Datamax H Class Operator's Manual page 77

IP DISCOVERY
ENABLED
DISABLED
SET FACTORY
DEFAULTS
Note: Following a parameter change, save your changes, exit the menu system, and wait
for the printer to reset.
HOST SETTINGS
HOST TIMEOUT
10
CONTROL
CODES
STANDARD
CODES
ALTERNATE
CODES
ALTERNATE
CODES 2
CUSTOM
CODES
FEEDBACK
CHARACTERS
ENABLED
DISABLED
Sets the address discovery method, where:
Upon start-up, the card will broadcast into the network to receive an
addresses from the responsible server. Manual modifications to IP
Address, Subnet Mask, or Gateway Address is not allowed; and, if no
server is found, the specified static value will be used.
A server assigned IP address takes precedence over any
static IP address stored in the interface.
The stored static IP, Subnet Mask, and / or Gateway Address will be
used. (Default Setting)
Resets all NIC Adapter parameters to the factory defaults, including some
parameters not accessible through the printer's menu.
Controls the communications with a host device, as follows:
Sets the number of seconds (1 - 60) that an established communications
port must be idle before data can be received through an alternate port.
Note: If the time-out period is exceeded before all data is received,
the data will be ignored.
Is the Default Setting.
Allows changes to the prefix of the software commands interpreted by the
printer, where:
Hex 01 = SOH command; Hex 02 = STX command; count-by = ^; Hex 1B
= ESC; Hex 0x0D = Carriage Return. (Default Setting)
Hex 5E = SOH command; Hex 7E = STX command; count-by = @; Hex
1B = ESC; Hex 0x0D = Carriage Return.
Hex 5E = SOH command; Hex 7E = STX command; count-by = @; Hex
1B = ESC; Hex 0x7C = Carriage Return.
Each DPL command (SOH, STX, CR, and count-by) may be selected by
entering the desired Hex code.
Allows the printer to return a Hex 1E (RS) after each label successfully
prints, and a Hex 1F (US) after each label batch successfully prints,
where:
Feedback characters are sent to the host.
No feedback characters are sent. (Default Setting)
69
