CDM-600L Satellite Modem
Remote Control
Command
Arguments
(Instruction
for Command
Parameter
Type
Code and
or Response
Qualifier)
AUPC
APP=
6 bytes
Parameters
Circuit ID
CID=
40 bytes
String
Outdoor Unit
ODU=
1 byte, value
Comms enable
of 0 or 1
Configuration
CST=
1 byte
Save
Configuration
CLD=
1 byte
Load
Description of Arguments
to Query
Command or Query.
Defines AUPC operating parameters. Format is abc.cd, where:
a=Defines action on max. power condition.
(0=do nothing, 1=generate Tx alarm)
b=Defines action on remote demod unlock.
(0=go to nominal power, 1=go to max power)
c.c=target Eb/No value, for remote demod, from 0.0 to 9.9 dB
d =Max increase in Tx Power permitted, from 0.0 to 9.0 dB
Example: APP=015.67 (Sets no alarm, max power, 5.6 dB target
and 7 dB power increase.
Command or Query.
Sets or queries the user-defined Circuit ID string, which is a
fixed length of 40 characters.
Valid characters include:
Space ( ) * + – , . / 0 9 and A thru Z
Command or Query.
Enables or disables communications, via the FSK link, with a
compatible transceiver (ODU), where:
0=Disabled
1=Enabled
Example: ODU=0 (Disabled)
Command only.
Command causes the CDM600L to store the current modem
configuration in Configuration Memory location defined by the
one-byte argument (0 to 9).
Example: CST=4 (store the current configuration in location 4)
Command only.
Causes the CDM600L to retrieve a previously stored modem
configuration from Configuration Memory location defined by
the one-byte argument (0 to 9).
Example: CLD=4 (retrieve modem configuration from
location 4)
Response to
Command
APP=
APP?
APP*
APP#
CID=
CID?
CID*
CID#
ODU=
ODU?
ODU*
ODU#
CST=
CST?
CST*
CST#
CLD=
CLD?
CLD*
CLD#
16–23
Revision 2
MN/CDM600L.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
APP?
APP=abc.cd
(see description of
arguments)
CID?
CID=x
(see description of
arguments)
ODU?
ODU=x
(see description of
arguments)
N/A
N/A
N/A
N/A
