Microscan MINI Hawk User Manual page 96

Initiating Calibration
Fine-Tune Pass
The theory behind Fine-Tune Pass is to dial in a decoded symbol based on the range
supplied by the Medium Pass.
Prog Rating
77 6416
79 6424
81 6424
84 6432
86 6448
88 6464
90 6476
93 6488
95 6506
97 6524
100 6538
Rating List (Best):
Rating = 6527; Focus = 386; Shutter = 250; Gain = 48
Rating = 6517; Focus = 386; Shutter = 250; Gain = 47
Rating = 6505; Focus = 386; Shutter = 250; Gain = 46
Rating = 6491; Focus = 386; Shutter = 250; Gain = 45
Rating = 6476; Focus = 386; Shutter = 250; Gain = 44
Rating = 6462; Focus = 386; Shutter = 250; Gain = 43
Rating = 6449; Focus = 386; Shutter = 250; Gain = 42
Calibration PASSED.
4-18
Running Fine Tune Pass
Decode Quality
3 104
3 112
3 112
3 120
3 136
3 152
3 164
3 176
3 194
3 212
3 226
Focus Shutter
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
MINI Hawk High Performance Imager User's Manual
Gain Locate
38 7
39 6
40 6
41 6
42 5
43 5
44 5
45 5
46 6
47 5
48 6
