Appendix C - Module File Definitions

The following file formats can be stored using the SDIO or USB Host Ports. Once processed
and stored onto a module, the external file extension is converted, when necessary, for
recognition by the printer.
File
Extension(s)
Industry standard format. Portrait/
SFL & SFP
landscape bitmapped font.
Downloadable Datamax boot-loader
BS
upgrade file.
True type / scalable font. Industry
TTF
standard format.
BMP, PCX, & Black and white graphics files.
IMG Industry standard format.
Downloadable language message file
in a single or double byte format
LS
generated from an Excel spread
sheet via macros.
Downloadable plugin file containing a
group of hidden encrypted or normal
PLG
files. The file is generated via
"img2dl" and "bfcart" utilities.
Downloadable compressed firmware
ZS
upgrade download file.
F7B 7-bit Datamax image load file.
Supported (External) File Types
Definition
135
Details
The label name should contain the Font
ID as last three digits before the file
extension to allow automated
conversion.
Datamax specific format.
Label name should contain the Font ID
as last two digits before the file
extension to allow automated
conversion.
N/A
Datamax specific format.
Datamax specific format.
Datamax specific format.
Datamax specific format.
