Bit No. Bit Name
Bit[3] Audio mute
Bit[2] Clear mute
Bit[1] Mute status
(read-only)
Bit[0] Mute flag (read-
only)

Address 0x0019 PWM Status Register (Default: 0x0000)

Table 49.
Bit No. Bit Name Description
Bits[15:4] Reserved Always write as 0 if writing to this register.
Bit[3] PWM4 status Set when the PWM4 outputs have gone from zero to 50/50 duty cycle.
0b = PWM4 disabled
1b = PWM4 enabled
Bits[2] PWM3 status Set when the PWM3 outputs have gone from zero to 50/50 duty cycle.
0b = PWM3 disabled
1b = PWM3 enabled
Bits[1] PWM2 status Set when the PWM2 outputs have gone from zero to 50/50 duty cycle.
0b = PWM2 disabled
1b = PWM2 enabled
Bit[0] PWM1 status Set when the PWM1 outputs have gone from zero to 50/50 duty cycle.
0b = PWM1 disabled
1b = PWM1 enabled

Address 0x001E Reserved (Default: 0x3205)

Address 0x001F PWM Control Register (Default: 0x1070)

Table 50.
Bit No. Bit Name
Bits[15:14] PWM Ready Configure
Bit[13] Reserved
ADAV4601 System Design Document
Rev.1 August 2009
Description
Used to control the software mute.
0b = unmute
1b = mute
Set to 1 to unmute the ADAV4601 when the external pin has been
used to mute the
part and the mute clear select bit is set. Having performed the
required action, this bit automatically resets to 0.
0b = no change
1b = clear pin mute
Displays the status of the ADAV4601 mute.
0b = currently unmuting or unmuted
1b = currently muting or muted
Set to 1 when the ADAV4601 is in mute.
0b = unmuted
1b = muted
Description
00b = PWM ready forced low
01b = PWM ready forced high
10b = PWM ready late
11b = PWM ready early
Always write as 0 if writing to this register.
Analog Devices
Default
0
0
0
0
Default
000000000000
0
0
0
0
Default
00
0
