Datamax H Class Operator's Manual page 72

LABEL STORE Determines the command recall level used when retrieving stored label
formats, where:
STATE & Recalls the printer state (that is, the heat setting, speed settings, etc.) and the
FIELDS label-formatting commands of the stored label. (Default Setting)
FIELDS Recalls only the label-formatting commands of the stored label.
ONLY
MENU
LANGUAGE
ENGLISH
FRANCIAIS.DLN French
ITALIANO.DLN
DEUTSCH.DLN
ESPANOL.DLN
FAULT Determines the intervention required and the disposition of the label in
HANDLING process when a fault occurs (ribbon out, media out, etc.), where:
LEVEL Selects the printer's action, the action required by the operator, and the
label's reprint status, where:
NO REPRINT Printing stops and a fault message is displayed. After the problem is
corrected, the FEED Key must be pressed to clear the fault. The label in
process is not reprinted.
STANDARD Printing stops and a fault message is displayed. After the problem is
corrected, the FEED Key must be pressed to clear the fault. The label in
process is reprinted. (Default Setting.)
VOID AND Further actions depend upon the RETRY COUNT and the Keys pressed
RETRY when faulted:
(A) If the Retry Count setting has not been exceeded, 'VOID' is printed on the label in
process and reprinting occurs automatically; or,
(B) If the Retry Count has been exceeded, printing stops and a fault message is displayed.
After the problem is corrected, the FEED Key must be pressed to clear the fault and reprint
the label in process; or,
(C) If the CANCEL Key is pressed, you have a reprint option: Press the ESCAPE Key to
reprint the label, or press the ENTER Key to cancel the reprint (and, press the ENTER Key
again to cancel the entire batch).
Selects the language in which to display the menu items and configuration
label. Only languages that are resident will be displayed, where:
English (Default Setting)
Italian
German
Spanish
Notes: (1) When no Linear Scanner is attached, the printer will perform in the
STANDARD setting, except that VOID will be printed on the faulted label.
(2) VOID will not be printed when insufficient space exists for the text (see
VOID DISTANCE, below), or if the fault occurred after the label was
completed.
(3) The Void Message can be customized, see the Class Series
Programmer's Manual for details.
64
