Grey Headline (continued)
Command reference - xConfiguration
Zones Zone [1..200] Match [1..5] Pattern Behavior: <Strip/Leave/Replace>
(Applies only if the Match mode is Pattern Match.) Determines whether the matched part of the alias should be modified before an LRQ is sent to this zone.
Leave: the alias will be unmodified.
Strip: the matching prefix or suffix will be removed from the alias.
Replace: the matching part of the alias will be substituted with the text in the Replace string.
Default: Strip
xConfiguration Zones Zone 2 Match 1 Pattern Behavior: Replace
Example:
Zones Zone [1..200] Match [1..5] Pattern Replace: <S: 0, 60>
(Applies only if the Pattern Behavior is Replace.) Specifies the string to be used as a substitution for the part of the alias that matched the pattern.
xConfiguration Zones Zone 2 Match 1 Pattern Replace: "example.com"
Example:
Zones Zone [1..200] Match [1..5] Pattern String: <S: 0, 60>
(Applies only if the Match mode is Pattern Match.) Specifies the pattern against which the alias is compared.
xConfiguration Zones Zone 2 Match 1 Pattern String: "example.net"
Example:
Zones Zone [1..200] Match [1..5] Pattern Type: <Exact/Prefix/Suffix/Regex>
(Applies only if the Match mode is Match.) Determines the way in which the string must match the alias.
Exact: the string must match the alias character for character.
Prefix: the string must appear at the beginning of the alias.
Suffix: the string must appear at the end of the alias.
Regex: the string will be treated as a regular expression.
Default: Prefix
xConfiguration Zones Zone 2 Match 1 Pattern Type: Suffix
Example:
Zones Zone [1..200] Match [1..5] Priority: <1..65534>
Determines the order in which the zone will be sent a search request. Zones with priority 1 matches are searched first, followed by priority 2, and so on.
Default: 100
xConfiguration Zones Zone 2 Match 1 Priority: 100
Example:
Zones Zone [1..200] Name: <S: 1, 50>
Assigns a name to this zone.
xConfiguration Zones Zone 3 Name: "UK Sales Office"
Example:
Zones Zone [1..200] Neighbor H323 Port: <1024..65534>
Specifies the port on the neighbor to be used for H.323 calls to and from this VCS.
Default: 1719
xConfiguration Zones Zone 3 Neighbor H323 Port: 1719
Example:
