Postal Symbologies
Postal Symbology Type
The following 1D Postal Symbologies are used in mail sortation, auditing,
Usage:
certified mail, registered mail, metered mail, and point-of-sale (POS) applications.
Determines the postal symbology that will be decoded by the imager.
Definition:
Postal symbology decode performance depends on accurate sampling
density information. Sampling density is determined by measuring the width
in pixels of a symbol image and then dividing that value by the width of the
actual symbol in inches or meters. For example, an image of a one-inch-wide
symbol that is 200 pixels across would have a sampling density of 200 dots
per inch.
The following table shows the range of supported sampling densities.
Symbology
U.S. Post
(POSTNET, PLANET,
USPS4CB)
Australia Post
Japan Post
Royal Mail, KIX
UPU
<K460,postal symbology
Serial Cmd:
status,POSTNET allow B and B' fields,Australia Post allow 0 FCC>
Default: Disabled
Options: 0 = Disabled
1 = U.S. Post (POSTNET, PLANET, USPS4CB)
2 = Australia Post
3 = Japan Post
4 = Royal Mail
5 = KIX
6 = UPU
6-30
Minimum Maximum
Sample Sample
Density Density
80 310
3150 12205
86 332
3386 13071
84 324
3307 12756
82 317
3228 12489
80 310
3150 12205
type,POSTNET status,PLANET status,USPS4CB
MINI Hawk High Performance Imager User's Manual
Unit of
Measurement
dots per inch
dots per meter
dots per inch
dots per meter
dots per inch
dots per meter
dots per inch
dots per meter
dots per inch
dots per meter
