Symbol Quality Separator/Data Matrix Output Mode

Symbol Quality Separator/Data Matrix Output Mode

Symbol Quality Separator applies to both Symbol Quality groups: ISO/IEC 16022 Symbol
Quality Output and Microscan Symbol Quality Output.
Symbol Quality Separator
Inserts a separator between each enabled field of the symbol quality output.
Definition:
<K708,symbol quality
Serial Cmd:
Default: <SP>
Any ASCII character.
Options:
Important: The ASCII characters <, >, and
For <:
<K708h,3C>
For >:
<K708h,3E>
For :
,
<K708h,2C>
See
ASCII Character Entry Modifier
enter ASCII characters as hex values.
Symbol Quality Separator by ESP
8-8
separator,output mode>
(space character)
on page 3-32 for a detailed explanation of how to
can only be entered as hex pairs:
,
When you double-click on the
default separator SP, the Symbol
Quality Separator Calculator
appears. Use the calculator keypad
for one-click separator configuration.
MINI Hawk High Performance Imager User's Manual
