Modifying a VLAN

W C L
ITH THE OMMAND INE
The following prompt is displayed:
Select VLAN ID (1-4094) [1]:
2 Enter the VLAN ID that you wish to display.
The detailed VLAN information for the selected VLAN ID is displayed as
shown in the example below.
VLAN ID: 1 Local ID: 1
Unit Ports
1 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
2 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14
Unicast Frames:
Multicast Frames:
Select menu option:
Immediately after creating a VLAN, the VLAN based counters will only
count for ports local to the unit where the VLAN was created. In order for
ports in other units to contribute to the VLAN counters, a reset of the
stack is required.
You can modify the VLAN name for a specified VLAN ID using the
command on the VLAN menu.
To modify a VLAN name:
1 At the Top-level menu, enter:
bridge vlan modify
The following prompt is displayed:
Select VLAN ID (1-4094) [1]:
2 Enter the VLAN ID that you wish to modify.
The following prompt is displayed:
Enter VLAN Name [VLAN 3]:
3 Enter the new VLAN name. The default option is the current VLAN name
for the specified VLAN ID.
I
NTERFACE
Name: Default VLAN
18564 Octets:
28157 Broadcast Frames:
4989235
0
modify
