Microscan MINI Hawk User Manual page 95

Medium Pass
The theory behind Medium Pass is to develop a readable range from which to dial in a
decoded symbol.
Prog Rating
51 4216
53 8436
55 6336
57 8448
59 8456
61 8464
63 8472
65 8488
67 8504
69 8512
71 8528
73 8584
75 8644
Rating List (Best):
Rating = 8606; Focus = 386; Shutter = 250; Gain = 48
Rating = 8581; Focus = 386; Shutter = 250; Gain = 44
Rating = 8553; Focus = 386; Shutter = 250; Gain = 40
Rating = 8527; Focus = 386; Shutter = 250; Gain = 36
Rating = 8505; Focus = 386; Shutter = 250; Gain = 32
Rating = 8488; Focus = 386; Shutter = 250; Gain = 28
Rating = 8476; Focus = 386; Shutter = 250; Gain = 24
MINI Hawk High Performance Imager User's Manual
Running Medium Pass
Decode Quality
2 8
4 20
3 24
4 32
4 40
4 48
4 56
4 72
4 88
4 96
4 112
4 168
4 228
Focus Shutter
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
386 250
Calibration
Gain Locate
0 5
4 4
8 4
12 4
16 5
20 4
24 5
28 5
32 5
36 5
40 6
44 5
48 5
4-17
