2-30
Emerald ICE Installation & Hardware Reference Manual
The IVM board can be substituted for the VAA card on the CCB for more
user-friendly call administration.
VoIP Gateway provides four more ports for the user to make VoIP calls
through the Internet simultaneously.
2. Second Cabinet ‐ Maximum: equipped to use 6 boards (base board is
included by default for PCB interconnection).
Base + 6CO + 12EKT + 6CO + 12EKT
...or Base + 6CO + 12EKT + 6CO + 12 EKT + 4SLT + 4SLT
...or Base + T1/PRI + 12EKT + 12EKT
...or Base + T1/PRI + 6CO + 12EKT + 12EKT
...or Base + T1/PRI + 6CO + 12EKT + 12EKT+ 4SLT + 4SLT
