Step Action
Press the ESC Key.
Use the DOWN Button to scroll to
GAP SENSOR LEVEL (or, if using
reflective media, MARK SENSOR
LEVEL) and then press the
13
ENTER Key.
Use the UP, DOWN, LEFT, and
RIGHT Buttons to set the Gap (or
Mark) value determined in Step 11
and then press the ENTER Key.
Press the ESC Key.
Use the DOWN Button to scroll to
EMPTY SENSOR LEVEL and then
press the ENTER Key.
14
Use the UP, DOWN, LEFT, and
RIGHT Buttons to set the Empty
value determined in Step 11 and
then press the ENTER Key.
Press the EXIT Key and, when
15
prompted, press the YES Key at
the SAVE CHANGES prompt.
Press and hold the FEED Key until
16
at least one label has been output.
Displayed
Message
GAP SENSOR
LEVEL
(0 - 255)
0 3 5
EMPTY SENSOR
LEVEL
(0 - 255)
0 1 1
This completes the Advanced
OFFLINE
Calibration procedure.
The printer is now ready for use.
Note: If calibration fails, try
desensitizing the sensor: Re-enter
CALIBRATION the ADVANCED MENU. Go to MEDIA
COMPLETE SETTINGS / SENSOR
CALIBRATION / ADVANCED ENTRY
followed by... / (TRAN OR REFL) SENSOR GAIN
then lower the corresponding Gain
READY Setting by one. Exit the menu and
save your changes. Test your media
at the new setting. If necessary,
repeat until a usable Gain setting is
obtained.
99
