TANDBERG Video Communication Server Administrator's Manual page 223

Grey Headline (continued)
Command reference - xConfiguration
Zones Zone [1..200] Neighbor SIP Encryption Mode: <Auto/Off>
Determines whether or not the VCS will allow encrypted SIP calls on this zone.
Auto: SIP calls will be encrypted if a secure SIP transport (TLS) is used.
Off: SIP calls will never be encrypted.
Default: Auto
xConfiguration Zones Zone 3 Neighbor SIP Encryption Mode: Auto
Example:
Zones Zone [1..200] Neighbor SIP MIME Strip Mode: <On/Off>
Controls whether multipart MIME stripping is performed on requests from this zone. This must be set to On for connections to a Microsoft Office Communications Server 2007.
Default: Off
xConfiguration Zones Zone 3 Neighbor SIP MIME Strip Mode: Off
Example:
Zones Zone [1..200] Neighbor SIP MediaRouting Mode: <Auto/Signaled/Latching>
Specifies how the VCS handles the media for calls to and from this neighbor, and where it will forward the media destined for this neighbor.
Signaled: The media is always taken for calls to and from this neighbor. It will be forwarded as signaled in the SDP received from this neighbor.
Latching: The media is always taken for calls to and from this neighbor. It will be forwarded to the IP address and port from which media from this neighbor is received.
Auto: Media is only taken if the call is a traversal call. If this neighbor is behind a NAT the VCS will forward the media to the IP address and port from which media from this zone is received
(latching). Otherwise it will forward the media to the IP address and port signalled in the SDP (signaled).
Default: Auto.
xConfiguration Zones Zone 3 Neighbor SIP MediaRouting Mode: Auto
Example:
Zones Zone [1..200] Neighbor SIP Poison Mode: <On/Off>
SIP requests sent out this zone will be 'poisoned' such that if they are received by this VCS again they will be rejected.
Default: Off
xConfiguration Zones Zone 3 Neighbor SIP Poison Mode: Off
Example:
Zones Zone [1..200] Neighbor SIP Port: <1024..65534>
Specifies the port on the neighbor to be used for SIP calls to and from this VCS.
Default: 5060
xConfiguration Zones Zone 3 Neighbor SIP Port: 5060
Example:
Zones Zone [1..200] Neighbor SIP SDP Attribute Line Limit Length: <80..65535>
If SIP SDP attribute line limit mode is set to On, sets the maximum line length of a=fmtp SDP lines.
Default: 130
xConfiguration Zones Zone 3 Neighbor SIP SDP Attribute Line Limit Length: 130
Example:
