Command reference - xConfiguration
Zones LocalZone Match [1..5] Pattern Replace: <S:0..60>
(Applies only if pattern behavior is set to Replace.) Specifies the string to be used as a substitution for the part of the alias that matched the pattern.
xConfiguration Zones LocalZone Match 1 Pattern Replace: "@example.com"
Example:
Zones LocalZone Match [1..5] Pattern String: <S:0..60>
Specifies the pattern against which the alias is compared.
xConfiguration Zones LocalZone Match 1 Pattern String: "@example.net"
Example:
Zones LocalZone Match [1..5] Pattern Type: <Exact/Prefix/Suffix/Regex>
Determines the way in which the string must match the alias.
Exact: the string must match the alias character for character.
Prefix: the string must appear at the beginning of the alias.
Suffix: the string must appear at the end of the alias.
Regex: the string will be treated as a regular expression.
Default: Prefix
xConfiguration Zones LocalZone Match 1 Pattern Type: suffix
Example:
Zones LocalZone Match [1..5] Priority: <1..65534>
Determines the order in which the zone will be sent a search request. Zones with priority 1 matches are searched first, followed by priority 2, and so on.
Default: 50
Example: xConfiguration Zones LocalZone Match 1 Priority: 100
Zones LocalZone SubZone [1..100] Bandwidth PerCall Inter Limit: <1..100000000>
Specifies the bandwidth limit (in kbps) on any one call to or from an endpoint in this subzone (applies only if Mode is set to Limited).
Default: 1920
xConfiguration Zones LocalZone SubZone 1 Bandwidth PerCall Inter Limit: 1920
Example:
Zones LocalZone SubZone [1..100] Bandwidth PerCall Inter Mode: <Limited/Unlimited/NoBandwidth>
Determines whether there is a limit on the bandwidth for any one call to or from an endpoint in this subzone.
NoBandwidth: no bandwidth available. No calls can be made to or from this subzone.
Default: Unlimited
xConfiguration Zones LocalZone SubZone 1 Bandwidth PerCall Inter Mode: Limited
Example:
Zones LocalZone SubZone [1..100] Bandwidth PerCall Intra Limit: <1..100000000>
Specifies the bandwidth limit (in kbps) for any one call between two endpoints within this subzone (applies only if Mode is set to Limited).
Default: 1920
Zones LocalZone SubZone 1 Bandwidth PerCall Intra Limit: 1920
Example:
