Displaying the Speed and Duplex Mode of Ports

You can display the speed and duplex mode of ports in the Switch
graphic using the Port Summary page.
To access the page:
Click the Summary hotlink under the Switch graphic. The Port
Summary page is displayed as shown in
Figure 7 The Port Summary page
If you have an Expansion Module fitted to your Switch, the Expansion
Module port numbers follow on sequentially from the number of fixed
ports.

Refreshing the Switch Graphic

The Switch graphic does not update itself automatically — if you make a
change to the status of a port, you need to click the Refresh hotlink
positioned under the Switch graphic. If, after clicking Refresh, the Switch
graphic does not update, you may need to make a small change to your
Web browser; for more information, see
Problems" on page 214.
Configuring the Current Switch
Figure 7.
"Solving Web Interface
55
