Capture Timing
Time Between Captures
This is useful in applications where more than one symbol can appear
Usage:
during a single read cycle (multisymbol), or where line speeds are slow
enough that captured frames might overlap or miss a symbol.
A time delay can be inserted between individual frame captures in Rapid
Definition:
Capture Mode.
<K242,time before 1st
Serial Cmd:
2,...time7]
Entering 0s will result in no time between captures.
Entering a different value in each field will vary the time delays accordingly.
Note: You must enter time values along with comma separators for each
field you want to change. If you omit fields, or enter only commas, the fields
will remain as previously set.
Important: If the imager is configured to capture more than 8 images, the
last (or 8th) delay value will be repeated for the remaining captures.
Default: 0
0 to 65535 (2.097 seconds, in 32
Options:
Note: Number of Captures and number of frame delays (Time Between Captures) must
be the same.
Start of Read Cycle
Diagram A
Diagram B
5-22
capture,time between captures
µS increments)
Time Delay Between Captures = 0
1 2 3 4 5
Time Delay Between Captures varies.
MINI Hawk High Performance Imager User's Manual
[time 1,time
End of
Read Cycle
