Advanced Entry Calibration

ADVANCED ENTRY should only be used when the Standard Calibration method has failed.
To facilitate the placement of the media sensor, the printhead assembly can be raised. During
this procedure, sampled readings will be used to manually establish the best gain algorithm for
sensing the media. Before calibrating, ensure that the Advanced Menu system is enabled, and
that the Media Sensor Type has been selected. Then, use the steps below and the displayed
prompts to guide you through the procedure:
Step Action
1 Press the MENU Button.
Press the ENTER Key to access
MEDIA SETTINGS, and then use
2
the UP Button to scroll to SENSOR
CALIBRATION.
Press the ENTER Key to access
SENSOR CALIBRATION. Use the
3
UP Button to scroll to ADVANCED
CALIBRATION and press the
ENTER Key.
Scroll to TRAN SENSOR GAIN (or
REFL SENSOR GAIN, if using
4
reflective media) then press the
ENTER Key.
Install roll media or box media.
Position the Media Sensor under
5
the label, then lower and latch the
Printhead Assembly.
Displayed
Message
CANNOT
CALIBRATE See MENU ORGANIZATION for
-or- menu navigation tips.
UNCALIBRATED
This is the MEDIA SETTINGS menu
MEDIA SETTINGS
branch.
You are beginning ADVANCED
ADVANCED
ENTRY calibration. Press the ESC
CALIBRATION
Key to abort this procedure.
TRAN SENSOR
GAIN
The examples that follow detail the
calibration of die-cut media; however,
(0 -
unless otherwise noted, the procedure
31)
for calibrating reflective media is the
YYY
same.
2 5
TRAN SENSOR
GAIN
If using preprinted media, ensure the
(0 -
label area over the sensor is free of
31)
text, graphics, lines, etc.
YYY
2 5
95
