK73K/ERJ/MCRJ331 3235003J0331 RES-MET RN -C R596, R597, R600, R601, CR/RK73K/ERJ/MCRJ332 3235003J0332 R607, R616, R617, R624, RES-MET RN -C R645 ~ R647...
  • Page 461 46F-PCB Assy (5/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C580 GRM/UMK/MCH/101CH 3033003C0101 CAP-Ceramic -C C590, C591, C646 GRM/UMK/MCH/150CH 3033003C0150 CAP-Ceramic -C C549 GRM/UMK/MCH/221CH 3033003C0221 CAP-Ceramic -C C563, C645 GRM/UMK/MCH/330CH 3033003C0330 CAP-Ceramic -C C564, C611 GRM/UMK/MCH/391CH 3033003C0391 CAP-Ceramic -C C648, C651 GRM/UMK/MCH/470CH 3033003C0470...
  • Page 462 46F-PCB Assy (6/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C552, C553 GRM/UMK/MCH/180CH 3033003C0180 CAP-Ceramic -C C508, C512 CC2012SL1H681J 303A3007K0681 CAP-Ceramic -C C654 CK2012F1C105Z 303A6008Z1105 CAP-Ceramic -C 1µF C505 CK2012F1C474Z 303A6008Z1474 CAP-Ceramic -C C586 CK2012F1H104Z 303A6008Z3104 CAP-Ceramic -C C3, C18 UVX/SME10VB-100-0A 3041103A1101 CAP-Alum(CE) -P...
  • Page 463 46F-PCB Assy (7/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 74HC00FP 702A1703N0000 Digital IC-MOS-S IC14 74HC126FP 702A1703N0126 Digital IC-MOS-S NJM386M 720A0028N0006 Analog-BIPLIN -S IC12 NJM4558M 720A0028N0039 Analog-BIPLIN -S IC13 NJM318E 720A0028N0113 Analog-BIPLIN -S IC18 UPC393G2 720A0523N0011 Analog-BIPLIN -S IC7, IC9 MTD2005FB 720A1816N0001 Analog-BIPLIN -S...
  • Page 464 46F-PCB Assy (8/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS LC1, LC2, LC5 MT-Y223NB 342A1013N0223 COMP PAR-LC- NL322522-100J-3 353A4007J0100 Coil-HF LHL08TB-103J 3531001J0103 Coil-HF TR506 2SA1162-Y 600A1025M0017Y TR-PNP/H FREQ-C TR513 2SA1338 600A1032N0010 TR-PNP/H FREQ-C 2SA950-Y 600A1125M0011Y TR-PNP/H FREQ- TR501, TR503, TR507 602A1025M0033 2SC2712-Y/G TR-PNP/H FREQ-C...
  • Page 465 46F-PCB Assy (9/9) (41196601) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS B2B-EH 224A3535P0020 Connector-PCB- CN12 ZC-014 224A3590P0140 Connector-PCB- 23FE-BT-VK-N 224A4134P0230 Connector-PCB- CN10 6-176135-6 224A4325P0500 Connector-PCB- HC-49/U03C-20.00MHz 3801001B0003 OSC-Crystal P-3-32.768KHZ 380A1201A0001 OSC-Crystal HC-49/U03C-28.224MHz 3801001B0005 OSC-Crystal BAT1 455A3027P0001 CR2430-FT6 BATT-Primary - F501 431001 5402200S0102 FUSE -C...
  • Page 466 R46-PCB Assy (1/10) (41033201) 466 / 41309401TH Rev.4...
  • Page 467 R46-PCB Assy (2/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D510 1SS392 (TE85R) 6110225N0001 D-Signal D506, D509 SS100MA80VACP 611A0000N0001 D-Signal D3 ~ D5, D501, D508 SS100MA80VSCP 611A0000N0003 D-Signal D6, D502 ~ D505, D507 SB007T03C 611A0232N0002 D-Signal RD4.7M-B2 613A0233M0102B D-Zener R525, R550 CR/RK73H/ERJ/MCRF102 3235003F0102...
  • Page 468 R46-PCB Assy (3/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R519 CR/RK73H/ERJ/MCRF362 3235003F0362 RES-MET RN -C R507 CR/RK73H/ERJ/MCRF391 3235003F0391 RES-MET RN -C R2, R7, R513, R514 CR/RK73H/ERJ/MCRF513 3235003F0513 RES-MET RN -C R25, R26, R506 CR/RK73H/ERJ/MCRF563 3235003F0563 RES-MET RN -C R509, R594 CR/RK73H/ERJ/MCRF623 3235003F0623...
  • Page 469 R46-PCB Assy (4/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R522, R548, R554, R555, CR/RK73K/ERJ/MCRJ472 3235003J0472 R564, R565, R589 RES-MET RN -C R23, R30, R53, R58, R59, CR/RK73K/ERJ/MCRJ473 3235003J0473 R78, R82, R83, R89, R92, RES-MET RN -C R98, R517, R535, R546, R547, R559 ~ R561, R567 ~ R569, R574, R579, R599 ~ R602...
  • Page 470 R46-PCB Assy (5/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RM1, RM2, RM8 ~ RM11, CN1J4/EXBV8V0Ω 3345003P0001 RM17 ~ RM20 RES-Block C28, C557 GRM/UMK/MCH/101CH 3033003C0101 CAP-Ceramic -C C565, C566 GRM/UMK/MCH/150CH 3033003C0150 CAP-Ceramic -C C546, C547 GRM/UMK/MCH/180CH 3033003C0180 CAP-Ceramic -C C13, C27, C536, C569, GRM/UMK/MCH/221CH 3033003C0221...
  • Page 471 R46-PCB Assy (6/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C4, C16, C30 ~ C32, C39 ~ GRM/TMK/MCH/104Z 25V 3036003Z0104 C42, C44, C503, C504, CAP-Ceramic -C C506, C509, C512, C514, C517 ~ C520, C523, C525 ~ C528, C530, C534, C537, C538, C540, C541, C543, C544, C549, C551, C552, C555, C556, C560, C563,...
  • Page 472 R46-PCB Assy (7/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS TC223G12CF-7001(Z) 7024925N0015 Digital IC-MOS-F IC21 74HC08FP 702A1703N0008 Digital IC-MOS-S IC15 74HC14FP 702A1703N0014 Digital IC-MOS-S IC14 74HC126FP 702A1703N0126 Digital IC-MOS-S IC24 74HC175FP 702A1703N0175 Digital IC-MOS-S IC22 NR8576AB 7201540N0001 Analog-BIPLIN -S IC11 NJM386M 720A0028N0006...
