Note: When the communication channel is selected and connected to the eval board, the icon for the
communication channel changes from orange to white. This is provided the USB adaptor board shipped
with the evaluation kit is connected to the PC. This indicates that the adaptor board is using the correct
driver. The adaptor board should always be connected before SigmaStudio is launched.
5. SigmaStudio is now configured to use the ADAV4601 Evaluation Board. To begin creating a new flow click
on the Schematic tab.
ADAV4601 System Design Document
Rev.1 August 2009
Figure 24: Connecting the Eval Board to the Adaptor Board
Figure 25: Schematic Window
