TECHNICAL
M A N U A L
EVOLUTION ELITE
REDUCED OIL CAPACITY OPEN FRYER
MODEL
EEE-181
EEE-182
EEE-183
EEE-184
(Electric)
TM
R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M
R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVOLUTION ELITE EEE-182 and is the answer not in the manual?

Questions and answers

Related Manuals for Henny Penny EVOLUTION ELITE EEE-182

Summary of Contents for Henny Penny EVOLUTION ELITE EEE-182

  • Page 1 TECHNICAL M A N U A L EVOLUTION ELITE (Electric) REDUCED OIL CAPACITY OPEN FRYER MODEL EEE-181 EEE-182 EEE-183 EEE-184 R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M R E G I S T E R W A R R A N T Y O N L I N E AT W W W.

  • Page 3: Table Of Contents

    Model EEE-182 TABLE OF CONTENTS Section Page Section 1. TROUBLESHOOTING ................... 1-1 Introduction ..................1-1 Safety ....................1-1 Troubleshooting ..................1-2 Error Code Table .................. 1-6 Section 2. INFO & FILTER BUTTON STATS ..............2-1 INFO Button Stats ................2-1 FILTER Button Stats ................
  • Page 4 Model EEE-182 TABLE OF CONTENTS Section Page Section 6. MAINTENANCE SECTION (Continued) Temperature Probe Replacement ............6-9 Oil Channel Clean-Out ................. 6-11 6-10 Element Safety Switch ................. 6-12 6-11 Contactors ..................... 6-13 6-12 Solenoid Valves ..................6-15 6-13 Filter Pump & Motor ................6-17 6-14 JIB Pump ....................

  • Page 5: Section 1. Troubleshooting

    Model EEE-182 SECTION 1. TROUBLESHOOTING 1-1. INTRODUCTION This section provides troubleshooting information in the form of an easy to read table. If a problem occurs during the first operation of a new fryer, recheck the installation per the Installation Section of this manual. Before troubleshooting, always recheck the operation pro- cedures per Section 3 of this manual. 1-2.

  • Page 6: Troubleshooting

    Model EEE-182 1-3. TROUBLESHOOTING To isolate a malfunction, proceed as follows: 1. Clearly define the problem (or symptom) and when it occurs. Locate the problem in the Troubleshooting table. Review all possible causes. Then, one-at-a-time work through the list of corrections until the problem is solved. Refer to the maintenance procedures in the Maintenance Section to safely and properly make the checkout and repair needed.
  • Page 7 Model EEE-182 Problem Cause Correction POWER switch ON • Open circuit • Plug fryer in but fryer completely • Check breaker or fuse at supply inoperative • (Non-US/some Int’l. locations only) Breakers in fryer tripped-open left door and reset breaker on fryer;...
  • Page 8 Model EEE-182 Problem Cause Correction Oil foaming or boiling • Water in oil • Drain and clean oil over top of vat • Improper or bad oil • Use recommended oil • Improper filtering • Refer to filtering procedures • Improper rinsing after • Clean and rinse vat and then cleaning the vat dry thoroughly...
  • Page 9 Model EEE-182 DISPLAYED PROMPT SECTION “IS POT FILLED” filter error • All oil did not completely • Have manager follow prompts prompt return after a filter cycle • Is JIB full? If not, fill JIB “CHECK PAN” prompt • Filter pad clogged • Replace filter pad/clean pan. “FILTER PAN MISSING” • Filter pan not completely • Adjust filter pan prompt appears engaged •...
  • Page 10 Model EEE-182 1-4. ERROR CODES In the event of a control system failure, the digital display shows an error message. The message codes are shown in the DISPLAY column below. A constant tone is heard when an er- ror code is displayed, and to silence this tone, press any button. DISPLAY CAUSE CORRECTION...
  • Page 11 Model EEE-182 1-4. ERROR CODES (Continued) DISPLAY CAUSE CORRECTION “E-21” Slow heat recovery Have a certified service technician check the fryer for correct voltage to the unit; have the contactors and heating element checked; have unit checked for loose or burnt wires “E-31” Elements are up Lower elements back into the vat “E-41”, “E-46”...

  • Page 13: Section 2. Info & Filter Button Stats

    Model EEE-182 SECTION 2. INFO & FILTER BUTTON STATS 2-1. INFO BUTTON STATS Actual Oil Temperature 1. Press and the actual oil temperature shows in the display, for each vat. Set-point Temperature 2. Press twice and SP shows in the display, along with the set-point (preset) temperature of each vat.
  • Page 15 Not all Information Mode functions are discussed in this section. To ensure proper operation of fryer, please consult Henny Penny Corp. before changing any of these settings. For more information on these functions, contact Technical Support at 1-800-417- 8405, or 1-937-456-8405.

  • Page 16: Section 3. Information Mode

    Model EEE-182 3-1. INFORMATION MODE 2. LAST LOAD (Information on recent cook cycles) DETAILS (Continued) Press and “2. LAST LOAD” show in displays. Press a timer button for the product you want to view the cook data and the LED flashes. Press button to start viewing the cook data. For example, if the left LED is flashing, “PRODUCT FRY L1”...
  • Page 17 Model EEE-182 3-1. INFORMATION MODE 3. DAILY STATS (Operational info of fryer for last 7 days) DETAILS (Continued) Press and “3. DAILY STATS” show in displays. Press button to start viewing the cook data. Press the right to view data for other days of week. FUNCTION DISPLAY EX: Day this data was recorded for...
  • Page 18 Model EEE-182 3-1. INFORMATION MODE 4. OIL STATS (info of current oil and avg. of last 4 batches of oil) DETAILS (Continued) Press and “4. OIL STATS” show in displays. Press button to start viewing the cook data. FUNCTION DISPLAY EX: Start date of new oil NEW OIL MAR-23...
  • Page 19 Model EEE-182 3-1. INFORMATION MODE 5. REVIEW USAGE (accumulated info since the data was reset) DETAILS (Continued) Press and “5. REVIEW USAGE” show in displays. Press button to start viewing the cook data. FUNCTION DISPLAY EX: Day the usage data was previously reset SINCE APR-19 3:00P Number of Hours the fryer was on...
  • Page 20 Model EEE-182 3-1. INFORMATION MODE 6. INPUTS DETAILS (Continued) Press and “6. INPTS” and “HDE” show in displays. H = HIGH LIMIT - If “H” is present, the high limit is good. If “-” shows then the high limit is tripped out (overheated) or discon- nected.

  • Page 21: Section 4. Product Program Mode

    Model EEE-182 SECTION 4. PRODUCT PROGRAM MODE This mode allows you to program the following: • Include in Filter Count (Global) • Change Product Name • Filter at X no. of loads (Mixed) • Assign Button • Load Compensation • Change Times & Temp •...
  • Page 22 Model EEE-182 4-1. MODIFYING PRODUCT To Change Times and Temperatures SETTINGS (Continued) 7. Press button until “COOK TIME” shows in the display, and then use the product buttons, or the buttons, to change the time in minutes and seconds, to a maximum of 59:59. 8.
  • Page 23 Model EEE-182 4-1. MODIFYING PRODUCT Mixed Filter Tracking SETTINGS (Continued) Filter After X Number of Loads 13b. Press button until “FILTER AFTER...” flashes in the left display along, and the number of cook cycles between filters shows in the right display. Press the product buttons, or the buttons, to change this value of 0 to 99 loads. This needs set for each product. >Load Compensation, Load Compensation Reference, Full Heat, PC Factor<...
  • Page 24 Model EEE-182...

  • Page 25: Section 5. Level 2 Programming

    Model EEE-182 SECTION 5. LEVEL 2 PROGRAMMING • Tech Mode Used to access the following: • Special Program Mode • Stats • Clock Set • Filter Control • Data Communication • Heat Control The Special Program Mode is used to set more detailed 5-1.
  • Page 26 Model EEE-182 5-1. SPECIAL PROGRAM Press and hold the button for 5 seconds until “LEVEL MODE (Continued) 2”followed by, “SP PROG” and “ENTER CODE” show in the display. Enter code 1,2,3, and “SP-1”, “TEMP”, “FORMAT” show in the displays. If a bad code is entered, a tone sounds and “BAD CODE” shows on the display.
  • Page 27 Model EEE-182 5-1. SPECIAL PROGRAM Audio Tone (SP-5) MODE (Continued) Press button and “SP-5” and “TONE” flash in the left display. Press the , or use product buttons, to adjust the tone of the speaker, 2000 being the maximum value and 50 the minimum. Liquid or Solid Cooking Oil Used (SP-6) Press button until “SP-6 MELT CYCLE SELECT”...
  • Page 28 Model EEE-182 5-1. SPECIAL PROGRAM Filter Tracking Mode (SP-8) MODE (Continued) Filter Tracking signals the operator when the oil needs filtering by counting the number Cook Cycles between filters. Press button and “SP-8” and “FILTER TRACKING MODE” show in the display. Use the buttons to choose either “1.MIXED” filter tracking or “2.GLOBAL”. GLOBAL means all the products have the same number of cook cycles between filters. MIXED means each product may be set with different num- No.
  • Page 29 Model EEE-182 5-1. SPECIAL PROGRAM Filter Tracking Mode (SP-8) (Continued) MODE (Continued) GLOBAL If GLOBAL is selected, press button. Split Vat If unit is a split vat, “SP-8A” and “LEFT VAT FILTER CYCLES” shows in the left display, and the number of cook cycles between filters shows on the right display (0 to 99).
  • Page 30 Model EEE-182 5-1. SPECIAL PROGRAM Polish Duration (SP-9) MODE (Continued) Press button and “SP-9 POLISH TIME” flashes in the left display. Press the , or use product buttons, to change polish time, from 0 to 10 minutes. Change Filter Pad Reminder Time (SP-10) Press button and “SP-10 CHANGE PAD’ REMINDER” flashes in the left display. Press the or , or use product buttons, to change the time from 0 to 100 hours.
  • Page 31 Model EEE-182 5-1. SPECIAL PROGRAM 2nd Language (SP-16) MODE (Continued) Press button and “SP-16 2ND LANGUAGE” flashes on the left display. Press the buttons to select the desired 2nd language. By setting a 2nd language in the controls, 2 languages can now be chosen by pressing button during normal operation.
  • Page 32 Model EEE-182 5-1. SPECIAL PROGRAM Auto lift Enabled (SP-21) MODE (Continued) Press button and “SP-21 AUTOLIFT ENABLED?” flashes in the left display. Press the or buttons to choose “YES LIFT” or “NO LIFT”. If fryer is fitted with the auto lift option, SP-21 must be set to “YES LIFT”, otherwise, set SP-21 to “NO LIFT”. Bulk Oil Supply (SP-22) Press button and “SP-22 BULK OIL SUPPLY?”...
  • Page 33 Model EEE-182 5-1. SPECIAL PROGRAM Program Code Change (SP-25) (Continued) MODE (Continued) If satisfied with code, press and “*CODE CHANGED*” shows in display. If not satisfied with code, press and “*CANCEL” shows in display, then reverts back to “SP-25” and “CHANGE, MGR CODE? 1=YES”. Now the above steps can be repeated. Usage Code Change (SP-26) This allows the operator to change the reset usage code (factory set at 1, 2, 3) to reset the usage amounts of each product.

  • Page 34: Do Not Disturb

    Model EEE-182 5-1. SPECIAL PROGRAM Skip ‘SKIM’ Prompt (SP-30) MODE (Continued) Press button and “SP-30 SKIP ‘SKIM’ PROMPT?” flashes in the left display. Press the or buttons to choose YES or NO. 2-Stage Wash Enabled (SP-31) Press button; “SP-31 2-STAGE WASH ENABLED?” flashes in the left display. Press the or buttons to choose YES or NO. 5-2. DO NOT DISTURB Time periods of peak operations during which the “FILTER NOW?”...

  • Page 35: Clock Set

    The Data Logging, Heat Control, Tech, Stat and Filter Control 5-4. DATA LOGGING, HEAT Modes are advanced diagnostic and program modes, mainly for CONTROL, TECH, STAT, Henny Penny use only. For more information on these modes, AND FILTER CONTROL contact the Service Department at 1-800-417- 8405 or 1-937- MODES 456-8405.

  • Page 36: Tech Mode

    Model EEE-182 5-5. TECH MODE The TECH Mode has self-diagnostic information, which can be used by certified technicians for troubleshooting purposes, such • Software • Fryer Type (Gas or Elec.) • Push Button Test • All On Display Test • Display Segment Test • Display Digits Test •...
  • Page 37 Model EEE-182 5-5. TECH MODE (Continued) 1. Press and hold the button for 5 seconds until “LEVEL 2”, followed by, “SP PROG” and “ENTER CODE” show in the display. 2. Press the button 4 times and “TECH” and “ENTER CODE” flash in the left display. 3. Enter code 1, 1, 2, 2, 1, 1, 2, 2 (first 2 product buttons).
  • Page 38 Model EEE-182 5-5. TECH MODE (Continued) T-7 - DECIMAL PTS TEST Press button to view all decimal points across the displays. T-8 - LED’S TEST Press buttons to view each LED across the control panel. T-17 - DIGITAL INPUTS - HDE H = HIGH LIMIT - If “H”...
  • Page 39 Model EEE-182 5-5. TECH MODE (Continued) T-20 - PUMPS & VALVES Press button and “LIGHTS” “DLT_” shows in displays. Press and left Filter Beacon lights (split vats) and press ® button and right Filter Beacon lights (display shows “DLTo” ® when on) Press button and “VALVES”...
  • Page 40 Model EEE-182 5-5. TECH MODE (Continued) Press button and “AIF REQ” and “RQ=Y OK=Y” shows in the displays. REQ=Y” means that this particular control is currently request- ing control of the AIF Board outputs. “OK=Y” means that the AIF Board has granted this control the authority to control the AIF Board outputs.
  • Page 41 Model EEE-182 5-5. TECH MODE (Continued) Press button and “OUT F_J_” and “N_DI_oJF_” shows in the displays. AIF Board Outputs: Current outputs status from AIF board. F = Filter Pump. (Fx = Filter pump is on) J = JIB Pump. (Jx = JIB pump is on) N = New Oil Pump.

  • Page 42: Stats Mode

    Model EEE-182 5-6. STATS MODE This mode allows a technician to view advanced information on the operation of the fryer and controls. 1. Press and hold the button for 5 seconds until “LEVEL 2”, followed by, “SP PROG” and “ENTER CODE” show in the display.

  • Page 43: Section 6. Maintenance Section

    Model EEE-182 SECTION 6. MAINTENANCE 6-1. INTRODUCTION This section provides checkout and replacement procedures, for various parts of the fryer. Before replacing any parts, refer to the Troubleshooting Section to aid you in finding the cause of the malfunction. 6-2. MAINTENANCE HINTS 1. A multimeter will help you to check the electric components.

  • Page 44: Control Panel And Menu Card Replacement

    Model EEE-182 6-4. CONTROL PANEL & Should the control panel become inoperative, or the menu card MENU CARD needs changed, follow these instructions: REPLACEMENT 1. Remove electrical power supplied to the vat. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
  • Page 45 Model EEE-182 6-5. HIGH TEMPERATURE A high limit thermocouple is attached to each element and LIMIT SYSTEM senses oil temperature. If temperature exceeds 600°F (316°C), a switch opens and shuts off heat to vat, and an E-10 error code is displayed. After oil temperature cools to a safe operat- ing temperature (15-20 min.), the high limit must be manually reset.
  • Page 46 Model EEE-182 6-5. HIGH TEMPERATURE heat and fi x the problem. If no, replace the high limit LIMIT SYSTEM control module (instructions below). (Continued) 9. Check the wiring between the high limit control module and the high limit reset switch for continuity. If the wiring passed the continuity check replace the high limit reset switch (instructions below).
  • Page 47 Model EEE-182 3. Using a Phillip’s-head screwdriver, remove the 2 screws securing the high limit to the bracket. 4. Use the lift tool and lift the hinged element from the vat. Avoid putting the lift tool in the center of the elements, at the same area as the high limit bulb, or damage to the high limit could result.

  • Page 48: High Temperature Limit Control

    Model EEE-182 6-5. HIGH TEMPERATURE Replacement (continued) LIMIT CONTROL (Continued) 8. Using a Phillip’s-head screwdriver, remove the screws securing the capillary bulb to the upper element brackets. 9. Remove high limit bulb from element and carefully straighten the capillary tube and pull the high limit control from the rear of the unit.
  • Page 49 Model EEE-182 6-5. HIGH TEMPERATURE Replacement (continued) LIMIT CONTROL 13. Using the capillary brackets removed in step 3 (see below), (Continued) attach the capillary to the lower brackets, aligning the capil- lary so it does NOT touch the element. (See side-view drawing for proper installation) Left-Front/Right-Rear Element Side View...

  • Page 50: Breakers

    Model EEE-182 6-6. BREAKERS There are 4 breaker on the electric fryers. To reset the breaker, open the left door and locate breakers behind drain knob plate. Push on the plunger on the breaker to reset. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.

  • Page 51: Main Power Switch

    Model EEE-182 6-7. MAIN POWER SWITCH This is a covered rocker switch, which in the ON position, sends power to all the controls and filter motor. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1.
  • Page 52 Model EEE-182 6-8. TEMPERATURE PROBE Checkout: REPLACEMENT (Continued) To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1. Remove control panel and hinge it down. 2.

  • Page 53: Oil Channel Clean-Out

    Model EEE-182 6-8. TEMPERATURE PROBE 5. Follow probe installation instructions below: REPLACEMENT (Continued) Excess force will damage temperature probe. Hand-tighten nut and then 1/2 turn with a wrench. 6. Connect new temperature probe to the 2 fryer connections. 7. Replace rear cover and reconnect power to vat. 8.

  • Page 54: Element Safety Switch

    Model EEE-182 6-10. ELEMENT SAFETY This switch cuts power to the element when the element is raised. SWITCH If a constant “E-31” “HEATING ELEMENTS ARE UP”, is shown on the display, when the elements are lowered into the vat, check the element safety switch. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.

  • Page 55: Contactors

    Model EEE-182 6-11. CONTACTORS The Evolution Elite fryer requires two switching, 24V con- ® tactors per vat: a primary and a heat contactor. The primary contactor energizes (contacts close) any time the main power switch is in the ON position, and the temperature of the short- ening is below 420°...
  • Page 56 Model EEE-182 6-11. CONTACTORS (Continued) 4. With power reapplied and in a heat-up mode, check the power going to both contactor coils. Power should be going to both contactors. If no voltage is found going into the primary contactor coil, check wiring, high limit, and element switch.

  • Page 57: Solenoid Valves

    Model EEE-182 6-12. SOLENOID VALVES Each vat has a solenoid plumbed-into the oil return lines. They are normally closed, but open when power is supplied, such as, the controls are filling the vats. To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.
  • Page 58 Model EEE-182 6-12. SOLENOID VALVES (Continued) 5. Pull the elbow away from the 1” nut, and using a 1-1/16” wrench or adjustable wrench, hold the solenoid in place while using another wrench to remove the elbow from the solenoid. Attach elbow to new solenoid, using pipe sealent on the threads.

  • Page 59: Filter Pump & Motor

    Model EEE-182 6-13. FILTER PUMP & MOTOR The 2 most common causes for a fryer not to pump oil are that the pump is clogged, or the thermal overload switch has been tripped on the motor. The pump and motor is located on the rear of the fryer.
  • Page 60 Model EEE-182 6-13. FILTER PUMP & MOTOR (Continued) To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. Motor Removal: 1. Remove JIB from fryer. 2. Remove the rear panel and the right side panel. 3. Using a 7/8” wrench, loosen the front, flexible line fitting, on the pump.
  • Page 61 Model EEE-182 6-13. FILTER PUMP & MOTOR (Continued) 7. Using a 7/16 in. wrench, remove the 4 bolts securing the motor to the motor bracket and pull the pump and motor assembly from fryer. 8. Pull pump and motor out, from front of fryer, across the JIB shelf.

  • Page 62: Jib Pump

    Model EEE-182 6-14. JIB PUMP T his pump keeps the vats filled and is used in the Oil Guard- ian™ process. Replacement To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1. Remove the right side panel. 2. Using a 1” wrench, loosen fitting on right side of pump.

  • Page 63: Transformers

    Model EEE-182 6-16. TRANSFORMERS Both the Express Filter transformer and the control transformer are the same part number. These components drop the line voltage to low voltage components such as, control board, Ex- press Filter board and contactors. Checkout: To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle.

  • Page 64: Filter Motor Relay

    Model EEE-182 6-17. FILTER MOTOR RELAY This component is located behind the left control panel and regulates voltage to the filter motor. Replacement: To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1.

  • Page 65: Drain Pan Switch

    Model EEE-182 6-18. DRAIN PAN SWITCH This switch closes when the drain pan is pushed properly in place under the fryer. If the drain pan is not properly in place, or the drain switch is faulty, display prompts such as, “CHECK PAN”;...

  • Page 66: Filter Beacon

    Model EEE-182 6-19. FILTER BEACON Replacement ® To avoid electrical shock or property damage, move the power switch to OFF and disconnect main circuit breaker, or unplug cord at wall receptacle. 1. Remove right or left side panel for end vats, or hinge-down the control panel for center vats.

  • Page 67: Oil Level Probes

    Model EEE-182 6-20. OIL LEVEL PROBES The oil level probes (left & right-see photo at left) monitor the oil level by temperature differences. If they becomes disabled, the display shows: “E-18A”= left probe; “E18-B”= right probe; “E18C”= both. Also, if any of the probes are out of calibration more than 10°F, or 10°C, the temperature probe should be replaced.
  • Page 68 Model EEE-182 6-20. OIL LEVEL PROBES Replacement: (Continued) 1. Pull-out on the drain knob and drain oil from vat. 2. Using a 1/2” wrench, remove the nut on the compression fitting, and remove the temperature probe from the vat. 3. Using a terminal extractor, remove the probe terminals from the connector and pull remove probe from unit.

  • Page 69: Drain Rod Switch

    Model EEE-182 6-20. OIL LEVEL PROBES 5. Connect new temperature probe to the connector and (Continued) fasten connector onto control panel. 6. Replace control panel and reconnect power to vat. 7. Fill vat by pressing and holding button until *FILTER* *MENU* shows in the display. Then once “1.EXPRESS FILTER”...

