130 C 4: W
HAPTER ORKING
Setting Up a Resilient
Link
Displaying Resilient
Link Information
W C L
ITH THE OMMAND INE
You can set up resilient links on the Switch units within the stack using
the command on the Resilience menu.
define
To set up a resilient link:
1 At the Top-level menu, enter:
feature resilience define
The following prompt is displayed:
Select unit for main link (1-4):
2 Enter the unit number for the main link that you wish to define.
The following prompt is displayed:
Select port for the main link (1,2,7):
3 Enter the port number for the main link that you wish to define.
The following prompt is displayed:
Select unit for standby link (1-4):
4 Enter the number of the unit for the standby link that you wish to define.
The following prompt is displayed:
Select port for the standby link (3,6):
5 Enter the number of the port for the standby link that you wish to define.
You can display detailed information for all resilient links set up within the
stack using the
detail
To display resilient link information:
1 At the Top-level menu, enter:
feature resilience detail
2 The resilient link information is displayed as shown in the example below.
Index Main Link
1 Unit 1 Port 1 Failed Unit 2 Port 1 Failed Standby
2 Unit 1 Port 6 Failed Unit 2 Port 6 Active Standby
Select menu option:
I
NTERFACE
command on the Resilience menu.
State Standby Link State Active Link Pair State
Operationa
l
Operationa
l