  • Page 473 R46-PCB Assy (8/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS MT-SL330KB 342A1013K0330 COMP PAR-LC- LC1, LC2, LC5 MT-Y223NB 342A1013N0223 COMP PAR-LC- BF501, LC3, LC4, R75, R76 ACB1608M-300-T 3775001P0001 Filter-PW line -C LHL08TB-181K 3531001K0181 Coil-HF L2, L3 NL322522-100J-3 353A4007J0100 Coil-HF LHL08TB-103J 3531001J0103 Coil-HF...
  • Page 474 R46-PCB Assy (9/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 06FE-ST-VK-N 2244101P0060 Connector-PCB- 00-8263-0212-00-000 224A3357P0020 Connector-PCB- CN1, CN13 00-8263-0412-00-000 224A3357P0040 Connector-PCB- S6B-PH-K-S 224A3531P0060 Connector-PCB- S10B-PH-K-S 224A3531P0101 Connector-PCB- S16B-PH-K-S 224A3531P0160 Connector-PCB- B2B-EH 224A3535P0020 Connector-PCB- 23FE-BT-VK-N 224A4134P0230 Connector-PCB- CN10 6-176135-6 224A4325P0500 Connector-PCB- HC-49/U03C-20.00MHz 3801001B0003...
  • Page 475 R46-PCB Assy (10/10) (41033201) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS Screw PSW3-4C 475 / 41309401TH Rev.4...
  • Page 476 04W-PCB Assy (1/3) (40071401) 476 / 41309401TH Rev.4...
  • Page 477 04W-PCB Assy (2/3) (40071401) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D1 ~ D8 1S953/1S2075K/1S2473 611A0003L0001 D-Signal GL3HD8 650A0128M0030 PHOTO-LED L2 ~ L7, L9 GL3HY8 650A0228M0010 PHOTO-LED RD1/4Y10ΩJ 321A1421J0100 RES-Carbon fim- R22 ~ R25 RD1/4Y100ΩJ 321A1421J0101 RES-Carbon fim- RD1/4Y150ΩJ 321A1421J0151 RES-Carbon fim- R4 ~ R9, R11 RD1/4Y220ΩJ...
  • Page 478 04W-PCB Assy (3/3) (40071401) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C5, C38 DD104B221K50V 302A4011K3221 CAP-Ceramic - C22, C23 CK92C1H471MS 303A4115M3471 CAP-Ceramic - C33 ~ C35 RD16XR/CK92C1H102 303A4003M3102 CAP-Ceramic -P CK92C1H472MS 303A4115M3472 CAP-Ceramic - 50MS5-0.68M 304A1046H1688 CAP-Alum (CE) KME25VB-47 304A1115E1470 CAP-Alum (CE) M38002M2-289SP 8530183M0005...
  • Page 479 EN9-PCB Assy (1/6) (41144301) 479 / 41309401TH Rev.4...
  • Page 480 EN9-PCB Assy (2/6) (41144301) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS AR1, AR2 SRH412-501MFT 5431004G0501 ARRESTER- -P ECQ-E2474KF 250V 306A2221K5474 CAP-Plast flm - SME10VB-100BP-0A 10V 304A1122A1101 CAP-Alum(CE) - TC04RSME50VB4R7MF50 3041010H1479 CAP-Alum(CE) -P C5, C9 ECQB1473JF3 100V 3062002J2473 CAP-Plast flm -P UVP2A2R2 100V 3041203A2229 CAP-Alum(CE) -P...
  • Page 481 EN9-PCB Assy (3/6) (41144301) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C521 CK2012B1H102K 303A6008K3102 CAP-Ceramic -C CN1, CN2 52830-6625/TM5RE2VX 2233003P0001 Connector-Plug- 2-176837-4 224A4335P0500 Connector-PCB- D1, D2 RD20E-B 613A1231L0252 D-Zener RD6.2F-B 613A2232L0132 D-Zener RD5.1E-B2 613A1231L0112B D-Zener E-152 611A0037L0011 D-Zener D6, D7 RD3.9E-B2 613A1231L0082B D-Zener...
  • Page 482 EN9-PCB Assy (4/6) (41144301) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS LHL08TB-682J 3531001J0682 Coil-HF LHL08TB-222J 3531001J0222 Coil-HF 2SD1209K 603A1121M0010 TR-NPN/L-FREQ- Q502 2SA1727/2SA1700-TL 6001103N0002 TR-NPN/L-FREQ-C Q503 2SA1384-0(TE12L,C) 6001025N0002 TR-NPN/L-FREQ-C R503 3235003J0152 CR/RK73K/ERJ/MCRJ152 RES-MET RN -C R505 RM73B2A303J 323A5003J0303 RES-MET RN -C R506 CR/RK73K/ERJ/MCRJ243 3235003J0243...
  • Page 483 EN9-PCB Assy (5/6) (41144301) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R529 CR/RK73K/ERJ/MCRJ104 3235003J0104 RES-MET RN -C R531 CR/RK73K/ERJ/MCRJ102 3235003J0102 RES-MET RN -C R532 ~ R535 CR/RK73K/ERJ/MCRJ683 3235003J0683 RES-MET RN -C R537 ~ R540 CR/RK73K/ERJ/MCRJ472 3235003J0472 RES-MET RN -C R542 CR/RK73K/ERJ/MCRJ183 3235003J0183 RES-MET RN -C...
  • Page 484 EN9-PCB Assy (6/6) (41144301) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS P-97 230A6021P0002 CONN PAR- ERZV10D680 6320229M0025 SEMICO-Vari - ERZV07D220 6320229M0011 SEMICO-Vari - LY-6314-1-GN L=10mm 484 / 41309401TH Rev.4...
  • Page 485 INU-PCB Assy (41144501)-US (1/4) (41144502)-INT (1/5) 485 / 41309401TH Rev.4...
  • Page 486 INU-PCB Assy (2/4) (41144501)-US REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS AR1, AR2 SRH412-501MFT 5431004G0501 ARRESTER- ECQ-E2474KF 250V 306A2221K5474 CAP-Plast flm SME10VB-100BP-0A 10V 304A1122A1101 CAP-Alum(CE) UVR1H2R2 50V 3041003H1229 CAP-Alum(CE) ECQB1473JF3 100V 3062002J2473 CAP-Plast flm UVP2A2R2 100V 3041203A2229 CAP-Alum(CE) C501 CK2012R1H223K 50V 303A6008K3223 CAP-Ceramic CN1, CN2...
  • Page 487 INU-PCB Assy (3/4) (41144501)-US REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS PS2525-1/TLP320 6520103M0002 PHOTO-Coupler IC606 LB1233M-TE-L 7600031N0701 ARRAY-TR 2SD1209K 603A1121M0010 TR-NPN/L-FREQ Q501 DTC323TK/RN1444-B 6021003N0003 TR-NPN/H-FREQ R502 CR/RK73K/ERJ/MCRJ222 3235003J0222 RES-MET RN R503 CR/RK73K/ERJ/MCRJ152 3235003J0152 RES-MET RN R505 RM73B2A303J 323A5003J0303 RES-MET RN R506, R521 CR/RK73K/ERJ/MCRJ203 3235003J0203...
  • Page 488 INU-PCB Assy (4/4) (41144501)-US REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RL1 ~ RL3, RL5 AJQ1349 2601009P1000 Relay-General AHY109/SY-5W-K 2601103P1000 Relay-General SR-422 3613000P0001 TFORMER-LF P-97 230A6021P0002 CONN PAR- ERZV10D680 6320229M0025 SEMICO-Vari ERZV07D220 6320229M0011 SEMICO-Vari S1 ~ S32 SHORT WIRE TA-0.6 L=55mm 488 / 41309401TH Rev.4...
  • Page 489 INU-PCB Assy (2/5) (41144502)-INT REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS AR1, AR2 SRH412-501MFT 5431004G0501 ARRESTER- C1, C101 ECQ-E2474KF 250V 306A2221K5474 CAP-Plast flm SME10VB-100BP-0A 10V 304A1122A1101 CAP-Alum(CE) UVR1H2R2 50V 3041003H1229 CAP-Alum(CE) ECQB1473JF3 100V 3062002J2473 CAP-Plast flm UVP2A2R2 100V 3041203A2229 CAP-Alum(CE) C501 CK2012R1H223K 50V 303A6008K3223...
  • Page 490 INU-PCB Assy (3/5) (41144502)-INT REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS PC123YS/TLP621 6520103M0001 PHOTO-Coupler IC2, IC3 PS2532-1/TLP627 6523103M0003 PHOTO-Coupler PS2525-1/TLP320 6520103M0002 PHOTO-Coupler IC606 LB1233M-TE-L 7600031N0701 ARRAY-TR 2SD1209K 603A1121M0010 TR-NPN/L-FREQ Q501 DTC323TK/RN1444-B 6021003N0003 TR-NPN/H-FREQ R502 CR/RK73K/ERJ/MCRJ222 3235003J0222 RES-MET RN R503 CR/RK73K/ERJ/MCRJ152 3235003J0152 RES-MET RN R505...
  • Page 491 INU-PCB Assy (4/5) (41144502)-INT REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R519 CR/RK73H/ERJ/MCRF153 3235003F0153 RES-MET RN R520 CR/RK73H/ERJ/MCRF223 3235003F0223 RES-MET RN R544 CR/RK73H/ERJ/MCRF271 3235003F0271 RES-MET RN R545 CR/RK73H/ERJ/MCRF681 3235003F0681 RES-MET RN R546 CR/RK73H/ERJ/MCRF183 3235003F0183 RES-MET RN R601 MCR100JZH J303 3235040J0303 RES-MET RN R602 MCR100JZH J430...
  • Page 492 INU-PCB Assy (5/5) (41144502)-INT REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS ERZV07D220 6320229M0011 SEMICO-Vari S1 ~ S32 SHORT WIRE TA-0.6 L=55mm 492 / 41309401TH Rev.4...
  • Page 493 MPW1546 (120V)-PCB Assy (1/5) (SIPS1303) 493 / 41309401TH Rev.4...
  • Page 494 MPW1546 (120V)-PCB Assy (2/5) (SIPS1303) REF. SYMBOL TYPE/NAME Q'TY REMARKS D11 ~ D14, D131 DIODE FUJI ELECTRIC CO., LTD. ERA15-06 D101 DIODE FUJI ELECTRIC CO., LTD. YG911S2 D102 DIODE FUJI ELECTRIC CO., LTD. YG811S06R D4, D7 DIODE ROHM CO., LTD. 1SS133 D103 DIODE...
  • Page 495 MPW1546 (120V)-PCB Assy (3/5) (SIPS1303) REF. SYMBOL TYPE/NAME Q'TY REMARKS TRANSIENT VOLTAGE FUJI ELECTRIC CO., LTD. EN241 SURGE SUPPRESSOR NOT MOUNTED NTC1 NTC THERMISTOR MURATA MFG CO., LTD. NTH7D4R0 RESISTOR 1/4W 10Ω RESISTOR 1/4W 22Ω RESISTOR 1/4W 68Ω RESISTOR 1/4W 150Ω R114, R150 RESISTOR 1/4W 220Ω...
  • Page 496 MPW1546 (120V)-PCB Assy (4/5) (SIPS1303) REF. SYMBOL TYPE/NAME Q'TY REMARKS RESISTOR 1/4W 18KΩ RESISTOR 1/4W 22KΩ RESISTOR 1/4W 33KΩ RESISTOR 1/4W 390KΩ RESISTOR 1/6W 10Ω R4, R7, R12, R51, R52, R121, NOT MOUNTED R160 VR151 RESISTOR 1/10W 5KΩ C11, C13 CERAMIC CAPACITOR MURATA MFG.
  • Page 497 MPW1546 (120V)-PCB Assy (5/5) (SIPS1303) REF. SYMBOL TYPE/NAME Q'TY REMARKS ELECTROLYTIC CAPACITOR 200V 220µF C4, C15, C20, C21, C101, NOT MOUNTED C102, C122, C151 INDUCOTR MATSUSHITA ELECTRIC ELF15N006 INDUSTRIAL CO.,LTD L101 INDUCOTR MURATA MFG. CO., LTD. 150S TRANSFORMER MURATA MFG. CO., LTD. 2C45 BEA1 FERRITE BEADS...
  • Page 498 MPW1446 (230V)-PCB Assy (1/6) (SIPS1302) 498 / 41309401TH Rev.4...
  • Page 499 MPW1446 (230V)-PCB Assy (2/6) (SIPS1302) REF. SYMBOL TYPE/NAME Q'TY REMARKS C11 ~ C14, C131 DIODE FUJI ELECTRIC CO., LTD. ERA15-06 D102 DIODE FUJI ELECTRIC CO., LTD. YG811S06R D101 DIODE FUJI ELECTRIC CO., LTD. YG911S2R D6, D7, D107 ~ D110 DIODE ROHM CO., LTD.
  • Page 500 MPW1446 (230V)-PCB Assy (3/6) (SIPS1302) REF. SYMBOL TYPE/NAME Q'TY REMARKS IC151 INTEGRATED CIRCUIT TOSHIBA CORP. INTERNATIONAL TA76431 OPERATIONS-Electronic Components INTEGRATED CIRCUIT MURATA MFG CO., LTD. H8D2877 PC1, PC2 OPTICAL ISOLATER SHARP Corp. Electronic Components Group PC123 OPTICAL ISOLATER SHARP Corp. Electronic Components Group S21ME6 TRANSIENT VOLTAGE FUJI ELECTRIC CO., LTD.
  • Page 501 MPW1446 (230V)-PCB Assy (4/6) (SIPS1302) REF. SYMBOL TYPE/NAME Q'TY REMARKS R107 RESISTOR 1/4W 3.3KΩ R101, R109, R152, R155 ~ RESISTOR R158 1/4W 4.7KΩ R102, R153 RESISTOR 1/4W 6.8KΩ R154 RESISTOR 1/4W 8.2KΩ R108, R110, R116 RESISTOR 1/4W 10KΩ R11, R12 RESISTOR 1/4W 12KΩ...
  • Page 502 MPW1446 (230V)-PCB Assy (5/6) (SIPS1302) REF. SYMBOL TYPE/NAME Q'TY REMARKS C9, C13 CERAMIC CAPACITOR MURATA MFG CO., LTD. 50V 100pF C104, C150 CERAMIC CAPACITOR MURATA MFG CO., LTD. 50V 0.1µF C7, C15 CERAMIC CAPACITOR MURATA MFG CO., LTD. VA3 3300pF CERAMIC CAPACITOR MURATA MFG CO., LTD.
  • Page 503 MPW1446 (230V)-PCB Assy (6/6) (SIPS1302) REF. SYMBOL TYPE/NAME Q'TY REMARKS BEA101 FERRITE BEADS MURATA MFG. CO., LTD. F102 FUSE WICKMANN-WERKE GMBH AC125V 2.0A (19396) F103 FUSE WICKMANN-WERKE GMBH AC250V 0.2A (19396) FUSE LITTELFUSE INC. AC250V T4.0AH (215) CONNECTOR MOLEX INC. 5277-02A CN101 CONNECTOR...
  • Page 504 P2H-PCB Assy (1/4) (40599101) 504 / 41309401TH Rev.4...
  • Page 505 P2H-PCB Assy (2/4) (40599101) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D60, D61, D68, D69 1S953/1S2075K/1S2473 611A0003L0001 D-Signal D63, D67, D72, D74 OR-DHM/ESJA/SHV-06 40681301 D51, D55 ~ D59, D62, D71, EU02A/RL105F-F 6100003M0001 D-Rectifying 1ZB300-Y-Z 613A2003M0001 D-Zener D65, D66 1ZB390 613A2258M0350 D-Zener RD22E-B2 613A1231L0262B...
  • Page 506 P2H-PCB Assy (3/4) (40599101) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R100 RD1/4Y3MΩJ 321A1421J0305 RES-Carbon flm - R115 RNL1/4C3F576KΩ 323A1222F5763 RES-MET RN - R114, R236 MRH100MK/HV-38-100MK 3263103K0107 RES-MET solid- R237 RD1/4Y5.1ΩJ 321A1421J0519 RES-Carbon flm - R238 RD16UJ1.5KΩ 3213420J0152 RES-Carbon flm - C105, C107, C119, C240, HNY5P/DE07-1KV-471K 3024003K7471...
  • Page 507 P2H-PCB Assy (4/4) (40599101) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS C-14576/SA-8506183 3502003P0102 Coil-Choke T2 ~ T4 HIGH VOLTAGE TRANSFORMER YB4049-7078P003 PS1 ~ PS4 RPI-574/#9568 652A0103M0002 PHOTO-Coupler - CVSW SM05S/SS5GL13 2071003P0001 Switch-Micro - SEL3910D/204AD 6500003M0001 PHOTO-LED - 23FE-BT-VK-N 224A4134P0230 Connector-PCB 53254-0210 224A4407P0020 Connector-PCB...
  • Page 508 P6L-PCB Assy (1/3) (40386701) 508 / 41309401TH Rev.4...
  • Page 509 P6L-PCB Assy (2/3) (40386701) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS D1, D8 EU02A/RL105F-F 6100003M0001 D-Rectifying D2, D3, D9 OR-DHM/ESJA/SHV-06 40681301 ERZV05D391 6320229M0003 SEMICO-Vari - D5 ~ D7 ERZ/JVR-05N471 6320003M0001 SEMICO-Vari - R1, R4 ~ R6 RD16U/VTJ5.1KΩ 3213420J0512 RES-Carbon flm - RD1/4Y1MΩJ 321A1421J0105 RES-Carbon flm -...
  • Page 510 P6L-PCB Assy (3/3) (40386701) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS RT-01T-1.0B 2247000P0001 Connector-PCB 510 / 41309401TH Rev.4...
  • Page 511 G4N-PCB Assy (1/5) (41033701) 511 / 41309401TH Rev.4...
  • Page 512 G4N-PCB Assy (2/5) (41033701) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS 2-176837-4 224A4335P0500 Connector-PCB TM5RJ-88 2233010P0001 Connector-Plug C3, C6 KMG10VB-470M-FC 304A1180A1471 CAP-Alum(CE) UVX/SME25VB-22-0A 3041103E1220 CAP-Alum(CE) C500, C501 GRM/UMK/MCH/050CH 3033003C0050 CAP-Ceramic C538 GRM/UMK/MCH/220CH 3033003C0220 CAP-Ceramic C539 GRM/UMK/MCH/270CH 3033003C0270 CAP-Ceramic C593, C594 GRM/UMK/MCH/470CH 3033003C0470 CAP-Ceramic...
  • Page 513 G4N-PCB Assy (3/5) (41033701) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R579 CR/RK73H/ERJ/MCRF303 3235003F0303 RES-MET RN R609 CR/RK73H/ERJ/MCRF622 3235003F0622 RES-MET RN R607 CR/RK73H/ERJ/MCRF621 3235003F0621 RES-MET RN R593, R594 CR/RK73K/ERJ/MCRJ102 3235003J0102 RES-MET RN R189 CR/RK73K/ERJ/MCRJ105 3235003J0105 RES-MET RN R589 CR/RK73K/ERJ/MCRJ152 3235003J0152 RES-MET RN R102 CR/RK73K/ERJ/MCRJ181...
  • Page 514 G4N-PCB Assy (4/45) (41033701) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS R107~R109, R147~R150, CR/RK73Z/ERJ/MCRJ-0V 3255003P0001 R161, R163, R165, R167, RES-0Ω R169, R171, R173, R175, R187, R208~R215, R523, R583~R586, R597~R600, R602~R605, R705, R707~ R718 RM1~RM9 CN1J4/EXBV8V22ΩJ 3345003J0220 RES-Block RM12, RM13 CN1J4/EXBV8V47KΩJ 3345003J0473 RES-Block D500~D506...
  • Page 515 G4N-PCB Assy (5/5) (41033701) REF. SYMBOL TYPE/NAME PART NO. Q'TY REMARKS HD6437034AE08F 8530432N0005 CPU-MOS (ROM) OSC1 HC-49/U03C-19.66MHz 3801001B0002 OSC-Crystal OSC2 HC-49/U03C-12.288MHz 3801001B0001 OSC-Crystal LC1, LC2 MT-Y223NB 342A1013N0223 COMP PAR-LC PE-65795 3655000P0001 TFORMER-Pulse L2, L3 LHL10-102J 353A1013J0102 Coil-HF 515 / 41309401TH Rev.4...

  • Page 516: Appendix Fpc-Loading

    PC-LOADING General Application This specification applies to the OKIFAX4550/OKIOFFICE87, an MFP unit capable of two-way communication using the parallel port as its standard feature. General This specification describes the details of PC loading through the Centro connector provided in the OKIFAX4550/OKIOFFICE87.

  • Page 517: Basic Operation

    Basic Operation Supported Functions The PC loading functions described herein are as follows. Functions equivalent to those used in the existing HSLS (High Speed Loading System) are supported. Default data area loading function Language area loading function Flash memory area program loading function These PC loading functions are supported only when the OS used on the PC side is either MS-DOS Ver.

  • Page 518: Pc Loading Procedure

    PC Loading Procedure PC Loading upon Memory Error Occurrence 3.1.1 Explanation on Procedure The PC loading procedure when the LCD on the MFP displays “MEMORY ERROR” for a hash NG state due to one reason or another is explained below. (1) Activate the MS(PC)-DOS with the host PC and the MFP connected via the Centro cable.

  • Page 519: Pc Loading By Manual Operation

    PC Loading by Manual Operation 3.2.1 Explanation on Procedure Loading shall be performed as shown below when the PC loading function is selected by key operation by a service man. (1) Activate the MS(PC)-DOS with the host PC and the MFP connected via the Centro cable. (2) Input the copy command from the MS(PC)-DOS on the PC to output the loading data file in binary specification to the LPT1 in order to transfer the loading data to the MFP.

  • Page 520: Operation Flow

    3.2.3 Operation Flow TECH. PROGRMMING YES(←/1-5) NO(→) ← key → key 14:14 [FAX] 1:LOCAL TEST YES(←) NO(→/1-6) ← key → key Local test 2:TECHNICAL FUNCTION YES(←) NO(→/1-6) ← key → key Setting by 3:SYSTEM RESET service man YES(←) NO(→/1-6) ← key →...

  • Page 521: Lcd Messages

    LCD Messages The LCD message in each operation state is shows below. Note that each message does not vary with the default type or language type. (1) Upon transition to PC loading function Transition by manual operation PC-LOADING Transition by a memory error MEMORY ERROR (2) During data receiving before loading end buzzer sounding PC-LOADING...

  • Page 522: Buzzer Sounding Patterns

    Buzzer Sounding Patterns The buzzer sounding patterns for various cases are shown below. In each case, the buzzer frequency is 2,400 Hz and the sound volume is maximum. Upon Start of PC Loading Upon Normal End Upon Error Occurrence The following sounding patterns are provided for indicating various error causes. Intermittent sounding is repeated until the MFP power is turned off.

  • Page 523: List Of Error Causes And Corresponding Codes

    List of Error Causes and Corresponding Codes The table below lists the error causes likely to occur during PC loading and the corresponding codes. When an error occurs, the corresponding error code is displayed, the buzzer sounds in the corresponding pattern and transition to the permanent loop state occurs. (See Note 1.) See “4.

  • Page 524: Cautions

    MFP power off until the buzzer indicating the end of MFP loading sounds. Loading Processing Time The processing time for reloading in the whole OKIFAX4550/OKIOFFICE87 area (program 1, language and default) is shown below. Use the value only as reference since the transfer time varies with each type of PC.

  • Page 525: Appendix Grmcs System Manual (For Model 40)

    APPENDIX G RMCS SYSTEM MANUAL (For Model 40) Notes to RMCS user Introduction RMCS stands for the Remote Management Center System. The purpose of this system is to speed up customer service and reduce maintenance costs. 1.2. System Configuration of RMCS MODEL40 System configuration of RMCS Model 40 is shown below.

  • Page 526: Quick Set-Up Manual For Rmcs Model 40

    Quick Set-up manual for RMCS Model 40 RMCS Installation Insert the disk to set up the RMCS in the drive. Start up Installer. Execute installation by following the SETUP screen. * You can set an operator password during Install. * You can skip password registration. * You can use up to 15 alphanumeric characters to set up a password.

  • Page 527: System Main Screen

    SYSTEM Main Screen Screen Titles Once the RMCS for Win is booted, the System Main screen appears. The titles used in the System Main screen are explained next. Title Bar: Displays the folder names that are displayed on the User Display window. Menu Bar: Displays the menu that executes the various functions.

  • Page 528: Disk By Models

    DISK by Models 4.2.1 Adding Models You must run Install by using the DISK by the models and add models to run maintenance on the facsimile devices. The procedure is explained next. (1) Insert the DISK by the facsimile models in the drive. (2) Select [Install] on the [FAX] menu.
  • Page 529 4.3.2 Selecting User Information To select the user information subject to maintenance so as to move to the Model OFFLINE screen. Select the user information on which you want to run maintenance at the User Display window. Select [Select] on the [User] menu. * You can select by right clicking at the All Users window.

  • Page 530: Model Main Screen

    Model Main Screen Screen Title When User Information is selected at the RMCS for Win SYSTEM Main screen, the Model Main screen appears. The Model Main screen is explained next. Title Bar: To display the facsimile model name Menu Bar: To display the menu at which each function is executed Area to display user information and operator information: To display user information and operator IDs to set/display/edit...
  • Page 531 5.2.1 Loading To load file-format data from the RMCS (maintenance work PC) to the target FAX device. The data in the target FAX device is replaced with the loaded data. Select items to load at the [File[LOAD(→FAX)]] sub-menu on the [Remote Operation] menu. All data User data Serviceman data...
  • Page 532 5.2.4 Initializing To initialize the contents of registration of the target FAX device by sending the initialization command to the target FAX device from the RMCS (Maintenance work PC). (1) Select an item to initialize at the [Initialization of FAX] sub-menu on the [Remote Operation] menu.

  • Page 533: Appendix H Okifax4550/Okioffice87 Troubleshooting Manual

    APPENDIX H OKIFAX4550/OKIOFFICE87 TROUBLESHOOTING MANUAL General This manual shall be used to identify the failure cause when a failure of the board is detected as a result of recovery through board replacement, etc. Therefore, the solder failure, pattern failure, part mounting failure are excluded.

  • Page 534: R46 Board (Okioffice87)

    R46 Board (OKIOFFICE87) Description Remarks See: Memory error LCD display or test print NG Figures H.1 (1/4~4/4) Reading running system NG Document feed error, etc. Figure H.2 Read image data NG All white, all black, image disturbance, etc. Figures H.3 (1/2, 2/2) Heater NG Printer alarm 4, etc.

  • Page 535: Description

    Description 46F Board (OKIFAX4550) 4.1.1 Memory error 1: Memory error Note1: When RAM-NG appears on the test print Error displayed on LCD (See Note 1.) Waveforms of pins 11, 26 , 28 of FLS are similar to Figures H.1(1/4, 2/4)

  • Page 536: Reading Running System Ng

    4.1.2 Reading running system NG 2: Reading running system NG (document feed error) Motor does not start when the document is fed to PC1 Pin 81 of IC2 becomes "L" when the document is inserted to PC1 Motor does not stop when the document is fed to Pin 12 of IC14 becomes "L"...

  • Page 537: Read Image Data Ng

    4.1.3 Read image data NG 3: Read image data NG Sensor LED is lit 5V input to pin 2 of TR505 when the sensor is lit Voltage of pin 3 of TR1 comes down approximately 0.7 V than pin 1 when the sensor is lit Replace IC16.

  • Page 538: Heater Ng

    4.1.4 Heater NG 4: Heater NG (printer alarm 4) Pin 27 of IC2 repeated 5V and 0V ON/OFF during printing Replace IC2. Pin 1 results in 5V output when approximately 3V is input to pin 3 of IC18 Replace IC18. Pin 3 becomes lower than 1V when 5V is input to pin 2 of TR502...
  • Page 539 4.1.5 Recording paper running system NG 5: Recording paper running system NG Recording paper feed is NG Motor is started? Pin 2 of TR512 changes from 0V to 5V when recording paper is fed Input waveforms of pins 17, 26 of IC9 are similar to Figures H.4(1/2, 2/2) Replace IC2.

  • Page 540: Printed Image Data Ng

    4.1.6 Printed image data NG 6: Printed image data NG Printed image is All black or all white Signals of pins 25, 29, 30 of IC2 are similar to Figures H.5(2/6, 3/6, 4/6) during printing Positive after-image provided Signals of pins 33, 35 of IC2 change between 0V and 5V cyclically during printing Waveforms are similar...

  • Page 541: Sending Ng

    4.1.7 Sending NG 7: Sending NG Call origination is impossible Call origination mode is (DP or PB) Pin 2 of IC2 repeats 5V and 0V cyclically during DP call origination Protocol signal receiving is NG Replace IC2. During protocol signal receiving, sine wave or modulated sine wave input is provided between pins 2 and 3 of IC12...

  • Page 542: Receiving Ng

    4.1.8 Receiving NG 8: Receiving NG RING signal cannot be detected 5V and 0V are alternately input to pin 9 of IC14, synchronized with the RING signal Pin 195 of IC2 repeats 5V and 0V cyclically, synchronized Check CN10. with the RING signal Protocol signal receiving is NG Replace IC14.

  • Page 543: Clock Ng

    4.1.9 Clock NG 9: Clock NG Clock display is NG All other operation display are OK Memory check is OK (memory error does not displayed on operation panel) See the operation See the memory error. interface error. Time error Battery voltage at 2.5V or higher Replace the battery.

  • Page 544: No Sound From The Speaker

    4.1.10 No sound from the speaker 10: No sound from the speaker Monitor Monitor or buzzer buzzer Communication normal Sine wave or modulated wave input is provided at pin 13 of IC11 during communication See sending or receiving NG. Replace TR501. Pulse wave input is provided at pin 5 of IC11 when the key is pressed or the soft...

  • Page 545: Pc/If Not Operating Correctly

    4.1.11 PC/IF not operating correctly 11: PC/IF does not operate correctly Pin 11 of CN11 (BUSY-P) is near 0V Pin 11 of IC20 is near 0V Replace IC20. Replace IC2. Waveform of pin 1 of CN11 (STB-N) is similar to Figure H.7(2/2) Check CN11 connection.
  • Page 546 4.1.12 Operation interface not operating correctly 12: Operation interface does not operate correctly Pin 77 of IC2 remains at 0V Pin 79 of IC2 remains at 0V or 5V Pin 5 of IC15 remains at 0V or 5V Check CN4 Replace IC15.

  • Page 547: R46 Board (Okioffice87)

    R46 Board (OKIOFFICE87) 4.2.1 Memory error 1: Memory error Note1: When RAM-NG appears on the test print Error displayed on LCD (See Note 1.) Waveforms of pins 11, 26 , 28 of FLS1 are similar to Figures H.1(1/4, 2/4) 11 : WR 26 : CE 28 : OE Waveform of pin 14 (RAS)

  • Page 548: Reading Running System Ng

    4.2.2 Reading running system NG 2: Reading running system NG (document feed error) Motor does not start when the document is fed to PC1 Pin 94 of CPU1 becomes "L" when the document is inserted to PC1 Motor does not stop when the document is fed to Pin 12 of IC14 becomes "L"...

  • Page 549: Read Image Data Ng

    4.2.3 Read image data NG 3: Read image data NG Sensor LED is lit 5V input to pin 2 of TR5 when the sensor is lit Voltage of pin 3 of TR6 comes down approximately 0.7 V than pin 1 when the sensor is lit Replace IC16.

  • Page 550: Heater Ng

    4.2.4 Heater NG 4: Heater NG (printer alarm 4) Pin 98 of IC2 repeated 5V and 0V ON/OFF during printing Replace IC2. Pin 1 results in 5V output when approximately 3V is input to pin 3 of IC18 Replace IC18. Pin 3 becomes lower than 1V when 5V is input to pin 2 of TR2...
  • Page 551 4.2.5 Recording paper running system NG 5: Recording paper running system NG Recording paper feed is NG Motor is started? Pin 2 of TR505 changes from 0V to 5V when recording paper is fed Input waveforms of pins 17, 26 of IC9 are similar to Figures H.4(1/2, 2/2) Replace CPU1.

  • Page 552: Printed Image Data Ng

    4.2.6 Printed image data NG 6: Printed image data NG Printed image is All black or all white Signals of pins 86, 87, 88 of IC2 are similar to Figures H.5(2/6, 3/6, 4/6) during printing Positive after-image Signals of pins 93, 95 of IC2 provided change between 0V and 5V cyclically during printing...

  • Page 553: Sending Ng

    4.2.7 Sending NG 7: Sending NG Call origination is impossible Call origination mode is (DP or PB) Pin 63 of IC2 repeats 5V and 0V cyclically during DP call origination Protocol signal receiving is NG Replace IC2. During protocol signal receiving, sine wave or modulated sine wave input is provided between pins 2 and 3 of IC10...

  • Page 554: Receiving Ng

    4.2.8 Receiving NG 8: Receiving NG RING signal cannot be detected 5V and 0V are alternately input to pin 9 of IC14, synchronized with the RING signal Pin 71 of IC2 repeats 5V and 0V cyclically, synchronized Check CN10. with the RING signal Protocol signal receiving is NG Replace IC14.

  • Page 555: Clock Ng

    4.2.9 Clock NG 9: Clock NG Clock display is NG All other operation display are OK Memory check is OK (memory error does not displayed on operation panel) See the operation interface error. Time error See the memory error. Battery voltage at 2.5V or higher Replace the battery.

  • Page 556: No Sound From The Speaker

    4.2.10 No sound from the speaker 10: No sound from the speaker Monitor Monitor or buzzer buzzer Communication normal Sine wave or modulated wave input is provided at pin 13 of IC8 during communication See sending or receiving NG. Replace TR1. Pulse wave input is provided at pin 5 of IC8 when the key is pressed or the soft...

  • Page 557: Pc/If Not Operating Correctly

    4.2.11 PC/IF not operating correctly 11: PC/IF does not operate correctly Pin 11 of CN11 (BUSY-P) is near 0V Pin 45 of IC12 is near 0V Replace IC12. Replace IC2. Waveform of pin 1 of CN11 (STB-N) is similar to Figure H.8(2/2) Check CN11 connection.
  • Page 558 4.2.12 Operation interface not operating correctly 12: Operation interface does not operate correctly Pin 101 of CPU1 remains at 0V Pin 92 of CPU1 remains at 0V or 5V Pin 9 of IC15 remains at 0V or 5V Check CN4 Replace IC15.

  • Page 559: Board

    04W Board 4.3.1 LCD display NG 1: LCD not displayed Input of pin 27 of IC1 changes from 0V to 5V upon power on Input of pin 4 of IC503 changes from 0V to 5V upon power on Input of pin 5 of IC503 comes down to 0V then goes back to 5V upon completion Replace IC502.

  • Page 560: Operation Not Responded

    4.3.2 Operation not responded 2: Operation not responded Clock display normal See 1: LCD is not displayed. LED is not lit. A pin either pin 33 through pin 48 of IC1 changes to 5V or near 0V when the LED should be lit Replace IC1.

  • Page 561: G4N Board

    G4N Board 4.4.1 ISDN Board NG (01) 1: ISDN Board NG (01) The signal BOOT2 from 46F/R46 board to G4N board is High level at power on. Check BOOT2 signal level High at CN10-A11 pin of 46F/R46 board without G4N board. Check 46F/R46 board Check CPU-97 pin solderling.

  • Page 562: Isdn Board Ng

    4.4.2 ISDN Board NG (02) 2: ISDN Board NG (02) Program hash NG at flash memory in G4N board. Check FLS chip solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 12, 14, 43, 15 of FLS are similar to Figure H.9 Replace FLS and re-loading G4N program...

  • Page 563: Isdn Board Ng

    4.4.3 ISDN Board NG (03) 3: ISDN Board NG (03) MUPIS I/F initial sequence couldn’t be completed during 10 seconds. Check CN1 solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 51, 50, 27 of RAM3 are similar to Figure H.10(1/3).

  • Page 564: Isdn Board Ng

    4.4.4 ISDN Board NG (04) 4: ISDN Board NG (04) Initializing IC2 (ISDN LSI) couldn’t be completed. Check IC2 solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 75, 76, 79 of IC2 and pin 53 of CPU are similar to Figures H.11(1/3, 2/3).

  • Page 565: Isdn Board Ng

    4.4.5 ISDN Board NG (05) 5: ISDN Board NG (05) The result of self test of IC2 (ISDN LSI) is NG. Check IC2 solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Replace IC2. 565 / 41309401TH Rev.4...

  • Page 566: Cpu Rom Hash Ng

    4.4.6 CPU ROM HASH NG 6: CPU ROM HASH NG HASH of CPU Internal ROM is uncorrect. Check CPU solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Replace CPU. 566 / 41309401TH Rev.4...

  • Page 567: Cpu Ram Ng

    4.4.7 CPU RAM NG 7: CPU RAM NG Test result of CPU Internal RAM is NG. Check CPU solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Replace CPU. 567 / 41309401TH Rev.4...

  • Page 568: Program Hash Ng

    4.4.8 PROGRAM HASH NG 8: PROGRAM HASH NG Program hash NG at flash memory in G4N board. Check FLS chip solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 12, 14, 43, 15 of FLS are similar to Figure H.9 Replace FLS and re-loading G4N program...

  • Page 569: Ram Ng

    4.4.9 RAM NG 9: RAM NG DRAM read/write test result is NG. Check RAM1 solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 14, 31, 13, 2 of RAM1 are similar to Figure H.12. Replace RAM1 Replace G4N board.

  • Page 570: Dpram Ng

    4.4.10 DPRAM NG 10: DPRAM NG Dual Port RAM read/write test result is NG. Check RAM3 solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 51, 50, 27 of RAM3 are similar to Figure H.10(1/3). Check CN1 solderling Waveform of pins 1, 6, 7, 17 of RAM3 are similar...

  • Page 571: G4 Mode Communication Ng

    4.4.11 G4 mode communication NG 11: G4 mode communication NG Check ISDN cable. Connect correctly Check user/service setting concerned. Set parameter correctly Waveform between CN2-3 pin and 6 pin, and between CN2-4 pin and 5 pin are similar to Figure H.13(1/2). Check T1, CN2, R583-586, R597-600, L4 solderling.

