Emerald ICE Installation & Hardware Reference Manual
KSU4
• 1 mounting template
• 1 Expansion Cabinet equipped with Base Board
• 1 hardware packet
Open the carton(s) and verify that all items are complete and undamaged. Remove
all packing material and store for future use in the event that return shipment is
required.
Mounting the KSU
Follow these instructions to mount the KSU.
1. Select a suitable location for the KSU3 considering that the expansion
(KSU4) may be installed at the same time or sometime in the future. KSU3
and KSU4 may be mounted such that they are side‐by‐side or mounted
one above the other. The ventilation and mounting provisions of each KSU
allow them to be mounted horizontally or vertically. Refer to the pictures
for examples of how the KSU(s) may be mounted.
