LINKING THE APPLICATION LAYER SOFTWARE TO YOUR AUDIO FLOW

To create an Application Layer for the new SigmaStudio Audio Flow, the user must generate a number of files from
SigmaStudio. These files are used by the Application Layer Software.
Generate the project data files in
/project_folder/IC 1_name_of_folder
Generate params.params file. Save it in
/project_folder/IC1_name_of_folder
ADAV4601 System Design Document
Rev.1 August 2009
Figure 39:Generating and saving files for use in the Application Layer Software
Analog Devices
Input "params" as file name. Save it in
/project_folder/IC1_name_of_folder
