Tadiran Telecom Emerald ICE Installation Manual page 90

6-12
Emerald ICE Installation & Hardware Reference Manual
DID (Direct In Dial) ‐ Used for incoming trunk calls only. After
receiving an incoming call signaling, the DSP on the T1 receives the
Caller ID and DID number in "DTMF". Dial Tone will be provided to
the incoming DID trunk. After the Caller ID (if provided) and DID
numbers are received, the destination corresponding to the Service
Mode (Day / Night) by that time will be received after checking
against a Translation Table programmed for that Trunk Route of the
T1Trunk. If no destination is found or the destination does not exist,
the incoming call will be routed to a programmed Intercept extension.
If the Intercept is not programmed, it will ring to the Tenant
Attendant. If no DID digit in DTMF is received within 10 seconds, the
trunk will be routed to the Intercept No. and the call will ring to the
Intercept. If the Intercept is not programmed, it will ring to the Tenant
Attendant.
Immediate Start E&M ‐ Similar to Loop Start Trunk.
Wink Start E & M‐ A 'wink' must be detected first, and the dialed
number will be sent to a CO line. If the system does not get the
'wink', the call will be dropped.
b. Using the checkbox, select whether the programmed channel will
Loop Back.
c. Click on the
into the table.
5. Click on the Update button to enter your settings into the RMP database.
button to enter your information, for each channel,
