Bit No. Bit Name
Bit[10] PWM Enable 4
Bit[9] PWM Enable 3
Bit[8] PWM Enable 2
Bit[7] PWM Enable 1
Bit[6] SRC2 lock (read-only)
Bit[5] SRC1 lock (read-only)
Bit[4] MCLK_OUT Enable
Bits[3:1] Select internally
generated clock
Bit[0] PLL enable
ADAV4601 System Design Document
Rev.1 August 2009
Description
The PWM outputs are disabled by default, which means that the
outputs are
at GND. When this bit is set to 1 and Bit[14] of this register is set to
1, then the
PWM Enable 4 channel is enabled.
0b = disabled
1b = enabled
The PWM outputs are disabled by default, which means that the
outputs are
at GND. When this bit is set to 1 and Bit[14] of this register is set to
1, then the
PWM Enable 3 channel is enabled.
0b = disabled
1b = enabled
The PWM outputs are disabled by default, which means that the
outputs are
at GND. When this bit is set to 1 and Bit[14] of this register is set to
1, then the
PWM Enable 2 channel is enabled.
0b = disabled
1b = enabled
The PWM outputs are disabled by default, which means that the
outputs are
at GND. When this bit is set to 1 and Bit[14] of this register is set to
1, then the
PWM Enable 1 channel is enabled.
0b = disabled
1b = enabled
Set to 1 when the sample rate converter (SRC) locks to the
incoming data,
indicating the data is valid.
0b = not locked
1b = locked
Set to 1 when the sample rate converter (SRC) locks to the
incoming data,
indicating the data is valid.
0b = not locked
1b = locked
Enables the clock chosen by Bit[13] and Bits[3:1] to be output on
the MCLK_OUT pin.
0b = MCLK_OUT function disabled
1b = MCLK_OUT function enabled
Selects the frequency of the internally generated clock to be output on
the MCLK_OUT pin.
000b = crystal clock from internal PLL
001b = audio processor clock (122.88 MHz/2560 × FS)
010b = engine clock 49.152 MHz/1024 × FS)
011b = SRC clock/2 (24.576 MHz/512 × FS)
1xxb = modulator clock (6.144 MHz/128 × FS)
Enables the PLL.
0b = PLL bypassed
1b = PLL enabled
