Chapter 2
Installation
This Chapter covers the physical installation of the UniGateway EH-2101W.
Requirements
•
Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors.
•
TCP/IP protocol must be installed on all PCs.
•
For Internet Access, an Internet Access account with an ISP, and either of:
•
A DSL or Cable modem (for WAN port usage)
•
An analog modem or ISDN TA (for serial port usage)
•
To use the Wireless Access Point, all Wireless devices must be compliant with the
IEEE802.11b specifications.
•
For shared access to the attached printer, the following clients are supported:
•
Windows 95/98/ME
•
Windows NT 4.0, 2000, or XP.
•
Apple Macintosh
•
Unix (LPD printing)
Procedure
1. Choose an Installation Site
Select a suitable place on the network to install the UniGateway EH-2101W.
Ensure the UniGateway EH-2101W and the DSL/Cable modem are powered OFF.
Figure 3: Installation Diagram
2
8
