Command reference - xConfiguration
Zones Zone [1..200] Neighbor Interworking SIP Audio DefaultCodec: <G711u/G711a/G722_48/G722_56/G722_64/G722_1_16/G722_1_24/G722_1_32/G722_1_48/G723_1/G728/G729/AALCD_48/
AALCD_56/AALCD_64/AMR>
Specifies which audio codec to use when empty INVITEs are not allowed.
Default: G711u
xConfiguration Zones Zone 3 Neighbor Interworking SIP Audio DefaultCodec: G711u
Example:
Zones Zone [1..200] Neighbor Interworking SIP EmptyInviteAllowed: <On/Off>
Determines whether the VCS will generate a SIP INVITE message with no SDP to send to this zone. INVITES with no SDP mean that the destination device is asked to initiate the codec
selection, and are used when the call has been interworked locally from H.323.
On: SIP INVITEs with no SDP will be generated and sent to this neighbor.
Off: SIP INVITEs will be generated and a pre-configured SDP will be inserted before the INVITEs are sent to this neighbor..
Default: On
xConfiguration Zones Zone 3 Neighbor Interworking SIP EmptyInviteAllowed: On
Example:
Zones Zone [1..200] Neighbor Interworking SIP Search Strategy: <Options/Info>
Determines how the VCS will search for SIP endpoints when interworking an H.323 call.
Options: The VCS will send an OPTIONS request.
Info: the VCS will send an INFO request.
Default: Options
xConfiguration Zones Zone 3 Neighbor Interworking SIP Search Strategy: Options
Example:
Zones Zone [1..200] Neighbor Interworking SIP Video DefaultBitrate: <64..2048>
Specifies which video bitrate to use when empty INVITEs are not allowed.
Default: 384
xConfiguration Zones Zone 3 Neighbor Interworking SIP Video DefaultBitrate: 384
Example:
Zones Zone [1..200] Neighbor Interworking SIP Video DefaultCodec: <None/H261/H263/H263p/H263pp/H264>
Specifies which video codec to use when empty INVITEs are not allowed.
Default: H263
xConfiguration Zones Zone 3 Neighbor Interworking SIP Video DefaultCodec: H263
Example:
Zones Zone [1..200] Neighbor Interworking SIP Video DefaultResolution: <None/QCIF/CIF/4CIF/SIF/4SIF/VGA/SVGA/XGA>
Specifies which video resolution to use when empty INVITEs are not allowed.
Default: CIF
xConfiguration Zones Zone 3 Neighbor Interworking SIP Video DefaultResolution: CIF
Example:
Zones Zone [1..200] Neighbor Peer [1..6] Address: <S:0..128>
Specifies the IP address or Fully Qualified Domain Name (FQDN) of the neighbor. If the neighbor zone is a VCS cluster, this will be one of the peers in that cluster.
xConfiguration Zones Zone 3 Neighbor Peer 1 Address: "192.44.0.18"
Example:
