CDM-600L Satellite Modem
Front Panel Operation
6.3.7.1
ODU: BUC-FSK
FSK: LINK =OFF
Select a parameter to edit using the [←] [→] arrow keys.
LINK
TX-OUTPUT
LEVELING
ADDRESS
ODU: BUC-CONFIG
BUC: POWER=OFF 10MHz=OFF ALARM-LOW=0.0A
ALARM-HIGH=2.0A CAR-DELAY=00:00 MIN:SEC
Select a parameter to edit using the [←] [→] arrow keys.
POWER
10 MHz
ALARM-LOW
ALARM-HIGH
CAR-DELAY
MIN:SEC
LEVELING=N/A
Turns the FSK communications with the BUC ON and OFF. Use [↑] [↓]
arrow keys to select ON and OFF and press ENTER.
Disabled in LINK OFF position. Turns the TX RF output from the BUC ON
and OFF. Use [↑] [↓] arrow keys to select ON or OFFand then press
ENTER.
Disabled in LINK OFF position. Turns the automatic BUC output power
leveling loop ON and OFF. Use [↑] [↓] arrow keys to select ON or OFF and
press ENTER.
Disabled in LINK OFF position. Sets the FSK address for the BUC. Use [↑]
[↓] arrow keys to select the address from 1 to 15 and press ENTER.
Turns the BUC power supply ON and OFF. Use [↑] [↓] arrow keys to select
ON and OFF and press ENTER.
Turns the 10 MHz reference output to the BUC ON and OFF. Use [↑] [↓]
arrow keys to select ON or OFF and press ENTER.
Sets the BUC low current alarm threshold in amps. Use [↑] [↓] and [←]
[→] arrow keys set the threshold and press ENTER.
Sets the BUC high current alarm threshold in amps. Use [↑] [↓] and [←]
[→] arrow keys set the threshold and press ENTER.
Sets a carrier time delay from modem power up to TX carrier output turn
On. This time delay allows the BUC to warm up for stable operating
frequency or output power prior to transmitting a carrier. Use [↑] [↓] and [←]
[→] arrow keys to set carrier on delay. If a nonzero value of carrier delay is
set up, this menu also shows the remaining time for the output delay to
expire. When the cursor is not on the CAR-DELAY field, the timer will count
down any time remaining, and indicates this on the front panel by a flashing
TX LED.
TX–OUTPUT=N/A
ADDRESS=N/A
6–43
Revision 2
MN/CDM600L.IOM
