Tadiran Telecom Emerald ICE Installation Manual page 86

6-8
Emerald ICE Installation & Hardware Reference Manual
6. Select RP, CO Line Application, Translation Table as shown below.
7. Proceed with the following on the RP: CO Line Application‐Translation
Table:
a. Change the Translation Table No. field concur with he number of the
table that you selected in step 6.
b. Enter the DID Length of the extensions. This specifies the number of
DID (DDI) digits that will be sent from the Digital Trunk in the CO
Route for which the Table is assigned. The options are from 0' to '12.
Default is 0.
c. Enter an extension number in the Intercept field. This item specifies
the Extension or Hunt Group directory Number to which the
Incoming Digital calls will be routed if a match for the Incoming DID
(DDI) Digits is not in the Translation Table. The Intercept can be either
an Extension Directory No. or Hunt Group Directory No. The default
is NULL.
