TANDBERG Video Communication Server Administrator's Manual page 193

Grey Headline (continued)
Command reference - xConfiguration
Administration HTTP Mode: <On/Off>
Determines whether HTTP calls will be redirected to the HTTPS port.
On: calls will be redirected to HTTPS.
Off: no HTTP access will be available.
Note: You must restart the system for any changes to take effect.
Default: On
xConfiguration Administration HTTP Mode: On
Example:
Administration HTTPS Mode: <On/Off>
Determines whether the VCS can be accessed via the web server. This must be
Note: You must restart the system for any changes to take effect.
Default: On
xConfiguration Administration HTTPS Mode: On
Example:
Administration SSH Mode: <On/Off>
Determines whether the VCS can be accessed via SSH and SCP.
Note: You must restart the system for any changes to take effect.
Default: On
xConfiguration Administration SSH Mode: On
Example:
Administration Telnet Mode: <On/Off>
Determines whether the VCS can be accessed via Telnet.
Note: You must restart the system for any changes to take effect.
Default: Off
xConfiguration Administration Telnet Mode: Off
Example:
Administration TimeOut: <0..10000>
Sets the number of minutes that an administration session (HTTPS, Telnet or SSH) may be inactive before the session is timed out. A value of
Default: 0
xConfiguration Administration TimeOut: 0
Example:
Alternates ConfigurationMaster: <1..6>
Specifies which peer in this cluster is the master, from which configuration will be replicated to all other peers. A cluster consists of up to 6 peers, including the local VCS.
xConfiguration Alternates ConfigurationMaster: 1
Example:
Alternates Peer [1..6] Address: <S: 0, 128>
Specifies the IP address of one of the peers in the cluster to which this VCS belongs. A cluster consists of up to 6 peers, including the local VCS.
Note: this must be a valid IPv4 or IPv6 address.
xConfiguration Alternates 1 Peer Address: "10.13.0.2"
Example:
