TESTPOINTS

Testpoints are distributed on the evaluation board to facilitate the examination of signals. In general a black
testpoint should reference a ground signal, while a red testpoint should reference other (non-ground) signals. Table
5 below indicates the corresponding signal for each testpoint.
Table 5: Testpoints
Testpoint Signal
TP1 SDIN0
TP3 BOARD3.3V
TP6 DUT_DVDD
TP7 DUT_3.3V
TP8 DGND
TP9 DGND
TP10 DGND
TP11 DGND
TP12 DGND
TP13 DGND
TP14 DGND
TP15 MUTEB
TP16 SDA
TP17 SCL
TP18 LRCLK2
TP19 BCLK2
TP20 DUT_DVDD
TP21 AGND
TP22 VREF
TP23 AGND
TP24 AGND
TP25 AGND
TP26 LRCLK0
TP27 BCLK0
TP29 ADI Testpoint
TP30 ADI Testpoint
TP31 ADI Testpoint
TP32 AGND
TP33 AGND
TP34 AGND
TP35 BCLK1
TP36 LRCLK1
TP37 SD0
TP42 DGND
TP43 DGND
ADAV4601 System Design Document
Rev.1 August 2009
Pin 22 of DUT (Not Stuffed)
Output of voltage regulator U35
DUT_AVDD, DUT_PLLVDD and DUT_ODVDD Supply
Pin 15 of DUT
Pin 16 of DUT
Pin 17 of DUT
Pin 18 of DUT
Pin 19 of DUT
Pin 14, 21, 31, 40 and 51 of DUT
Pin 2 of DUT
Pin 26 of DUT (Not Stuffed)
Pin 27 of DUT (Not Stuffed)
Pin 35 of DUT (Not Stuffed)
Pin 36 of DUT (Not Stuffed)
Pin 37 of DUT – I
Analog Devices
2
C Address select on reset (Not Stuffed)
