Datamax H Class Operator's Manual page 20

8. After entering the addresses, press the EXIT button and save your changes when
prompted.
9. Turn OFF the printer, connect the Ethernet cable, turn the printer back ON, and then
install the port and printer driver using the Windows
section, Driver and Port Setup.
•
Configuration Using IP Discovery: DHCP, BootP, and RARP are server services that
provide a method for assigning and maintaining IP Addresses. With IP Discovery enabled,
the Print Server obtains IP information from this service. Because IP Discovery is, by
default, disabled in the printer, it must first be enabled for use. To use IP Discovery follow
the steps below:
Note: When IP DISCOVERY is set to ENABLED you will not be able to change the
values for the IP ADDRESS, SUBNET MASK, or GATEWAY menu items. The
values displayed are for reference only.
1. Without connecting the Ethernet cable, turn ON the printer. Verify the printer is in
READY MODE then press the MENU Button.
2. Using the NAVIGATION Buttons, scroll to COMMUNICATIONS > NIC ADAPTER >
IP DISCOVERY.
3. Scroll to ENABLED, press the ENTER Key, then save your changes when prompted,
and exit the menu system.
4. Turn OFF the printer.
5. Plug your Ethernet cable into the printer and then turn ON the printer.
6. After the connection is established, obtain the Assigned IP Address (see example)
by printing a Configuration Label.
®
'Add a Printer Wizard'; see
