Microscan MINI Hawk User Manual page 347

Delete Master Symbol Data
Match Replace
Mismatch Replace
Camera and IP Setup
Mirrored Image
Window of Interest
Focal Distance
Increment Focus Position
Decrement Focus Position
Focal Distance Table (Read-Only)
Illumination Brightness
Camera
Pixel Sub-Sampling
Morphological Pre-Processing
Morphological Operation
Configuration Database
Number of Active Indexes
Configuration Database Status
Save Current Settings to Database
Load Current Settings from Database
Request Selected Index Settings
Request All Database Settings
Database Mode
Output Format
Format Extract
Format Insert
Format Assign
Format Status
Output Filter Configuration
Ordered Output Filter
MINI Hawk High Performance Imager User's Manual
<K231,master symbol number,>
<K735,status,match replacement string>
<K736,status,mismatch replacement string>
<K514,mirrored image>
<K516,row pointer,column pointer,row depth,column width>
<K525,focal distance>
<525+>
<525–>
<K526,number of focal distances,focal distance>
<K536,brightness>
<K541,shutter speed,gain>
<K542,pixel sub-sampling,AEC/AGC mode,AEC/AGC brightness>
<K550,morphological pre-processing>
<K551,0,morphological operation,operator size>
<K252,number of active database settings,database sort>
<K255,index,shutter speed,gain,focal distance,pixel sub-sampling,
row pointer, column pointer,row depth,column width,narrow margins,
background color,symbology>
<K255+,index>
<K255-,index>
<K255?,index>
<K255?>
<K256,switch mode,frame count/time,image process looping,image
dimensions>
<K740,output index,start location,length>
<K741,output index,length,hex string>
<K742,symbol number,status>
<K743,output format status>
<K744,filter number,symbology,length,wildcard,placeholder,
data,unused,database index>
<K745,number of filters>
Appendices
A-11
