2.16
Figure 2-15 Deluxe
Telphone with DSS Unit
2-20
Emerald ICE Installation & Hardware Reference Manual

DSS (Direct Station Selection Terminal)

The DSS Console is a digitally interfaced component of the Emerald ICE. It
connects to the system via any available digital port (610+2 Board/E or 12EKT
digital port). The DSS is equipped with 40 Programmable Buttons. 12 of these
buttons are intended for features code storage only and do not have LED
indications associated with them. The 40 buttons are equipped with dual color
LEDs and may be assigned any system Feature Code or Directory Number. (These
buttons may be assigned for either system features operations or CO line access
operations.)
The DSS Console may be mounted in two positions (Lower Profile Desk Position
and Wall Mounted Position). DSS Consoles are programmed to operate with an
associated speakerphone. Speakerphones may be assigned up to 4 DSS Consoles
each if required. The maximum DSS Consoles supported by the Emerald ICE is 12.
Each equipped DSS Console requires one digital port therefore the total number
(system capacity) of speakerphones possible is reduced by one for each DSS
console installed.
