Address 0x008F Reserved (Default: 0x000A)

Address 0x0200 EEPROM Self Boot Control Register (Default: 0x0000)

Table 54.
Bit No. Bit Name
Bits[15] Self boot enable
Bits[14:6] Reserved
Bit[5] Safe load target/slew
RAM
Bit[4] Safe load parameter
RAM
Bits[3:0] Reserved

Address 0x0316 EEPROM Device Address Register (Default: 0x0050)

Table 55.
Bit No. Bit Name
Bits[15:7] Reserved
Bits [6:0] EEPROM device address

Address 0x0317 EEPROM Data Address Register (Default: 0x0000)

Table 56.
Bit No. Bit Name
Bits[15:0] EEPROM start address
ADAV4601 System Design Document
Rev.1 August 2009
Description
It initiates a self boot from the external EEPROM.
0b = normal operation
1b = initiates self boot
Always write as 0 if writing to this register.
Initiates a safe load to target/slew RAM. Cleared when safe load
completed.
0b = finished
1b = safe load request
Initiates a safe load to parameter RAM. Cleared when safe load
completed.
0b = finished
1b = safe load request
Always write as 0 if writing to this register.
Description
Always write as 0 if writing to this
register.
0x50 = sets external EEPROM address
Description
0x0000 = default address
Analog Devices
Default
0
000000000
0
0
0000
Default
000000000
1010000
Default
0000000000000000
Confidential Information
Page 98
