Displays and controls various internal counters, where:
MEDIA
COUNTERS
ABSOLUTE Shows the total number of inches printed and the date the counter was set;
COUNTER this counter is not resettable.
PRINTHEAD Shows the total number of inches printed; this counter is not user
COUNTER resettable.
RESETTABLE Shows the number of inches printed since the last user reset.
COUNTER
RESET Returns the Resettable Counter to zero.
COUNTER
PRINT
CONFIGURATION
(1) The information on this label may vary with the model, firmware version and installed options.
Notes:
(2) To capture all the data, use media that is at least 2 inches (51 mm) wide and set the Label Width
(in Media Settings) according to the width of your labels.
(3) If menu settings that require a reset to become effective have been changed, they will be
indicated with a section symbol (§); alternately, bulleted items (•) indicate denote changes that have
occurred via the host but not yet saved in memory.
CONFIGURATION
LEVEL
PRINTER KEY
Produces a Configuration Label, which indicates the printer's current
database information. (To generate the label, shown here, press the
RIGHT Button or the ENTER Key. )
Displays the hardware and software levels of the printer, important when
upgrading the application program (resident software) version of the
printer because the compatibility levels must match for the update to be
accepted, where:
Identifies the unique key number of the printer, in the form: vvvv-cwxx-
yyyyyy-zzz, where:
- Represents the printer model number.
vvvv
- Represents the hardware/software feature level, where:
cwxx
- Represents the printer class.
c
- Represents hardware feature level of the main board.
w
xx - Represents the software feature level 10 = standard DPL,
and 20 = Internal CG Times Font. Features are accepted up
to the this value, but increases beyond the range will require
an authorization code.
yyyyyy - Is the manufacturing date code.
- Is a unique time stamp.
zzz
