Datamax H Class Operator's Manual page 105

Step Action
Use the UP, DOWN, LEFT, and
RIGHT Buttons to set the Gain
Number to 00 and then press the
ENTER Key.
Record the reading as a TOF
Value for Gain Number 00 in the
table.
Increment the Gain Number and
press the ENTER Key, note the
TOF Value. Repeat this process to
8
document the TOF Values for the
thirty remaining Gain Numbers.
Calibration Table
Gain Label
Number Value
00 252
01 250
02 248
... ...
31 131
In the table, where both the Label
Value and TOF Value are above
20, subtract them and record the
result as a Difference Value (see
below). Then find the largest
Difference Value in your table – its
corresponding Gain Number will be
used for sampling the media.
Calibration Table
Gain Label
9 Number Value
00 252
01 250
... ...
06 200
07 189
08 178
09 167
... ...
30 135
31 131
TRAN SENSOR
YYY
TOF Difference
Value Value
248
245
234
...
14
TRAN SENSOR
TOF Difference
Value Value
248 4
YYY
245 5
... ...
88 112
58 131
32 146
19 N/A
... ...
14 N/A
14 N/A
Displayed
Message
GAIN
Note: The LEFT and RIGHT Buttons
(0 -
shift the cursor position.
31)
0 0
GAIN
In this example, Gain Number 08 is
chosen because, where both the
(0 -
Label Value (178) and TOF Value
31)
(32) are above twenty, it delivers the
highest Difference Value (146).
3 1
97
