Communication Protocol Commands
Image Output
Target/Flood LEDs
EZ Trax Output
Database Identifier Output
EZ Button
EZ Button Modes
Trend Analysis Output 1
Trend Analysis Output 2
Trend Analysis Output 3
Diagnostic Output 1
Diagnostic Output 2
Diagnostic Output 3
ISO/IEC 16022 Symbol Quality Output 1 <K800,output on symbol contrast,symbol contrast threshold,output
ISO/IEC 16022 Symbol Quality Output 2 <K801,output on symbol contrast,symbol contrast threshold,output
ISO/IEC 16022 Symbol Quality Output 3 <K802,output on symbol contrast,symbol contrast threshold,output
Configurable Output 1
Configurable Output 2
Configurable Output 3
Symbol Quality
Symbol Quality Separator/ Data Matrix
Output Mode
ISO/IEC 16022 Symbol Quality Output
Microscan Symbol Quality Output
Static Validation Report
Matchcode
Matchcode Type
Number of Master Symbols
New Master Pin
Enter Master Symbol Data
Request Master Symbol Data
A-10
<K739,image output mode,communication port,file format,JPEG
quality>
<K750,green flash LED status,target pattern LED status,green
flash duration>
<K757,comm port,image mode,image format,JPEG quality,
object info output,grade output>
<K759,status,separator>
<K770,global status,default on power-on,load Configuration
Database,save for power-on>
<K771,single beep,two beeps,three beeps,four beeps>
<K780,trend analysis mode,trigger evaluation period,number to
output on,decodes per trigger threshold>
<K781,trend analysis mode,trigger evaluation period,number to
output on,decodes per trigger threshold>
<K782,trend analysis mode,trigger evaluation period,number to
output on,decodes per trigger threshold>
<K790,unused 1,service unit>
<K791,unused 1,service unit>
<K792,unused 1,service unit>
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on UEC,UEC threshold>
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on UEC,UEC threshold>
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on UEC,UEC threshold>
<K810,output on,output state,pulse width,output mode>
<K811,output on,output state,pulse width,output mode>
<K812,output on,output state,pulse width,output mode>
<K708,symbol quality separator,data matrix output mode>
<K709,symbol contrast,print growth,axial non-uniformity,UEC>
<K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone>
<VAL>
<K223,matchcode type,sequential matching,match start position,match
length,wild card character,sequence on No Read,sequence on
mismatch>
<K224,number of master symbols>
<K225,status>
<K231,master symbol number,master symbol data>
<K231?,>[for all] or <K231?,master symbol number>
