Henny Penny Evolution Elite EEE-153 Technical Manual

Reduced oil capacity open fryers (split vat & full vat– electric)

Hide thumbs Also See for Evolution Elite EEE-153:

Operator's manual (70 pages)

Technical manual (88 pages)

Operator's manual (80 pages)

Table Of Contents

Table of Contents

Quick Links

Troubleshooting

Need help?

Do you have a question about the Evolution Elite EEE-153 and is the answer not in the manual?

Questions and answers

Summary of Contents for Henny Penny Evolution Elite EEE-153

Page 1 Henny Penny Evolution Elite ® Reduced Oil Capacity Open Fryers (Split Vat & Full Vat– Electric Model EEE-153 Model EEE-154 TECHNICAL MANUAL...
Page 3: Table Of Contents
Model EEE-153, 154 TABLE OF CONTENTS Section Page Section 1. TROUBLESHOOTING ................... 1-1 Introduction ..................1-1 Safety ....................1-1 Troubleshooting ..................1-2 Error Code Table .................. 1-7 Section 2. INFO & FILTER BUTTON STATS ..............2-1 INFO Button Stats ................2-1 FILTER Button Stats ................
Page 4 Model EEE-153, 154 TABLE OF CONTENTS Section Page Section 6. MAINTENANCE SECTION (Continued) Temperature Probe Replacement ............6-8 Oil Channel Clean-Out ................. 6-10 6-10 Element Safety Switch ................. 6-11 6-11 Contactors ..................... 6-12 6-12 Solenoid Valves ..................6-14 6-13 Filter Pump & Motor ................6-16 6-14 JIB Pump ....................
Page 5: Section 1. Troubleshooting
Model EEE-153, 154 SECTION 1. TROUBLESHOOTING 1-1. INTRODUCTION This section provides troubleshooting information in the form of an easy to read table. If a problem occurs during the ﬁ rst operation of a new fryer, recheck the installation per the Installation Section of this manual.
Page 6: Troubleshooting
Model EEE-153, 154 1-3. TROUBLESHOOTING To isolate a malfunction, proceed as follows: Clearly deﬁ ne the problem (or symptom) and when it occurs. Locate the problem in the Troubleshooting table. Review all possible causes. Then, one-at-a-time work through the list of corrections until the problem is solved. Refer to the maintenance procedures in the Maintenance Section to safely and properly make the checkout and repair needed.
Page 7 Model EEE-153, 154 Problem Cause Correction POWER SECTION • • With power switch in Open circuit Check to see that unit is plugged in ON position, the fryer • is completely inoperative Check the breaker or fuse at supply box •...
Page 8 Model EEE-153, 154 Problem Cause Correction HEATING OF SHORTENING SECTION (Continued) Oil will not heat • • Drain valve open Close drain valve (Continued) • • Possible faulty temperature probe Replace temperature probe • • Faulty contactor Check contactor per maintenance section on contactors •...
Page 9 Model EEE-153, 154 Problem Cause Correction OIL LEVEL SECTION Oil foaming or boiling over vat • Water in oil • At end of a Cook Cycle,drain vat and clean vat; add fresh oil • Improper or bad oil • Use recommended oil •...
Page 10 Model EEE-153, 154 Problem Cause Correction FILTER MOTOR SECTION Filter motor runs but • Filter line connections • Tighten all ﬁ lter line pumps oil slowly loose connections • Filter paper or pad clogged • Change ﬁ lter paper or pad Filter motor will not run •...
Page 11 Model EEE-153, 154 1-4. ERROR CODES In the event of a control system failure, the digital display shows an error message. The message codes are shown in the DISPLAY column below. A constant tone is heard when an er- ror code is displayed, and to silence this tone, press any button. DISPLAY CAUSE CORRECTION...
Page 12 Model EEE-153, 154 1-4. ERROR CODES (Continued) DISPLAY CAUSE CORRECTION “E-31” Elements are up Lower elements back into the vat “E-41”, “E-46” Programming Turn switch to OFF, then back to ON; if display shows any failure of these error codes, have the controls re-initialized; if error code persists, have the control board replaced “E-47”...
Page 13: Section 2. Info & Filter Button Stats
Model EEE-153, 154 SECTION 2. INFO & FILTER BUTTON STATS 2-1. INFO BUTTON STATS Actual Oil Temperature 1. Press and the actual oil temperature shows in the display, for each vat. Set-point Temperature 2. Press twice and SP shows in the display, along with the set-point (preset) temperature of each vat.
Page 14: Section 3. Information Mode
Not all Information Mode functions are discussed in this section. To ensure proper operation of fryer, please consult Henny Penny Corp. before changing any of these settings. For more information on these functions, contact Technical Support at 1-800-417- 8405, or 1-937-456-8405.
Page 15 Model EEE-153, 154 3-1. INFORMATION MODE 2. LAST LOAD (Information on recent cook cycles) DETAILS (Continued) Press and “2. LAST LOAD” show in displays. Press a timer button for the product you want to view the cook data and the LED ﬂ ashes. Press button to start viewing the cook data.
Page 16 Model EEE-153, 154 3-1. INFORMATION MODE 3. DAILY STATS (Operational info of fryer for last 7 days) DETAILS (Continued) Press and “3. DAILY STATS” show in displays. Press button to start viewing the cook data. Press the right to view data for other days of week. FUNCTION DISPLAY EX: Day this data was recorded for...
Page 17 Model EEE-153, 154 3-1. INFORMATION MODE 4. OIL STATS (info of current oil and avg. of last 4 batches of oil) DETAILS (Continued) Press and “4. OIL STATS” show in displays. Press button to start viewing the cook data. FUNCTION DISPLAY EX: Start date of new oil NEW OIL...
Page 18 Model EEE-153, 154 3-1. INFORMATION MODE 5. REVIEW USAGE (accumulated info since the data was reset) DETAILS (Continued) Press and “5. REVIEW USAGE” show in displays. Press button to start viewing the cook data. FUNCTION DISPLAY EX: Day the usage data was previously reset SINCE APR-19 3:00P Number of Hours the fryer was on...
Page 19 Model EEE-153, 154 3-1. INFORMATION MODE 6. INPUTS DETAILS (Continued) Press and “6. INPTS” and “HDE” show in displays. H = HIGH LIMIT - If “H” is present, the high limit is good. If “-” shows then the high limit is tripped out (overheated) or discon- nected.
Page 21: Section 4. Product Program Mode
Model EEE-153, 154 SECTION 4. PRODUCT PROGRAM MODE This mode allows you to program the following: • Include in Filter Count (Global) • Change Product Name • Filter at X no. of loads (Mixed) • Assign Button • Load Compensation •...
Page 22 Model EEE-153, 154 4-1. MODIFYING PRODUCT To Change Times and Temperatures SETTINGS (Continued) 7. Press button until “COOK TIME” shows in the display, and then use the product buttons, or the buttons, to change the time in minutes and seconds, to a maximum of 59:59. 8.
Page 23 Model EEE-153, 154 4-1. MODIFYING PRODUCT Mixed Filter Tracking SETTINGS (Continued) Filter After X Number of Loads 13b. Press button until “FILTER AFTER...” ﬂ ashes in the left display along, and the number of cook cycles between ﬁ lters shows in the right display. Press the product buttons, or the buttons, to change this value of 0 to 99 loads.
Page 24: Section 5. Level 2 Programming