  • Page 572: G3 Mode Communication Ng

    4.4.12 G3 mode communication NG 12: G3 mode communication NG Able to communicate at G4 mode Check No. 11 item During protocol signal sending or receiving, sine wave or modulated sine wave output is provided between pin 44 and pin 46 of CN1 and between pin 48 and pin 46 of CN1.

  • Page 573: G4 Mode Pc Loading Ng

    4.4.13 G4 mode PC loading NG 13: G4 mode PC loading NG Error at G4 mode PC loading. Check CN1, RAM3, RAM1, FLS, IC1 solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 51, 50, 27 of RAM3 are similar to Figure H.10(1/3).

  • Page 574: Power On Ng

    4.4.14 Power ON NG (01) 14: Power ON NG (01) LCD display "ISDN BOARD I/F ERROR" at power on. Check CN1, RAM3, IC2, IC1, FLS, CPU solderling. Good Re-solderling Check appearance of G4N board. Good Modify bad point Waveform of pins 51, 50, 27 of RAM3 are similar to Figure H.10(1/3).

  • Page 575: Power On Ng

    4.4.15 Power ON NG (02) 15: Power ON NG (02) G4A Board not detected at power on. Check MUPISID signal level at pin 39 of CN1 High Check 46F/R46 board Check CN1 solderling 575 / 41309401TH Rev.4...
  • Page 576 Stop: 500MS/s 20 Acqs C1-Width FLS-pin 26 300.5ns (FLS1-pin 26) Low signal amplitude C4-Width FLS-pin 28 123.0ns (FLS1-pin 28) Low signal amplitude C2-Width 101.2ns Low signal amplitude 5.00 V 5.00 V M50.0ns 2.4 V 20 Jun 1998 5.00 V 5.00 V 19:06:46 Figure H.1 (1/4) FLASH RD Stop:...
  • Page 577 Stop: 500MS/s 4 Acqs C1-Width RAM2,3-pin 14 127.50ns (RAM1-pin 14) Low signal amplitude C4-Width RAM2,3-pin 30,31 50.25ns (RAM1-pin 37,38) Low signal amplitude RAM2,3-pin 3 (RAM1-pin 13) 5.00 V 5.00 V M25.0ns State 20 Jan 1998 5.00 V 5.00 V 18:35:58 Ref1 5.00 V 25.0ns...
  • Page 578 IC16-pin 77 (IC2-pin 187) IC16-pin 78 (IC2-pin 188) IC16-pin 79 (IC2-pin 186) IC16-pin 80 (IC2-pin 189) Figure H.2 578 / 41309401TH Rev.4...
  • Page 579 500mV A 100ns 2.31 V CN5-pin 1 IC13-pin 3 (IC3-pin 3) CH1gnd CN5-pin 8 CH2gnd Figure H.3 (1/2) A 100ns 2.30 V IC6-pin 12 (IC13-pin 39) CH1gnd ADCLK IC6-pin 7 CH2gnd Figure H.3 (2/2) 579 / 41309401TH Rev.4...
  • Page 580 TEK/2430 500mV /div NORMAL 10mSEC/div 500mV /div NORMAL 10mSEC/div DHON1 IC9-pin 27,16 REF1 REF1 IC9-pin 26 IC9-pin 17 REF1 500mV /div NORMAL 10mSEC/div Figure H.4 (1/2) TEK/2430 500mV /div NORMAL 500 SEC/div 500mV /div NORMAL 500 SEC/div IC9-pin 26 IC9-pin 17 Figure H.4 (2/2) 580 / 41309401TH Rev.4...
  • Page 581 272 Acqs Stop: 2.50MS/s C2 Period 137.60 s C2 + width 36.00 s DBPWN IC22-pin 9,10,11 (IC2-pin 89) 10 Jun 1998 1.00 V M 20.0 s 2.52 V 10:16:34 Figure H.5 (1/6) 160 Acqs Stop: 2.50MS/s C2 Period 137.60 s C2 + width 35.88 s CHPWN...
  • Page 582 0 Acqs Stop: 2.50MS/s : 218.8 s @: 195.6 s C2 Period 137.60 s C2 + width 36.00 s TR2PWN IC2-pin 29 (IC2-pin 87) 10 Jun 1998 1.00 V M 20.0 s 2.52 V 11:00:50 Figure H.5 (3/6) 10 Acqs Stop: 2.50MS/s : 210.0 s...
  • Page 583 Tek Run: 250MS/s Sample Trig? C2 + Width 1.5996 s HLATCH IC2-pin 111 (IC2-pin 207) 9 Jun 1998 1.00 V M 200ns 2.52 V 18:48:40 Figure H.5 (5/6) Tek Run: 1.00GS/s Sample Trig? C1 Freq 6.6852MHz HCLCK IC2-pin 112 C2 + Width (IC2-pin 202) 1152.25ns HDATA...
  • Page 584 Stop: 500MS/s 98 Acqs IC3-pin 2 C1-Width 250.3ns Low signal amplitude C4-Width IC3-pin 8 203.4ns Low signal amplitude IC3-pin 4 IC3-pin 14 5.00 V 5.00 V M50.0ns Pattern LXXL 20 Jun 1998 5.00 V 5.00 V 19:13:36 Figure H.6 (1/2) Stop: 500MS/s 1 Acqs...
  • Page 585 Figure H.7 (1/2) RTC Time Read Figure H.7 (2/2) RTC Time Set 585 / 41309401TH Rev.4...
  • Page 586 Stop: 10.0MS/s 3 Acqs : 19.8 s @: 15.0 s IC20-pin 9, 8 (IC12-pin 46) FAULT IC20-pin 3, 4 (IC12-pin 44) AUTOFEED IC15-pin 13 (IC12-pin 26) 5.00 V 5.00 V M5.00 s Width 5 Feb 1998 5.00 V 10:31:07 Figure H.8 (1/2) Stop: 50.0MS/s 27 Acqs...
  • Page 587 Figure H.9 Figure H.10 (1/3) 587 / 41309401TH Rev.4...
  • Page 588 Figure H.10 (2/3) Figure H.10 (3/3) 588 / 41309401TH Rev.4...
  • Page 589 Figure H.11 (1/3) Figure H.11 (2/3) 589 / 41309401TH Rev.4...
  • Page 590 Figure H.11 (3/3) Figure H.12 590 / 41309401TH Rev.4...
  • Page 591 Figure H.13 (1/2) Figure H.13 (2/2) 591 / 41309401TH Rev.4...
  • Page 592 Figure H.14 (1/2) Figure H.14 (2/2) 592 / 592 41309401TH Rev.3...

This manual is also suitable for:

Okioffice87

Table of Contents