  • Page 70: Wiring Diagrams - 208/240V

    Model EEE-182 The legend below helps in identifying the components of the wiring diagrams on the following wiring diagrams. 208/240 VOLT WIRING DIAGRAMS 6-28 July 2016...
  • Page 71 Model EEE-182 July 2016 6-29...
  • Page 72 Model EEE-182 July 2016 6-30...
  • Page 73 Model EEE-182 July 2016 6-31...
  • Page 74 Model EEE-182 July 2016 6-32...
  • Page 75 Model EEE-182 July 2016 6-33...
  • Page 76 Model EEE-182 July 2016 6-34...
  • Page 77 Model EEE-182 July 2016 6-35...
  • Page 78 Model EEE-182 July 2016 6-36...
  • Page 79 Model EEE-182 July 2016 6-37...
  • Page 80 Model EEE-182 6-38 July 2016...
  • Page 81 Model EEE-182 July 2016 6-39...
  • Page 82 Model EEE-182 July 2016 6-40...
  • Page 83 Model EEE-182 July 2016 6-41...
  • Page 84 Model EEE-182 July 2016 6-42...

  • Page 85: Introduction

    Evolution Elite fryer. ® 7-2. GENUINE PARTS Use only genuine Henny Penny parts in your fryer. Using a part of lesser quality or substitute design may result in damage to the unit or personal injury. 7-3. WHEN ORDERING PARTS Once the parts that you want to order have been found in the...
  • Page 86 Model EEE-182 (6PL) (2PL) (4PL) (2PL) (2PL) 06160007 (6PL) 8.5kw Split Heating Elelemnt Assy July 2016...
  • Page 87 Model EEE-182 Item No. Part No. Description Quantity 159152 ASSY, SPLITELEMENT, 8.5KW ..........NS02-007 .NUT, HEX, 8-32 ................. 2 per Assy 159810 .BRACKET, REAR, RESET SWITCH ........1 per Assy 159812 .STUD ASSY, HILIMIT, MTG BRACKET........ 1 per Assy SC01-209 .SCREW, 10-32 X 3/8 PH THD SS ...........
  • Page 88 Model EEE-182 NOTE: All items not called out can be seen in the split element figure. (2PL) (2PL) (12PL) 06160010 (4PL) 17kw Full Heating Elelemnt Assy July 2016...
  • Page 89 Model EEE-182 Item No. Part No. Description Quantity 159160 ASSY, FULL ELEMENT, 17KW ..........78494 . WELD ASSY, SPREADER, FULL LVE ........2 per Assy SC04-003 . SCREW, 8-32 X 3/8 PH PAN THRD........12 per Assy 78503 . FOOT, FULL ELEMENT ............4 per Assy 91269 .
  • Page 90 Model EEE-182 17kw Full Heating Elelemnt Assy July 2016...
  • Page 91 Model EEE-182 Item No. Part No. Description Quantity 140464 KIT, EEE18X, HI LIMIT PROBE ..........P/O item 1 . PROBE, HI LIMIT ..............1 per kit P/O item 1 . WIRE TIE, 1/8 P ..............5 per kit P/O item 1 .
  • Page 92 Model EEE-182 High Limit Control Modules, Reset Switches, and Wiring July 2016...
  • Page 93 Model EEE-182 Item No. Part No. Description Quantity 159044 CONTROL MODULE, HI LIMIT ..........2/vat 157360 BUTTON, RESET, HI LIMIT ............. 2/vat 159915-001 WELL 1 HARNESS ..............159915-002 WELL 2 HARNESS..............159915-003 WELL 3 HARNESS ..............Recommend Parts: A=Truck Stock/B=Dist. Stock / *not shown AR=As Required **Only wells with the Express Filter PC board behind the control panel (as shown) has 2 transformers July 2016...

  • Page 94: Electrical Components

    Model EEE-182 (Behind Control Panel) (left side panel removed) Electrical Components ASSY-24V/208V 75VA TRANSFORMER Item No. Part No. Description Quantity ME90-008 RELAY - PUMP MOTOR- 12 VDC - 30 AMP ......84454RB PC BOARD - EXPRESS FILTER ..........140057 KIT-TRANSFORMER - Before 11/25/2009 ......1/vat 84134 24V/208V 75VA TRANSFORMER- 11/25/2009 &...
  • Page 95 Model EEE-182 Recommend Parts: A=Truck Stock/B=Dist. Stock Right Side Panel Removed Item No. Part No. Description Quantity 81027 ASSY - LEVER SWITCH & BRACKET ...... 1/vat 50764 MICROSWITCH - RIGID LEVER ......1/vat Α 81017 HARNESS LEVER SWITCH ........1/vat 81495 BRACKET - LEVER SWITCH MOUNTING ..
  • Page 96 Model EEE-182 81911 VALVE-ACTUATOR, DRAIN W/ O-RINGS ....84415 O-RING, 326 DRAIN VALVE LVX ....... *not shown July 2016 7-12...
  • Page 97 Model EEE-182 08160002 Rear View Item No. Part No. Description Quantity 78702 ASSY - TERMINAL BLOCK - DOM ........18227 SWITCH - ELEMENT LIFT ............78753 CONTACTOR, SQUARE D 24V ..........5197 CONTACTOR, 24 VAC .............. 74469 VALVE, 1/2 CHECK..............74582 VALVE 220-240V, SOLENOID 1/2NPT ........
  • Page 98 Model EEE-182 Front View (Continued) 75381 ASSY - POWER CORD - 208-240V-60 AMP......1/vat 82087 ASSY - POWER CORD - 208-240V-50 AMP......1/vat 79364 ASSY - CE POWER CORD ............1/vat July 2016 7-14...
  • Page 99 Model EEE-182 Front View Item No. Part No. Description Quantity 85520 HANGER-BASKET - EEE-141 ........... 77842 HANGER-BASKET - EEE-142 ........... 77709 HANGER-BASKET - EEE-143 ........... 77934 HANGER-BASKET - EEE-144 ........... 91164 HANGER-BASKET - EEE-142 Auto Lift ......Α 2 52224 SWITCH - POWER ..............
  • Page 100 Model EEE-182 Front View (Continued) Part No. Description Quantity 140481 KIT-EEX CONTROL, W/THUMB DRIVE ......03623 WELD ASSY - COVER - SPLIT VAT ......... 1/vat 03624 WELD ASSY - COVER - FULL VAT ........1/vat 81915 BASKET - 1/2 SIZE - COATED HANDLE ......2/vat 83449 BASKET-1/2 SIZE-TIERED-FRONT/REAR HOOK ..
  • Page 101 Model EEE-182 EEE-184 Door Break Down 92348 92616 92617 92617 ASSY-LH DOOR ASSY-LH DOOR ASSY-LH DOOR ASSY-RH DOOR EEE-183 Door Break Down 92348 92617 92617 ASSY-LH DOOR ASSY-LH DOOR ASSY-RH DOOR EEE-182 Door Break Down 92348 92617 ASSY-LH DOOR ASSY-RH DOOR EEE-181 Door Break Down 92931 ASSY-LH DOOR...
  • Page 102 Model EEE-182 Door Hinge Chart Top Hinge Top Hinge Bottom Hinge Bottom Hinge Door Bushing (Frame) (Door) (Door) (Frame) 92931 92080 92342 92340 92079 39752 92348 92080 92342 92340 92079 39752 92617 92620 92618 92619 92621 39752 92616 92080 92342 92340 92079 39752...
  • Page 103 Model EEE-182 Top View Item No. Part No. Description Quantity 77838 WELD ASSY- LOW OIL DIVERTER ........1/vat NS03-044 NUT - ACORN - #10-24 - SS ..........1/vat Β 4 74725 HANDLE - ELEMENT LIFT ..........Β 5 84362 RACK - SPLIT VAT ..............1/vat Β...
  • Page 104 Model EEE-182 Control Panel Assembly Control Assembly Item No. Part No. Description Quantity Β 1 81943RB ASSY - EEE14X CONTROL ..........Β 1 84417RB ASSY - EEE14X AUTO LIFT CONTROL ......81354 DECAL - EVOLUTION ELITE CONTROL ....1/control ® 83206 DECAL - EE AUTO LIFT CONTROL ......
  • Page 105 Model EEE-182 EEE-14X Filter Pan Assembly & Cleaning Brushes Item No. Part No. Description Quantity 77531 ASSY - DRAIN PAN ............... 87609 ASSY - DRAIN PAN - EEE-141 Only ........82673 ASSY-DRAIN PAN COVER ..........82674 ASSY-DRAIN PAN COVER - EEE-141 Only ....76259 WELD ASSY-CRUMB CATCHER ........
  • Page 106 Model EEE-182 JIB System - EEE-142, 143, 144 Item No. Part No. Description Quantity 03617 ACCESSORY-JUG-AUTO TOP OFF (EMPTY) ...... 78992 ASSY-JIB TUBE & QUICK DISC ..........80490 ASSY-INT’L. JIB TUBE & QUICK DISC ......... 81513 ASSY - HOSE ................85966 WELD ASSY - JIB SHELF ............
  • Page 107 Model EEE-182 Oil Pan & Door Assembly - EEE-141 Item No. Part No. Description Quantity 74189 O-RING-PICKUP TUBE ..........85969 OIL BOX WELD ASSY - FULL VAT ......89376 OIL BOX WELD ASSY - SPLIT VAT ......86065 OIL BOX COVER ASSY ..........85163 DOOR ASSY - EEX-141 ..........
  • Page 108 Model EEE-182 Oil Management Components - EEE-141 Item No. Part No. Description Quantity 74582 VALVE - SOLENOID 220-240V - 1/2N (Vat Fill Solenoids) . 74469 VALVE - CHECK - 1/2” (Vat Fill) ........74583 PUMP - OIL TOP OFF - 230V ..........85777 PUMP &...
  • Page 109 Model EEE-182 Drain Valve Linkage Parts Item No. Part No. Description Quantity XXXXX See Chart on next page 1/vat 79590 VALVE-DRAIN 1.250 PORT W/O HDL 1/vat VALVE-DRAIN 1-1/2 NPT X 1 NPT - EEE141 ONLY 83732 81911 ASSY-ACTUATOR DRAIN W/O-RINGS (Smart Touch) 1/vat 73994 HANDLE - PIVOT - DRAIN 1/vat...
  • Page 110 Model EEE-182 Pivot Stop Drain Handle Kit / Part Numbers 74626 81573 Models 17255 17255 140175 140176 NS03-103 NS03-103 Full Vats: SN: BK1201020 & Before SN: EEE-141, 142, After (Jan. 25, 2012 BK1201020 143 & 144 Split Vats: SN:BK1202011 & Before SN: EEE-141, 142, After (Feb.
  • Page 111 Model EEE-182 EEE-142, EEE-143. EEE-144 EEE-141 Filter Return Line Assembly Item No. Part No. Description Quantity 77523-002 TUBE-SUCTION 18 IN L DORMONT ......FP01-206 CONNECTOR-3/8 NPT FEM 45 FLARE ..... FP01-029 REDUCER 1/2NPT M-3/8NPT F SS ......77259 BRACKET-PLUG AND PLAY ........77248 ADAPTER-TUBE END ..........
  • Page 112 Model EEE-182 Filter Motor and Pump Item No. Part No. Description Quantity Α 1 67583 MOTOR, 1/2 HP - 50/60 Hz ..........Α 2 17476 SEAL KIT ................ Β 3 17437 PUMP ASSEMBLY ............SC01-132 SCREW, Pump Cover ..........17451 COVER, Pump ............
  • Page 113 Model EEE-182 Bulk Dispose - EEE-142, 143, 144 Item No. Part No. Description Quantity 140053 KIT - EEE BULK DISPOSE RETROFIT ........Β 1 67662 ASSY - DIRECT CONNECT HOSE ........Β 2 21612 DISCONNECT - FEMALE ..........Β 3 21800 VALVE - 3/4 CHECK ............
  • Page 114 Model EEE-182 Bulk Dispose - EEE-181 Item No. Part No. Description Quantity 140118 KIT - EEE-141 ONLY BULK DISPOSE ......Β 1 67662 ASSY - DIRECT CONNECT HOSE ......Β 2 21800 VALVE - 3/4 CHECK ..........Β 3* 21612 DISCONNECT - FEMALE ........
  • Page 115 Model EEE-182 Front Bulk Dispose - EEE-182 (Australia) EEE-182 Part No. Description B 17333 RINSE HOSE DISCONNECT FEMALE 1 B 74582 VALVE-220-240V SOLENOID 1/2NPT 77523-008 TUBE-SUCTION DORMONT-7 IN 91351 ASSY-2WELL FS RET OIL CHK V FD 81878 WELD ASSY-FS 2WELL MANIFOLD 81879 ASSY-2WELL JIB OIL CHECK VALVE 1 17407...
  • Page 116 Model EEE-182 Front Bulk Dispose - EEE-141 (France) Item No. Part No. Description Quantity Β 1 17333 DISCONNECT - FEMALE ..........84790 LABEL ................Β 3 84987 SWITCH - MOMENTARY - SPLASH ......140153 ASSY - HOSE DISPOSE ..........Β 5 17334 DISCONNECT - MALE ..........

This manual is also suitable for:

Evolution elite eee-183Evolution elite eee-181Evolution elite eee-184