Model EEE-153, 154 SECTION 5. LEVEL 2 PROGRAMMING • Tech Mode Used to access the following: • Special Program Mode • Stats • Clock Set • Filter Control • Data Communication • Heat Control The Special Program Mode is used to set more detailed 5-1.
Page 25 Model EEE-153, 154 5-1. SPECIAL PROGRAM Press and hold the button for 5 seconds until “LEVEL MODE (Continued) 2”followed by, “SP PROG” and “ENTER CODE” show in the display. Enter code 1,2,3, and “SP-1”, “TEMP”, “FORMAT” show in the displays. If a bad code is entered, a tone sounds and “BAD CODE”...
Page 26 Model EEE-153, 154 5-1. SPECIAL PROGRAM Audio Tone (SP-5) MODE (Continued) Press button and “SP-5” and “TONE” ﬂ ash in the left display. Press the , or use product buttons, to adjust the tone of the speaker, 2000 being the maximum value and 50 the minimum.
Page 27 Model EEE-153, 154 5-1. SPECIAL PROGRAM Filter Tracking Mode (SP-8) Filter Tracking signals the operator when the oil needs ﬁ ltering MODE (Continued) by counting the number Cook Cycles between ﬁ lters. Press button and “SP-8” and “FILTER TRACKING MODE” show in the display. Use the buttons to choose either “1.MIXED”...
Page 28 Model EEE-153, 154 5-1. SPECIAL PROGRAM Filter Tracking Mode (SP-8) (Continued) MODE (Continued) GLOBAL If GLOBAL is selected, press  button. Split Vat If unit is a split vat, “SP-8A” and “LEFT VAT FILTER CYCLES” shows in the left display, and the number of cook cycles between ﬁ...
Page 29 Model EEE-153, 154 5-1. SPECIAL PROGRAM Polish Duration (SP-9) MODE (Continued) Press button and “SP-9 POLISH TIME” ﬂ ashes in the left display. Press the , or use product buttons, to change polish time, from 0 to 10 minutes. Change Filter Pad Reminder Time (SP-10) Press button and “SP-10 CHANGE PAD’...
Page 30 Model EEE-153, 154 5-1. SPECIAL PROGRAM 2nd Language (SP-16) MODE (Continued) Press button and “SP-16 2ND LANGUAGE” ﬂ ashes on the left display. Press the buttons to select the desired 2nd language. By setting a 2nd language in the controls, 2 languages can now be chosen by pressing button during normal operation.
Page 31 Model EEE-153, 154 5-1. SPECIAL PROGRAM Autolift Enabled (SP-21) Press button and “SP-21 AUTOLIFT ENABLED?” MODE (Continued) ﬂ ashes in the left display. Press the buttons to choose “YES LIFT” or “NO LIFT”. If fryer is ﬁ tted with the auto-lift option, SP-21 must be set to “YES LIFT”, otherwise, set SP-21 to “NO LIFT”.
Page 32 Model EEE-153, 154 5-1. SPECIAL PROGRAM Program Code Change (SP-25) (Continued) If satisﬁ ed with code, press and “*CODE MODE (Continued) CHANGED*” shows in display. If not satisﬁ ed with code, press and “*CANCEL” shows in display, then reverts back to “SP-25” and “CHANGE, MGR CODE? 1=YES”.
Page 33: Do Not Disburb
Model EEE-153, 154 5-1. SPECIAL PROGRAM Skip ‘SKIM’ Prompt (SP-30) Press button and “SP-30 SKIP ‘SKIM’ PROMPT?” MODE (Continued) ﬂ ashes in the left display. Press the buttons to choose YES or NO. 2-Stage Wash Enabled (SP-31) Press button; “SP-31 2-STAGE WASH ENABLED?” ﬂ...
Page 34: Clock Set
The Data Logging, Heat Control, Tech, Stat and Filter Control 5-4. DATA LOGGING, HEAT Modes are advanced diagnostic and program modes, mainly for CONTROL, TECH, STAT, Henny Penny use only. For more information on these modes, AND FILTER CONTROL contact the Service Department at 1-800-417- 8405 or 1-937- MODES 456-8405.
Page 35: Tech Mode
Model EEE-153, 154 5-5. TECH MODE The TECH Mode has self-diagnostic information, which can be used by certiﬁ ed technicians for troubleshooting purposes, such • Software • Fryer Type (Gas or Elec.) • Push Button Test • All On Display Test •...
Page 36 Model EEE-153, 154 5-5. TECH MODE (Continued) 1. Press and hold the button for 5 seconds until “LEVEL 2”, followed by, “SP PROG” and “ENTER CODE” show in the display. 2. Press the button 4 times and “TECH” and “ENTER CODE”...
Page 37 Model EEE-153, 154 5-5. TECH MODE (Continued) T-7 - DECIMAL PTS TEST Press button to view all decimal points across the displays. T-8 - LED’S TEST Press buttons to view each LED across the control panel. T-17 - DIGITAL INPUTS - HDE H = HIGH LIMIT - If “H”...
Page 38 Model EEE-153, 154 5-5. TECH MODE (Continued) T-20 - PUMPS & VALVES Press button and “LIGHTS” “DLT_” shows in displays. ® Press and left Filter Beacon lights (split vats) and press ® button and right Filter Beacon lights (display shows “DLTo” when on) Press button and “VALVES”...
Page 39 Model EEE-153, 154 5-5. TECH MODE (Continued) Press button and “AIF REQ” and “RQ=Y OK=Y” shows in the displays. REQ=Y” means that this particular control is currently request- ing control of the AIF Board outputs. “OK=Y” means that the AIF Board has granted this control the authority to control the AIF Board outputs.
Page 40 Model EEE-153, 154 5-5. TECH MODE (Continued) Press button and “OUT F_J_” and “N_DI_oJF_” shows in the displays. AIF Board Outputs: Current outputs status from AIF board. F = Filter Pump. (Fx = Filter pump is on) J = JIB Pump. (Jx = JIB pump is on) N = New Oil Pump.
Page 41: Stats Mode
Model EEE-153, 154 5-6. STATS MODE This mode allows a technician to view advanced information on the operation of the fryer and controls. 1. Press and hold the button for 5 seconds until “LEVEL 2”, followed by, “SP PROG” and “ENTER CODE” show in the display.
Page 42: Section 6. Maintenance Section
Model EEE-153, 154 SECTION 6. MAINTENANCE 6-1. INTRODUCTION This section provides checkout and replacement procedures, for various parts of the fryer. Before replacing any parts, refer to the Troubleshooting Section to aid you in ﬁ nding the cause of the malfunction. 6-2.
Page 43: Control Panel And Menu Card Replacement
Model EEE-153, 154 6-4. CONTROL PANEL & Should the control panel become inoperative, or the menu card MENU CARD needs changed, follow these instructions: REPLACEMENT 1. Remove electrical power supplied to the vat. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 44: High Temperature Limit Control
Model EEE-153, 154 6-5. HIGH TEMPERATURE This is a safety, manual reset control, which senses the temper- LIMIT CONTROL ature of the oil. If the oil temperature exceeds 425°F (218°C), this switch opens and shuts off the heat to the vat. When the temperature of the oil drops to a safe operation limit, manually reset the control by pressing the reset button.
Page 45 Model EEE-153, 154 6-5. HIGH TEMPERATURE Replacement (continued) LIMIT CONTROL (Continued) 4. Use the lift tool and lift the hinged element from the vat. Avoid putting the lift tool in the center of the elements, at the same area as the high limit bulb, or damage to the high limit could result.
Page 46 Model EEE-153, 154 6-5. HIGH TEMPERATURE Replacement (continued) LIMIT CONTROL (Continued) 8. Using a Phillip’s-head screwdriver, remove the screws securing the capillary bulb to the upper element brackets. 9. Remove high limit bulb from element and carefully straighten the capillary tube and pull the high limit control from the rear of the unit.
Page 47 Model EEE-153, 154 6-5. HIGH TEMPERATURE Replacement (continued) LIMIT CONTROL 13. Using the capillary brackets removed in step 3 (see below), (Continued) attach the capillary to the lower brackets, aligning the capil- lary so it does NOT touch the element. (See side-view drawing for proper installation) Left-Front/Right-Rear Element Side View...
Page 48: Breakers
Model EEE-153, 154 6-6. BREAKERS There are 4 breaker on the electric fryers. To reset the breaker, open the left door and and locate breakers behind drain knob plate. Push on the plunger on the breaker to reset. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 49: Main Power Switch
Model EEE-153, 154 6-7. MAIN POWER SWITCH This is a covered rocker switch, which in the ON position, sends power to all the controls and ﬁ lter motor. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 50 Model EEE-153, 154 6-8. TEMPERATURE PROBE Checkout: REPLACEMENT (Continued) To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1. Remove control panel and hinge it down. 2.
Page 51: Oil Channel Clean-Out
Model EEE-153, 154 6-8. TEMPERATURE PROBE 5. Follow probe installation instructions below: REPLACEMENT (Continued) Excess force will damage temperature probe. Hand-tighten nut and then 1/2 turn with a wrench. 6. Connect new temperature probe to the 2 fryer connections. 7. Replace rear cover and reconnect power to vat. 8.
Page 52: Element Safety Switch
Model EEE-153, 154 6-10. ELEMENT SAFETY This switch cuts power to the element when the element is raised. SWITCH If a constant “E-31” “HEATING ELEMENTS ARE UP”, is shown on the display, when the elements are lowered into the vat, check the element safety switch. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 53: Contactors
Model EEE-153, 154 6-11. CONTACTORS ® The Evolution Elite fryer requires two switching, 24V con- tactors per vat: a primary and a heat contactor. The primary contactor energizes (contacts close) any time the main power switch is in the ON position, and the temperature of the short- ening is below 420°...
Page 54 Model EEE-153, 154 6-11. CONTACTORS (Continued) 4. With power reapplied and in a heat-up mode, check the power going to both contactor coils. Power should be going to both contactors. If no voltage is found going into the primary contactor coil, check wiring, high limit, and element switch.
Page 55: Solenoid Valves
Model EEE-153, 154 6-12. SOLENOID VALVES Each vat has a solenoid plumbed-into the oil return lines. They are normally closed, but open when power is supplied, such as, the controls are ﬁ lling the vats. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 56 Model EEE-153, 154 6-12. SOLENOID VALVES (Continued) 5. Pull the elbow away from the 1” nut, and using a 1-1/16” wrench or adjustable wrench, hold the solenoid in place while using another wrench to remove the elbow from the solenoid. Attach elbow to new solenoid, using pipe sealent on the threads.
Page 57: Filter Pump & Motor
Model EEE-153, 154 6-13. FILTER PUMP & MOTOR The 2 most common causes for a fryer not to pump oil are that the pump is clogged, or the thermal overload switch has been tripped on the motor. The pump and motor is located on the rear of the fryer.
Page 58 Model EEE-153, 154 6-13. FILTER PUMP & MOTOR (Continued) To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. Motor Removal: 1. Remove JIB from fryer. 2.
Page 59 Model EEE-153, 154 6-13. FILTER PUMP & MOTOR (Continued) 7. Using a 7/16 in. wrench, remove the 4 bolts securing the motor to the motor bracket and pull the pump and motor assembly from fryer. 8. Pull pump and motor out, from front of fryer, across the JIB shelf.
Page 60: Jib Pump
Model EEE-153, 154 6-14. JIB PUMP This pump keeps the vats ﬁ lled and is used in the Oil Guard- ian™ process. Replacement To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 61: Transformers
Model EEE-153, 154 6-16. TRANSFORMERS Both the Express Filter transformer and the control transformer are the same part number. These components drop the line voltage to low voltage compoents such as, control board, Ex- press Filter board and contactors. Checkout: To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 62: Filter Motor Relay
Model EEE-153, 154 6-17. FILTER MOTOR RELAY This component is located behind the left control panel and regulates voltage to the ﬁ lter motor. Replacement: To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 63: Drain Pan Switch
Model EEE-153, 154 6-18. DRAIN PAN SWITCH This switch closes when the drain pan is pushed properly in place under the fryer. If the drain pan is not properly in place, or the drain switch is faulty, display prompts such as, “CHECK PAN”;...
Page 64: Filter Beacon
Model EEE-153, 154 ® 6-19. FILTER BEACON Replacement To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1. Remove right or left side panel for end vats, or hinge-down the control panel for center vats.
Page 65: Oil Level Probes
Model EEE-153, 154 6-20. OIL LEVEL PROBES The oil level probes (left & right-see photo at left) monitor the oil level by temperature differences. If they becomes disabled, the display shows: “E-18A”= left probe; “E18-B”= right probe; “E18C”= both. Also, if any of the probes are out of calibration more than 10°F, or 10°C, the temperature probe should be replaced.
Page 66 Model EEE-153, 154 6-20. OIL LEVEL PROBES Replacement: (Continued) 1. Pull-out on the drain knob and drain oil from vat. 2. Using a 1/2” wrench, remove the nut on the compression ﬁ tting, and remove the temperature probe from the vat. 3.
Page 67: Drain Rod Switch
Model EEE-153, 154 6-20. OIL LEVEL PROBES 5. Connect new temperature probe to the connector and (Continued) fasten connector onto control panel. 6. Replace control panel and reconnect power to vat. 7. Fill vat by pressing and holding button until *FILTER* *MENU* shows in the display.
Page 68: Time-Delay-Relays
Model EEE-153, 154 6-22. TIME-DELAY-RELAYS This relay is located behind the left control panel and transfers (EEE-153 & EEE154) electrical power to the control to the right, if power is lost in the left vat. Replacement To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
Page 69 Model EEE-153, 154 The legend below helps in identifying the components of the wiring diagrams on the following wiring diagrams. 208/240 VOLT WIRING DIAGRAMS 6-28...
Page 70 Model EEE-153, 154 Wendy’s 6-29...
Page 72: Introduction
® Evolution Elite fryer. 7-2. GENUINE PARTS Use only genuine Henny Penny parts in your fryer. Using a part of lesser quality or substitute design may result in damage to the unit or personal injury. 7-3. WHEN ORDERING PARTS Once the parts that you want to order have been found in the...
Page 73: Electrical Components
Model EEE-153, 154 (Behind Control Panel) (left side panel removed) Electrical Components Item No. Part No. Description Quantity ME90-008 RELAY - PUMP MOTOR- 12 VDC - 30 AMP ......84454RB PC BOARD - EXPRESS FILTER ..........84134 TRANSFORMER-120V/75VA ............ 1/vat EF02-104 FUSE HOLDER - 20A-250V ............
Page 74 Model EEE-153, 154 Recommend Parts: A=Truck Stock/B=Dist. Stock Right Side Panel Removed Item No. Part No. Description Quantity 81027 ASSY - LEVER SWITCH & BRACKET ...... 1/vat   50764 MICROSWITCH - RIGID LEVER ......1/vat 81017 HARNESS LEVER SWITCH ........1/vat 81495 BRACKET - LEVER SWITCH MOUNTING ..
Page 75 Model EEE-153, 154 Rear View Item No. Part No. Description Quantity  1 78753 CONTACTOR - 24V COIL (Heat Contactor) ........1/vat  2 29509 CONTACTOR - 24V COIL (Primary Contactor) ........ 1/vat  3 18227 SWITCH - ELEMENT LIFT ............... 1/vat ...
Page 76 Model EEE-153, 154 Front View Item No. Part No. Description Quantity 91359 HANGER-BASKET - EEE-15X ........1/vat   2 52224 SWITCH - POWER ............1/vat   3 81980 LED - 5 mm BLUE ............1/vat 81185 ASSY-LH DOOR ............81847 ASSY-LH DOOR - EEE-154 ONLY (not shown) ..
Page 77 Model EEE-153, 154 Top View Item No. Part No. Description Quantity 86010 WELD ASSY- OIL DIVERTER ..........1/vat NS03-044 NUT - ACORN - #10-24 - SS ..........1/vat  3 78484-001 ELEMENT-HEATING - 7 KW-208V ........2/vat  3 78484-006 ELEMENT-HEATING - 7 KW-240V ........
Page 78 Model EEE-153, 154 Item No. Part No. Description Quantity SC01-076 SCREW #8-32 X 1/4 PH THD S ............ 2/vat 75819 PLATE - FRONT CAPILLARY ............. 1/vat 75818 PLATE - REAR CAPILLARY ............1/vat SC01-074 SCREW #10-32 X 1/2 PH THD S ..........4/vat 74209 HOUSING - ELEMENT PIVOT ............
Page 79 Model EEE-153, 154 Control Panel Assembly Control Assembly Item No. Part No. Description Quantity 90785RB ASSY - EEE15X CONTROL ..........1/vat ® 81354 DECAL - EVOLUTION ELITE CONTROL ....1/control 83206 DECAL - EE AUTO-LIFT CONTROL ......1/control NS02-005 NUT - HEX KEPS #6-32 C ..........23/control ...
Page 80 Model EEE-153, 154 Wendy’s EEE-15X Filter Pan Assembly, Brushes & Accessory Holder Item No. Part No. Description Quantity 91130 ASSY - WIDE DRAIN PAN .......... 82673 ASSY-DRAIN PAN COVER ........76259 WELD ASSY-CRUMB CATCHER ......89416 WELD ASSY-FILTER WEIGHT .........
Page 81 Model EEE-153, 154 BIB System Item No. Part No. Description Quantity  B 1 86295 ASSY-BIB TUBE & QUICK DISC ........... 85966 WELD ASSY - JIB SHELF ............81513 ASSY - HOSE ................Recommend Parts: A=Truck Stock/B=Dist. Stock 7-10...
Page 82 Model EEE-153, 154 Drain Valve Linkage Parts Item No. Part No. Description Quantity 74626 STOP - PIVOT LINKAGE ..........1/vat 79590 VALVE-DRAIN 1.250 PORT W/O HDL ......1/vat 73994 HANDLE - PIVOT - DRAIN ..........1/vat 74568 PIVOT - BUSHING - ACTUATOR ........1/vat PN01-012 PIN - CLEVIS - 1/4 x 1 IN SS ..........1/vat 74571...
Page 83 Model EEE-153, 154 Filter Return Line Assembly Item No. Part No. Description Quantity 80758 ASSY - RETURN LINE ..........16807 FITTING - CONNECTOR MALE ........74469 VALVE - 1/2 CHECK ............FP01-028 NIPPLE - CLOSE - 1/2 NPT - SS - 1 LG ......FP01-112 1/2 NPT FEMALE PIPE TEE BI ........
Page 84 Model EEE-153, 154 Filter Motor and Pump Item No. Part No. Description Quantity  1 67583 MOTOR, 1/2 HP - 50/60 Hz .......... 2 17476 SEAL KIT ................  3 64218 PUMP - FILTER - 8 GPM .......... 4 SC01-132 SCREW, Pump Cover ..........
Page 85 Model EEE-153, 154 Bulk Dispose Item No. Part No. Description Quantity 140053 KIT - EEE BULK DISPOSE RETROFIT ........ 1 67662 ASSY - DIRECT CONNECT HOSE ........ 2 21612 DISCONNECT - FEMALE .......... 3 21800 VALVE - 3/4 CHECK ...............
Page 86 Model EEE-153, 154 Automatic Power Switching Components, High Limit Tool & PM Card Hook - EEE-15X Item No. Part No. Description Quantity  1 92982 RELAY-DELAY TIMER 24-240VAC ...... 2 92983 RELAY-BASE SOCKET .......... 3 91727 RELAY-POWER DPDT 240VAC ...........
