For best Wireless reception and performance, the Access
Point should be positioned in a central location with mini-
mum obstructions between the Access Point and the PCs.
Also, if using multiple Access Points, adjacent Access
Points should use different Channels.
2. Insert Wireless PCMCIA card
Ensuring the supplied Wireless PCMCIA card is the right way up, insert it into the slot on
the rear. Push it firmly until it clicks into position.
3. Connect LAN Cables
Use standard LAN cables to connect PCs to the Switching Hub ports on the UniGateway
EH-2101W. Both 10BaseT and 100BaseT connections can be used simultaneously.
If required, connect the "Uplink" port to a normal port on another Hub, using a standard
LAN cable.
Note: If the "Uplink" port is used, LAN port 1 can NOT be used.
4. Connect WAN Cable
Connect the DSL or Cable modem to the WAN port on the UniGateway EH-2101W. Use
the cable supplied with your DSL/Cable modem. If no cable was supplied, use a standard
cable.
5. Connect Printer Cable
Use a standard parallel printer cable to connect your printer to the Printer port on the Uni-
Gateway EH-2101W.
6. Power Up
•
Power on the Cable or DSL modem.
•
Connect the supplied power adapter to the UniGateway EH-2101W and power up.
Use only the power adapter provided. Using a different one may cause hardware damage
7. Check the LEDs
•
The Power LED should be ON.
•
The Status LED should flash, then turn Off. If it stays on, there is a hardware error.
•
For each LAN (PC) connection, the LAN Link/Act LED should be ON (provided the PC is
also ON.)
•
The WAN LED should be ON.
•
The Wireless LED should be ON.
•
If the printer is On and On-line, the Print Act LED should be ON.
For more information, refer to Front-mounted LEDs in Chapter 1.
