Optoisolator Inputs
All discrete inputs can be fully isolated pulses as PNP or NPN circuits.
V /I
IN-HIGH IN-HIGH
V /I
IN-LOW IN-LOW
Pulse Width
min
Input Examples
Fully Optoisolated
Isolated
V
CC
Not Optoisolated
Non-isolated
V
CC
New master pin input (–) is internally grounded.
MINI Hawk High Performance Imager User's Manual
Minimum Maximum
4.5 V/3.0mA 28 V/23mA
0 V/0mA 2.0V/1mA
48 µS
PNP Source
+V
Signal
Input (+)
Input (–)
New master pin input (–) is internally grounded.
PNP Source
+V
Power (+)
Input (+)
Input (–)
Power ground
New master pin input (–) is internally grounded.
Isolated
V
CC
Non-isolated Scanner
V
CC
Signal
Appendices
Input (+)
I
load
Input (–)
NPN Source
(trigger only)
+V
Input (+)
Input (–)
Signal
NPN Source
(trigger only)
+V
Power (+)
Input (+)
Input (–)
Signal
Power ground
