TANDBERG Video Communication Server Administrator's Manual page 216

Grey Headline (continued)
Command reference - xConfiguration
Zones LocalZone SubZone [1..100] Bandwidth PerCall Intra Mode: <Limited/Unlimited/NoBandwidth>
Determines whether there is a limit on the bandwidth for any one call between two endpoints within this subzone.
NoBandwidth: no bandwidth available. No calls can be made within this subzone.
Default: Unlimited
xConfiguration Zones LocalZone SubZone 1 Bandwidth PerCall Intra Mode: Limited
Example:
Zones LocalZone SubZone [1..100] Bandwidth Total Limit: <1..100000000>
Sets the total bandwidth limit (in kbps) of this subzone (applies only if Mode is set to Limited).
Default: 500000
xConfiguration Zones LocalZone SubZone 1 Bandwidth Total Limit: 500000
Example:
Zones LocalZone SubZone [1..100] Bandwidth Total Mode: <Limited/Unlimited/NoBandwidth>
Determines whether this subzone has a limit on the total bandwidth of calls being used by its endpoints at any one time.
NoBandwidth: no bandwidth available. No calls can be made to, from, or within this subzone.
Default: Unlimited
xConfiguration Zones LocalZone SubZone 1 Bandwidth Total Mode: Limited
Example:
Zones LocalZone SubZone [1..100] Name: <S: 1, 50>
Assigns a name to this subzone.
xConfiguration Zones LocalZone SubZone 1 Name: "BranchOffice"
Example:
Zones LocalZone SubZone [1..100] Subnet [1..5] IP address: <S: 0, 39>
Specifies an IP address used (in conjunction with the IP Prefix Length) to identify a subnet to be assigned to this subzone.
Default: 0.0.0.0
xConfiguration Zones LocalZone SubZone 1 Subnet 1 IP address: "192.168.0.0"
Example:
Zones LocalZone SubZone [1..100] Subnet [1..5] IP PrefixLength: <0..128>
Specifies the number of bits of the Subnet IP address which must match for an IP address to belong in this subzone.
Default: 32
xConfiguration Zones LocalZone SubZone 1 Subnet 1 IP PrefixLength: 64
Example:
Zones LocalZone Traversal H323 Assent Mode: <On/Off>
Determines whether or not H.323 calls using Assent mode for firewall traversal will be allowed. Applies to traversal-enabled endpoints registered directly with the VCS.
Default: On
xConfiguration Zones LocalZone Traversal H323 Assent Mode: On
Example:
Zones LocalZone Traversal H323 H46018 Mode: <On/Off>
Determines whether or not H.323 calls using H460.18 mode for firewall traversal will be allowed. Applies to traversal-enabled endpoints registered directly with the VCS.
Default: On
xConfiguration Zones LocalZone Traversal H323 H46018 Mode: On
Example:
