Wireless
On - Wireless connection available; Wireless Access Point is ready for
use.
Off - No Wireless connection available.
Flashing - Data is transmitted or received via the Wireless access point.
This includes "network traffic" as well as user data.
WAN
On - Connection to the modem attached to the WAN (Internet) port is
established.
Flashing - Data is being transmitted or received via the WAN port.
COM
Off - Idle or no active device connected to the serial (RS232) port.
(Serial Port)
Flashing - Data is transmitted or received via the serial (RS232) port.
Print Act
On - Connection to printer established.
Off - No connection to printer; printer is Off or Off-line.
Flashing - Data is being transmitted to the printer.
Print Error
On - Printer error detected.
Off - No printer error detected.
Introduction
5
