STEP-BY-STEP SAMPLE PROJECT CREATION

Here are the steps to follow in order to create a sample Application Layer project from scratch.
Application Layer Project Creation from SigmaStudio Project.
The user needs to create a project folder for the Application Layer, and then link it to a previously created
SigmaStudio project.
1. Create a new project
2. Import a SigmaStudio project
3. Add cells to create new registers
a. Depending on the cell, a different wizard will load
4. Edit / delete registers if it's needed
5. Compile and link the project
6. Generate HTML and C code data
7. Download the ROMs
