Morphological Operation and Operator Size

Morphological Operation
Morphological Operation allows the user to select the method for processing
Definition:
captured images.
<K551,0,morphological
Serial Cmd:
Default: Erode
Options: 0 = Erode
1 = Dilate
2 = Open
3 = Close
Erode
Erode increases the dark cell size of a symbol. Useful for increasing the dark cell size of a
dark-on-light Data Matrix symbol.
Dilate
Dilate increases the light cell size of a symbol. Useful for increasing the light cell size of a
light-on-dark Data Matrix symbol.
MINI Hawk High Performance Imager User's Manual
operation,operator size>
Camera and IP Setup
10-27
