Command reference - xCommand
SubZoneAdd
Adds and configures a new subzone.
SubZoneName(r): <S: 1, 50>
Assigns a name to this subzone.
Address: <S: 0, 39>
Specifies an IP address used (in conjunction with the IP Prefix Length) to identify a subnet to be assigned to this subzone.
PrefixLength: <0..128>
Specifies the number of bits of the Subnet IP address which must match for an IP address to belong in this subzone.
TotalMode: <Unlimited/Limited/NoBandwidth>
Determines whether the Default Subzone has a limit on the total bandwidth being used by its endpoints at any one time. NoBandwidth: no bandwidth available. No calls can be made
to, from, or within the Default Subzone.
Default: Unlimited.
Total: <1..100000000>
Sets the total bandwidth limit (in kbps) of the Default Subzone (applies only if Mode is set to Limited). Default: 500000.
PerCallInterMode: <Unlimited/Limited/NoBandwidth>
Determines whether there is a limit on the bandwidth for any one call to or from an endpoint in this subzone. NoBandwidth: no bandwidth available. No calls can be made to or from
this subzone.
Default: Unlimited.
PerCallInter: <1..100000000>
Specifies the bandwidth limit (in kbps) on any one call to or from an endpoint in this subzone (applies only if Mode is set to Limited).
Default: 1920.
PerCallIntraMode: <Unlimited/Limited/NoBandwidth>
Determines whether there is a limit on the bandwidth for any one call between two endpoints within this subzone. NoBandwidth: no bandwidth available. No calls can be made within
this subzone.
Default: Unlimited.
PerCallIntra: <1..100000000>
Specifies the bandwidth limit (in kbps) for any one call between two endpoints within this subzone (applies only if Mode is set to Limited).
Default: 1920.
xCommand SubZoneAdd SubZoneName: "BranchOffice" Address: "10.13.0.0" PrefixLength: 28 TotalMode: Limited Total: 1024 PerCallInterMode:
Example:
Limited PerCallInter: 512 PerCallIntraMode: Limited PerCallIntra: 512
SubZoneDelete
Deletes a subzone.
SubZoneId(r): <1..100>
The index of the subzone to be deleted.
xCommand SubZoneDelete SubZoneId: 2
Example:
